▶ EngineEngine Manufacturer Kubota Kubota Engine Model D902 V3307-CR-TE4 Engine Type Liquid-cooled, 4-cycle diesel Liquid-cooled, diesel, 4-cylinder, Turbocharged No. of Cylinders 3 4 Displacement 54.8 in³ 203 in³ Rated Engine Speed 3200 rpm 2400 rpm Engine Power (Gross) 21.6 hp 66.4 hp PTO Power 17.7 hp 56 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry element Dry paper, dual element, 8 in diameter, with pre-cleaner Fuel System Direct injection Common Rail System (CRS) Alternator 40 A, 12 V 45 A, 12 V ▶ HydraulicsPump Type Open center tandem pump gear type Gear Implement Flow 5.2 gpm 11.0 gpm Steering Flow 1.0 gpm 6.1 gpm Total Hydraulic Flow 6.2 gpm 17.1 gpm Overall Hydraulic Pump Flow 6.2 gpm 17.1 gpm Hydraulic System Type Open center tandem pump gear type Open Center Rear Remote Hydraulic Flow Not Published 11.0 gpm No. of Standard Remote Valves None (2-valve rear remote coupler optional) 1 (SCD) No. of Optional Remote Valves 2 (optional; ISO 7241-1 series A or B) 2nd, 3rd (optional) ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 18.5 gal Coolant Capacity 3.3 qt 8.5 qt Crankcase Capacity 3.4 qt 12.7 qt Transmission / Hydraulic System Capacity 2.98 gal 14.8 gal Front Axle Fluid Capacity 3.8 qt 5.8 qt (differential) plus 3.7 qt (each bevel gear case) ▶ PTO & HitchPTO Type Live independent PTO (with hydraulic clutch) Live-independent PTO, electro-hydraulic clutch with brake PTO Rear STD 540 rpm 540 rpm (540/540E optional) Mid-PTO Availability USA No.5 (KUBOTA 10-tooth) involute spline, 2500 rpm Not Published Category, 3-Point Hitch SAE Category I (optional) I / II Hitch Lift Capacity 1,213 lb 4,189 lb Hitch Lift Capacity (at 24”) 680 lb 3,307 lb Lift Control Type Quarter-inching valve Position, Draft (Top Link Sensing) & Mixed Control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission, high-low gear shift (2 forward, 2 reverse) Hydraulic-shuttle transmission (fully synchronized) No. of Speeds 2 Range (Low-High) F8/R8 Max Travel Speed (Forward) 0 mph to 8.4 mph 18.0 mph Max Travel Speed (Reverse) 0 mph to 6.5 mph 17.7 mph Clutch Dry type single plate - Main clutch 9.45" Multiple wet disc Differential Lock & Limited Slip Options Rear differential lock standard Rear differential lock standard (mechanical) ▶ Chassis, Steering & ControlsFrame Type Two-post foldable ROPS Two-post foldable ROPS Steering Hydrostatic Power Steering Hydrostatic power steering Brakes Mechanical, wet disc type Mechanical wet disc Seat Suspension & Adjustability High-back reversible seat (rotates for backhoe operation); fore/aft slide and backrest tilt adjustment Suspension seat, adjustable (travel, suspension tension, backrest tilt, armrests); optional air-suspension seat on cab models Front Axle Type 4WD: Bevel gear front axle, non-adjustable tread spacing Bevel gear type with 55 degree turning angle (4WD) Front Axle Rating Not Published 5,290 lb (6,615 lb with loader) Drawbar Capacity Maximum tongue weight 550 lb 2,200 lb ▶ Dimensions & ManeuverabilityOverall Width 45.1 in 73.0 in Wheelbase 55.1 in 83.1 in Ground Clearance 6.5 in (front axle) 18.1 in (crop clearance at front axle); 15.4 in (minimum ground clearance) Min. Turn Radius without Brakes 7.5 ft 11.8 ft Height to Top of ROPS 86.2 in 96.9 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published n/a (ROPS model) Overall Length 99.0 in (with 3-point hitch, with front guard) 138 in ▶ WeightTractor Weight (Base) 1,600 lb (with ROPS, front guard and control valve assembly) 5,005 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Front Turf/Industrial: 18×8.5-10; Rear Turf/Industrial: 26×12-12; Bar tire N/A Standard: 9.5-24 front, 16.9-28 rear R1 Agricultural - Front Not Published 9.5-24 R1 Agricultural - Rear Not Published 16.9-28/14.9-28 R3 Turf - Front 18×8.5-10 LSW305-521 R3 Turf - Rear 26×12-12 LSW570-648 R4 Industrial - Front 18×8.5-10 12.5/80-18 R4 Industrial - Rear 26×12-12 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System Kubota Swift-Tach (Quick attach) LA1154A: 2-Lever Quick Coupler Loader Model LA340S (standard, quick attach); LA340 (pin-on option) LA1154A Loader Lift Height 71.0 in (at pivot pin) Height position: 132.7 in; Power position: 117.2 in Loader Lift Capacity (Full Height) 739 lb (LA340 pin-on); 613 lb (LA340S quick attach) Height position: 2,469 lb; Power position: 2,928 lb Loader Breakout Force 1,407 lbf (LA340 pin-on); 1,286 lbf (LA340S quick attach) Height position: 4,230 lbf; Power position: 5,354 lbf ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours Basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours ▶ ITC Company AccessoriesAccessories that fit
