▶ EngineEngine Manufacturer Kubota Kubota Engine Model D902 D1105-D10 Engine Type Diesel, 3-cylinder, liquid-cooled inline Diesel, 3-cylinder, liquid-cooled, indirect injection No. of Cylinders 3 3 Displacement 54.8 in³ 68.5 in³ Rated Engine Speed 3200 rpm 2600 rpm Engine Power (Gross) 23 hp 24 hp PTO Power 17.5 hp 18 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Not Published Fuel System Not Published Indirect injection Alternator Not Published Not Published ▶ HydraulicsPump Type Not Published Not Published Implement Flow 6.2 gpm 5.8 gpm Steering Flow Not Published Not Published Total Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 6.2 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 6.3 gal Coolant Capacity 2.8 qt 3.6 qt Crankcase Capacity 3.3 qt 3.6 qt Transmission / Hydraulic System Capacity Not Published 3.2 gal Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent (rear); independent (mid) Live PTO Rear 540 rpm 540 rpm Mid-PTO Availability Mid-PTO, 2500 rpm Mid-PTO, 2537 rpm (Kubota 10-tooth) Category, 3-Point Hitch Category I (optional) Category I Hitch Lift Capacity 992 lb 1280 lb Hitch Lift Capacity (at 24”) 670 lb 1015 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Not Published Hydrostatic transmission, 2-range No. of Speeds Not Published 2-range Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Not Published Not Published ▶ Chassis, Steering & ControlsFrame Type Two-post folding ROPS (canopy optional) Two-post ROPS Steering Hydrostatic type power steering Power steering Brakes Wet disc Wet disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 551 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 95.5 in (tractor alone) 91.7 in Overall Width 44.5 in 46.3 in Wheelbase 55.1 in 59.4 in Ground Clearance 8.7 in (front axle) 12.8 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 87.2 in 77.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 1587 lb (tractor only) 1570 lb Weight with ROPS and Loader 2475 lb Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 18x8.5-10 front, 26x12-12 rear (Turf/Bar/Industrial) Ag: 6.50-10 (2WD) or 7.00-12 (4WD) front, 11.2-16 rear R1 Agricultural - Front Not Published 2WD: 6.50-10; 4WD: 7.00-12 R1 Agricultural - Rear Not Published 11.2-16 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 18x8.5-10 Not Published R4 Industrial - Rear 26x12-12 Not Published ▶ Loader & AttachmentsQuick Attach Loader System LA240A quick attach loader Not Published Loader Model LA240A; LA240A AU-SG (spill guard) LA301; LA351 Loader Lift Height LA240A: 71.3 in (at pin) LA301: 70.5 in; LA351: 70.5 in Loader Lift Capacity (Full Height) LA240A: 745 lb (at pin) LA301: 660 lb; LA351: 770 lb Loader Breakout Force LA240A: 992 lb (at 19.7 in) (19.7 in forward of pivot pin) LA301: 1150 lbf; LA351: 1335 lbf ▶ WarrantyWarranty Length & Coverage Not Published Not Published
