▶ EngineEngine Manufacturer Kubota Yanmar Engine Model D1005 3TNV80F-CJT Engine Type Liquid-cooled, 4-cycle diesel 3-cylinder, liquid-cooled diesel No. of Cylinders 3 3 Displacement 61.1 in³ 77.3 in³ Rated Engine Speed 3200 rpm 3200 rpm Engine Power (Gross) 23.3 hp 23.9 hp PTO Power 19.2 hp 18 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Water with pressurized radiator, reverse air-flow design Liquid-cooled Air Cleaner Dry element Dry with safety element Fuel System Direct injection Indirect injection Alternator 40 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Open center tandem pump gear type Gear Implement Flow 5.2 gpm 3.5 gpm Steering Flow 1.0 gpm 3.5 gpm Total Hydraulic Flow 6.2 gpm 7 gpm Overall Hydraulic Pump Flow 6.2 gpm 6.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 3.5 gpm implement circuit; total 7 gpm No. of Standard Remote Valves None (2-valve rear remote coupler optional) Not Published No. of Optional Remote Valves 2 (optional; ISO 7241-1 series A or B) Not Published ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 6.3 gal Coolant Capacity 3.5 qt 3.9 qt Crankcase Capacity 4.2 qt 2.9 qt Transmission / Hydraulic System Capacity 3.0 gal 3.25 gal Front Axle Fluid Capacity 3.8 qt 3.0 qt ▶ PTO & HitchPTO Type Live independent PTO (with hydraulic clutch) Independent PTO Rear STD (540 rpm) 540 rpm Mid-PTO Availability STD (2500 rpm) Standard, 2100 rpm Category, 3-Point Hitch SAE Category I Limited Category I Hitch Lift Capacity 1,213 lb 1,177 lb Hitch Lift Capacity (at 24”) 680 lb 758 lb Lift Control Type Quarter-inching valve Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission Hydrostatic - 2 range No. of Speeds 2 Range (Low-High) Infinite (hydrostatic), 2 ranges forward and reverse Max Travel Speed (Forward) 8.4 mph 9.1 mph Max Travel Speed (Reverse) 6.5 mph 9.1 mph Clutch None (HST) wet disc Differential Lock & Limited Slip Options Rear differential lock standard Standard rear differential lock ▶ Chassis, Steering & ControlsFrame Type Two-post foldable ROPS Semi-flat platform; two-post folding ROPS; four-wheel drive Steering Hydrostatic type power steering Power steering Brakes Mechanical, wet disc type Wet disk, left-hand pedal Seat Suspension & Adjustability High-back seat with armrests; fore/aft slide and backrest-tilt adjustment Deluxe suspension seat with armrests and tilt steering wheel Front Axle Type 4WD: Bevel gear front axle, non-adjustable tread spacing 4WD (MFWD), on-the-go engagement Front Axle Rating Not Published 1,349 lb Drawbar Capacity Max. drawbar load @ hitch: 550 lb 2,165 lb ▶ Dimensions & ManeuverabilityOverall Width 45.1 in 47.22 in (R3 tires); 47.32 in (R4 tires) Wheelbase 55.1 in 57.1 in Ground Clearance 6.5 in 7.7 in (front axle) Min. Turn Radius without Brakes 7.5 ft 7.4 ft (no brakes, no MFWD) Height to Top of ROPS 83.1 in 90 in (ROPS extended, R4 tires) Height to Top of ROPS (folded) Not Published 73 in Height to Top of Cab Model Not Published Not Published Overall Length 95.5 in (with 3-point hitch) 108 in ▶ WeightTractor Weight (Base) 1,521 lb (with ROPS) 1,556 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial Standard R4, optional R3 R1 Agricultural - Front 18X8.5-10 Not Published R1 Agricultural - Rear 26X12-12 Not Published R3 Turf - Front 18X8.5-10 18x8.5-10 R3 Turf - Rear 26X12-12 26x12-12 R4 Industrial - Front 18X8.5-10 18x8.5-10 R4 Industrial - Rear 26X12-12 26x12-12 ▶ Loader & AttachmentsQuick Attach Loader System Swift-Tach Loader (LA344S - Two Lever Quick Attach Bucket) Tool-free attach and park (MSL optional on 120R) Loader Model LA344S (standard, quick attach); LA344 (pin-on option) 120R (MSL or NSL); 120E (NSL only) Loader Lift Height 71.0 in (at pivot pin) 120R: 72 in; 120E: 71.2 in Loader Lift Capacity (Full Height) 739 lb (LA344 pin-on); 613 lb (LA344S quick attach) 120R (MSL): 680 lb; 120E (NSL): 519 lb (at 19.7 in ahead of pivot) Loader Breakout Force 1,407 lbf (LA344 pin-on); 1,286 lbf (LA344S quick attach) Not Published ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours Powertrain 6 years, standard at no cost, covers residential and commercial use ▶ ITC Company AccessoriesAccessories that fit None tagged yet
