▶ EngineEngine Manufacturer Kubota Kubota Engine Model D1005 D1105-E4-TLB-1 Engine Type Liquid-cooled, 4-cycle diesel 3-cylinder, indirect injection, liquid-cooled diesel No. of Cylinders 3 3 Displacement 61.1 in³ 68.5 in³ Rated Engine Speed 3200 rpm 2800 rpm Engine Power (Gross) 23.3 hp 23.3 hp PTO Power 19.2 hp 19.4 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Water with pressurized radiator, reverse air-flow design Liquid-cooled Air Cleaner Dry element Single element Fuel System Direct injection Indirect injection Alternator 40 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Open center tandem pump gear type Not Published Implement Flow 5.2 gpm 7.0 gpm Steering Flow 1.0 gpm 4.2 gpm Total Hydraulic Flow 6.2 gpm 11.1 gpm Overall Hydraulic Pump Flow 6.2 gpm 11.1 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None (2-valve rear remote coupler optional) Not Published No. of Optional Remote Valves 2 (optional; ISO 7241-1 series A or B) Up to 3 ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 8.1 gal Coolant Capacity 3.5 qt 4.7 qt Crankcase Capacity 4.2 qt 3.2 qt Transmission / Hydraulic System Capacity 3.0 gal 6.9 gal Front Axle Fluid Capacity 3.8 qt 5.0 qt ▶ PTO & HitchPTO Type Live independent PTO (with hydraulic clutch) Independent PTO Rear STD (540 rpm) 540 rpm Mid-PTO Availability STD (2500 rpm) Not Published Category, 3-Point Hitch SAE Category I Category I (optional) Hitch Lift Capacity 1,213 lb 2,139 lb Hitch Lift Capacity (at 24”) 680 lb 1,676 lb Lift Control Type Quarter-inching valve Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission HST Plus hydrostatic transmission, 3-range No. of Speeds 2 Range (Low-High) 3-range (infinite) Max Travel Speed (Forward) 8.4 mph 11.1 mph Max Travel Speed (Reverse) 6.5 mph 9.8 mph Clutch None (HST) Not Published Differential Lock & Limited Slip Options Rear differential lock standard Rear axle differential lock standard ▶ Chassis, Steering & ControlsFrame Type Two-post foldable ROPS Four-post ROPS/FOPS standard Steering Hydrostatic type power steering Hydrostatic power steering Brakes Mechanical, wet disc type Wet disc Seat Suspension & Adjustability High-back seat with armrests; fore/aft slide and backrest-tilt adjustment Reversible seat; tilt steering standard Front Axle Type 4WD: Bevel gear front axle, non-adjustable tread spacing Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Max. drawbar load @ hitch: 550 lb 1,100 lb ▶ Dimensions & ManeuverabilityOverall Width 45.1 in 53.7 in Wheelbase 55.1 in 62.2 in Ground Clearance 6.5 in 13.8 in Min. Turn Radius without Brakes 7.5 ft 8.2 ft Height to Top of ROPS 83.1 in 89.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 95.5 in (with 3-point hitch) 100.7 in (without 3-point hitch) ▶ WeightTractor Weight (Base) 1,521 lb (with ROPS) 2,606 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial Industrial (R4): 23x8.5-14 R4 front, 12.4-16 R4 rear; turf 24x8.50-14 front, 13.6-16 rear R1 Agricultural - Front 18X8.5-10 Not Published R1 Agricultural - Rear 26X12-12 Not Published R3 Turf - Front 18X8.5-10 24x8.50-14 R3 Turf - Rear 26X12-12 13.6-16 R4 Industrial - Front 18X8.5-10 23x8.50-14 R4 R4 Industrial - Rear 26X12-12 12.4-16 R4 ▶ Loader & AttachmentsQuick Attach Loader System Swift-Tach Loader (LA344S - Two Lever Quick Attach Bucket) TL500: 2-lever quick coupler standard Loader Model LA344S (standard, quick attach); LA344 (pin-on option) TL500 Loader Lift Height 71.0 in (at pivot pin) TL500: 94.5 in (at pivot pin) Loader Lift Capacity (Full Height) 739 lb (LA344 pin-on); 613 lb (LA344S quick attach) TL500: 1,301 lb (at pivot pin) Loader Breakout Force 1,407 lbf (LA344 pin-on); 1,286 lbf (LA344S quick attach) TL500: 2,343 lbf (at pivot pin) ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
