▶ EngineEngine Manufacturer Kubota Yanmar Engine Model D1703-M-DI-E4 3TNV88F-EPJT2 Engine Type Direct injection, vertical, water-cooled, 4-cycle diesel Diesel, naturally aspirated, direct injection No. of Cylinders 3 3 Displacement 100.47 in³ 100.2 in³ Rated Engine Speed 2200 rpm 2400 rpm Engine Power (Gross) 24.8 hp 24.4 hp PTO Power 19 hp 19.4 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Water pump Air Cleaner Dry paper single element (dual optional) Dry type with safety element Fuel System Direct injection Direct injection Alternator 40 A, 12 V 55 A, 12 V ▶ HydraulicsPump Type Open center tandem pump, gear type Implement/steering pump: tandem gear pump; hydrostatic pump: PV axial-piston pump Implement Flow 5.15 gpm 5.3 gpm Steering Flow 3.11 gpm 4.0 gpm Total Hydraulic Flow 8.26 gpm 9.3 gpm Overall Hydraulic Pump Flow 8.26 gpm 9.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Up to 3: self-canceling detent valve or float detent valve Up to 2 (optional) ▶ Fluid CapacityFuel Tank Capacity 10.0 gal 7.5 gal Coolant Capacity 6.3 qt 5.2 qt Crankcase Capacity 6.0 qt 4.5 qt Transmission / Hydraulic System Capacity HST (4WD): 6.2 gal; DT (2WD): 7.1 gal; DT (4WD): 7.3 gal 5.5 gal Front Axle Fluid Capacity 6.9 qt 4 qt ▶ PTO & HitchPTO Type F (2WD), DT (4WD): Transmission driven with overrunning clutch; HST (4WD): Live-continuous running Not Published PTO Rear 540 rpm 540 rpm Mid-PTO Availability No mid-PTO offered Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,918 lb Not Published Hitch Lift Capacity (at 24”) 1,389 lb 1,356 lb Lift Control Type Position control Not Published ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission (3-range) Hydrostatic transmission (HST) No. of Speeds 3-range Not Published Max Travel Speed (Forward) 11.5 mph Not Published Max Travel Speed (Reverse) 10.3 mph Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Rear differential lock standard Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Open operator station (OOS) Steering Integral type power steering Power steering Brakes Wet disc type Wet disc Seat Suspension & Adjustability Suspension seat with fore/aft travel adjustment and suspension tension adjustment Not Published Front Axle Type Bevel gear front axle, non-adjustable tread spacing 4WD (MFWD) Front Axle Rating 2,865 lb (4WD, at 43.1 in tread) 1,760 lb Drawbar Capacity 730 lb 880 lb (maximum vertical load) ▶ Dimensions & ManeuverabilityOverall Width 55.1 in 56.9 in (min. rear tread, standard R1 tires); 61.7 in (max. rear tread, larger R4 tires) Wheelbase 63.3 in 62.8 in Ground Clearance 13.4 in 12.7 in (R4 tires) Min. Turn Radius without Brakes 8.2 ft (with brake applied) Not Published Height to Top of ROPS 91.7 in 95.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 106.3 in (without 3-point hitch) 115.9 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 2,623 lb 2,222 lb Weight with ROPS and Loader Not Published 2,972 lb Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R4 Industrial R1 Bar, R3 Turf, R4 Industrial R1 Agricultural - Front 7.2-16 7-14 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front Not Published 27X8.50-15 R3 Turf - Rear Not Published 41X14-20 R4 Industrial - Front 27X8.50-15 25X8.50-14 or 27X8.50-15 R4 Industrial - Rear 15-19.5 15-19.5 or 43x16-20 ▶ Loader & AttachmentsQuick Attach Loader System Front Loader (LA525 - 2 Lever Quick Coupler) Quick-change attachment carrier Loader Model LA525 300E Loader Lift Height 94.3 in (at pivot pin) 84 in (at pivot pin) Loader Lift Capacity (Full Height) 1,082 lb (at pivot pin) 1,186 lb (at pivot pin) Loader Breakout Force 2,373 lbf (at pivot pin) 1,704 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours Basic 24 months or 2,000 hours; powertrain 72 months or 2,000 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
