▶ EngineEngine Manufacturer Kubota Kubota Engine Model D1703-M-DI-E4 D1105-E4-TLB-1 Engine Type Direct injection, vertical, water-cooled, 4-cycle diesel 3-cylinder, indirect injection, liquid-cooled diesel No. of Cylinders 3 3 Displacement 100.47 in³ 68.5 in³ Rated Engine Speed 2200 rpm 2800 rpm Engine Power (Gross) 24.8 hp 23.3 hp PTO Power 19 hp 19.4 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dry paper single element (dual optional) Single element Fuel System Direct injection Indirect injection Alternator 40 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Open center tandem pump, gear type Not Published Implement Flow 5.15 gpm 7.0 gpm Steering Flow 3.11 gpm 4.2 gpm Total Hydraulic Flow 8.26 gpm 11.1 gpm Overall Hydraulic Pump Flow 8.26 gpm 11.1 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Up to 3: self-canceling detent valve or float detent valve Up to 3 ▶ Fluid CapacityFuel Tank Capacity 10.0 gal 8.1 gal Coolant Capacity 6.3 qt 4.7 qt Crankcase Capacity 6.0 qt 3.2 qt Transmission / Hydraulic System Capacity HST (4WD): 6.2 gal; DT (2WD): 7.1 gal; DT (4WD): 7.3 gal 6.9 gal Front Axle Fluid Capacity 6.9 qt 5.0 qt ▶ PTO & HitchPTO Type F (2WD), DT (4WD): Transmission driven with overrunning clutch; HST (4WD): Live-continuous running Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability No mid-PTO offered Not Published Category, 3-Point Hitch Category I Category I (optional) Hitch Lift Capacity 1,918 lb 2,139 lb Hitch Lift Capacity (at 24”) 1,389 lb 1,676 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission (3-range) HST Plus hydrostatic transmission, 3-range No. of Speeds 3-range 3-range (infinite) Max Travel Speed (Forward) 11.5 mph 11.1 mph Max Travel Speed (Reverse) 10.3 mph 9.8 mph Clutch Not Published Not Published Differential Lock & Limited Slip Options Rear differential lock standard Rear axle differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Four-post ROPS/FOPS standard Steering Integral type power steering Hydrostatic power steering Brakes Wet disc type Wet disc Seat Suspension & Adjustability Suspension seat with fore/aft travel adjustment and suspension tension adjustment Reversible seat; tilt steering standard Front Axle Type Bevel gear front axle, non-adjustable tread spacing Not Published Front Axle Rating 2,865 lb (4WD, at 43.1 in tread) Not Published Drawbar Capacity 730 lb 1,100 lb ▶ Dimensions & ManeuverabilityOverall Width 55.1 in 53.7 in Wheelbase 63.3 in 62.2 in Ground Clearance 13.4 in 13.8 in Min. Turn Radius without Brakes 8.2 ft (with brake applied) 8.2 ft Height to Top of ROPS 91.7 in 89.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 106.3 in (without 3-point hitch) 100.7 in (without 3-point hitch) ▶ WeightTractor Weight (Base) 2,623 lb 2,606 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R4 Industrial Industrial (R4): 23x8.5-14 R4 front, 12.4-16 R4 rear; turf 24x8.50-14 front, 13.6-16 rear R1 Agricultural - Front 7.2-16 Not Published R1 Agricultural - Rear 11.2-24 Not Published R3 Turf - Front Not Published 24x8.50-14 R3 Turf - Rear Not Published 13.6-16 R4 Industrial - Front 27X8.50-15 23x8.50-14 R4 R4 Industrial - Rear 15-19.5 12.4-16 R4 ▶ Loader & AttachmentsQuick Attach Loader System Front Loader (LA525 - 2 Lever Quick Coupler) TL500: 2-lever quick coupler standard Loader Model LA525 TL500 Loader Lift Height 94.3 in (at pivot pin) TL500: 94.5 in (at pivot pin) Loader Lift Capacity (Full Height) 1,082 lb (at pivot pin) TL500: 1,301 lb (at pivot pin) Loader Breakout Force 2,373 lbf (at pivot pin) TL500: 2,343 lbf (at pivot pin) ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
