▶ EnginePTO Power 20.5 hp 17.7 hp Alternator 40 A, 12 V 40 A, 12 V Air Cleaner Not Published Sheet net and replaceable treated paper element, spin on oil filter Engine Type Direct injection, vertical, water-cooled, 4-cycle, diesel Liquid-cooled, 4-cycle diesel Fuel System Direct injection Diesel fuel No.2 [above -10 ℃ (14 ℉)] Diesel fuel No.1 [below -10 ℃ (14 ℉)] Displacement 100.5 in³ 54.8 in³ No. of Cylinders 3 3 Rated Engine Speed 2200 rpm 3200 rpm Cooling System Type Water-cooled Liquid-cooled Engine Manufacturer Kubota KUBOTA Engine Power (Gross) 24.8 hp 23 hp Engine Emissions Constraints Tier 4 Not Published ▶ WeightWeight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Applicable Not Applicable Tractor Weight (Base) — 1,598.3 lb (1600 lbs.) ▶ WarrantyWarranty Length & Coverage Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours. ▶ HydraulicsPump Type Not Published Hydrostatic transmission Steering Flow 3.13 gpm 1.0 gpm Implement Flow 5.15 gpm 6.2 gpm (23.5 l/min.) Total Hydraulic Flow 8.28 gpm 6.2 gpm Hydraulic System Type Not Published Open center tandem pump gear type Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 8.28 gpm 6.2 gpm No. of Optional Remote Valves Not Published 2 (optional; ISO 7241-1 series A or B) No. of Standard Remote Valves Not Published 2 valves System Operating Pressure — 12.3 MPa to 12.8 MPa ▶ PTO & HitchPTO Rear 540 rpm STD 540 rpm PTO Type DT (2WD), DT (4WD): Transmission driven with overrunning clutch; HST (4WD): Live-continuous running Live independent PTO (with hydraulic clutch) Lift Control Type Not Published Quarter-inching valve Hitch Lift Capacity 1918 lb 1,213 lbs. Mid-PTO Availability Not Published STD (2500rpm) Category, 3-Point Hitch Not Published SAE Category 1 Hitch Lift Capacity (at 24”) 1389 lb 680 lb ▶ Tire OptionsR3 Turf - Rear Not Applicable 26×12-12 R3 Turf - Front Not Applicable 18×8.5-10 Tire Size & Options R1 Agricultural; R4 Industrial Front Turf/Industrial: 18×8.5-10; Rear Turf/Industrial: 26×12-12; Bar tire N/A R4 Industrial - Rear DT (2WD): Not Applicable; DT (4WD), HST (4WD): 15-19.5 26×12-12 R4 Industrial - Front DT (2WD): Not Applicable; DT (4WD), HST (4WD): 27X8.50-15 18×8.5-10 R1 Agricultural - Rear 11.2-24 Not Applicable R1 Agricultural - Front DT (2WD): 5-15; DT (4WD), HST (4WD): 7.2-16 Not Applicable ▶ Fluid CapacityCoolant Capacity Not Published 0.8 gal (3.3 U.S.qts.) Crankcase Capacity Not Published 0.9 gal (3.4 U.S.qts.) Fuel Tank Capacity 10.0 gal 6.6 gal (6.6 U.S.gals.) Front Axle Fluid Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published 2.98 U.S. gals. ▶ Loader & AttachmentsLoader Lift Height 94.3 in 71.0 in Loader Breakout Force 2373 lbf 6258 N (1407 lbs) [LA340] / 5719 N (1286 lbs) [LA340S] Quick Attach Loader System Front Loader (LA526 - 2 Lever Quick Coupler (OPT)) Kubota Swift-Tach (Quick attach) Loader Lift Capacity (Full Height) 1082 lb 738.5 lb (739 lbs) [LA340] / 612.9 lb (613 lbs) [LA340S] ▶ Transmission & DrivetrainClutch DT (2WD), DT (4WD): Dry type single stage; HST (4WD): Not Applicable Dry type single plate - Main clutch 9.45" No. of Speeds DT (2WD), DT (4WD): 8 forward, 4 reverse; HST (4WD): 3-range 2 Range (Low-High) Transmission Type DT (2WD), DT (4WD): Gear shift; HST (4WD): Hydrostatic transmission (3-range) Hydrostatic transmission, High-Low gear shift (2 forward, 2 reverse) Max Travel Speed (Forward) DT (2WD), DT (4WD): 10.7 mph; HST (4WD): 11.5 mph 0 mph to 8.4 mph Max Travel Speed (Reverse) DT (2WD), DT (4WD): 3.9 mph; HST (4WD): 10.3 mph 0 mph to 6.5 mph Differential Lock & Limited Slip Options Not Published Rear differential lock standard ▶ Chassis, Steering & ControlsBrakes Wet disc type Mechanical, wet disc type Steering Integral type power steering Hydrostatic Power Steering Frame Type Not Published Two-post foldable ROPS Front Axle Type Not Published 4WD: Bevel gear front axle, non-adjustable tread spacing Drawbar Capacity Not Published Maximum tongue weight 550 lb. Front Axle Rating Not Published Not Published Seat Suspension & Adjustability Not Published Not Published ▶ Dimensions & ManeuverabilityWheelbase 63.3 in 55.1 in (55.1 in.) Overall Width 55.1 in 45.1 in (45.1 in.) Ground Clearance DT (2WD): 13.6 in; DT (4WD), HST (4WD): 13.4 in 5.8 in (5.83 in.) Height to Top of ROPS 91.7 in 86.2 in (86.2 in.) Height to Top of Cab Model Not Applicable Not Applicable Height to Top of ROPS (folded) Not Published Not Published Min. Turn Radius without Brakes Not Published 7.5 feet Overall Length with 3-Point Hitch DT (2WD): 110.6 in; DT (4WD), HST (4WD): 106.3 in 99.0 in. w/3-Pt., w/ Front guard Overall Length — 87 in (87.0 in.) w / Front guard (without 3P), 99 in (99.0 in.) w / Front guard (with 3P)
