▶ EngineEngine Manufacturer Kubota Kubota Engine Model D1703-M-DI-E4 D1005 Engine Type Direct injection, vertical, water-cooled, 4-cycle diesel Liquid-cooled, 4-cycle diesel No. of Cylinders 3 3 Displacement 100.47 in³ 61.1 in³ Rated Engine Speed 2200 rpm 3200 rpm Engine Power (Gross) 24.8 hp 23.3 hp PTO Power 19 hp 19.2 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Water-cooled Water with pressurized radiator, reverse air-flow design Air Cleaner Dry paper single element (dual optional) Dry element Fuel System Direct injection Direct injection Alternator 40 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Open center tandem pump, gear type Open center tandem pump gear type Implement Flow 5.15 gpm 5.2 gpm Steering Flow 3.11 gpm 1.0 gpm Total Hydraulic Flow 8.26 gpm 6.2 gpm Overall Hydraulic Pump Flow 8.26 gpm 6.2 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published None (2-valve rear remote coupler optional) No. of Optional Remote Valves Up to 3: self-canceling detent valve or float detent valve 2 (optional; ISO 7241-1 series A or B) ▶ Fluid CapacityFuel Tank Capacity 10.0 gal 6.6 gal Coolant Capacity 6.3 qt 3.5 qt Crankcase Capacity 6.0 qt 4.2 qt Transmission / Hydraulic System Capacity HST (4WD): 6.2 gal; DT (2WD): 7.1 gal; DT (4WD): 7.3 gal 3.0 gal Front Axle Fluid Capacity 6.9 qt 3.8 qt ▶ PTO & HitchPTO Type F (2WD), DT (4WD): Transmission driven with overrunning clutch; HST (4WD): Live-continuous running Live independent PTO (with hydraulic clutch) PTO Rear 540 rpm STD (540 rpm) Mid-PTO Availability No mid-PTO offered STD (2500 rpm) Category, 3-Point Hitch Category I SAE Category I Hitch Lift Capacity 1,918 lb 1,213 lb Hitch Lift Capacity (at 24”) 1,389 lb 680 lb Lift Control Type Position control Quarter-inching valve ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission (3-range) Hydrostatic transmission No. of Speeds 3-range 2 Range (Low-High) Max Travel Speed (Forward) 11.5 mph 8.4 mph Max Travel Speed (Reverse) 10.3 mph 6.5 mph Clutch Not Published None (HST) Differential Lock & Limited Slip Options Rear differential lock standard Rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post foldable ROPS Steering Integral type power steering Hydrostatic type power steering Brakes Wet disc type Mechanical, wet disc type Seat Suspension & Adjustability Suspension seat with fore/aft travel adjustment and suspension tension adjustment High-back seat with armrests; fore/aft slide and backrest-tilt adjustment Front Axle Type Bevel gear front axle, non-adjustable tread spacing 4WD: Bevel gear front axle, non-adjustable tread spacing Front Axle Rating 2,865 lb (4WD, at 43.1 in tread) Not Published Drawbar Capacity 730 lb Max. drawbar load @ hitch: 550 lb ▶ Dimensions & ManeuverabilityOverall Width 55.1 in 45.1 in Wheelbase 63.3 in 55.1 in Ground Clearance 13.4 in 6.5 in Min. Turn Radius without Brakes 8.2 ft (with brake applied) 7.5 ft Height to Top of ROPS 91.7 in 83.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 106.3 in (without 3-point hitch) 95.5 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 2,623 lb 1,521 lb (with ROPS) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 7.2-16 18X8.5-10 R1 Agricultural - Rear 11.2-24 26X12-12 R3 Turf - Front Not Published 18X8.5-10 R3 Turf - Rear Not Published 26X12-12 R4 Industrial - Front 27X8.50-15 18X8.5-10 R4 Industrial - Rear 15-19.5 26X12-12 ▶ Loader & AttachmentsQuick Attach Loader System Front Loader (LA525 - 2 Lever Quick Coupler) Swift-Tach Loader (LA344S - Two Lever Quick Attach Bucket) Loader Model LA525 LA344S (standard, quick attach); LA344 (pin-on option) Loader Lift Height 94.3 in (at pivot pin) 71.0 in (at pivot pin) Loader Lift Capacity (Full Height) 1,082 lb (at pivot pin) 739 lb (LA344 pin-on); 613 lb (LA344S quick attach) Loader Breakout Force 2,373 lbf (at pivot pin) 1,407 lbf (LA344 pin-on); 1,286 lbf (LA344S quick attach) ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours ▶ ITC Company AccessoriesAccessories that fit
