▶ EngineEngine Manufacturer Kubota Kubota Engine Model D1703-M-DI-E4 D1703-M-DI-E4 / D1703-M-DI-E4K Engine Type Direct injection, vertical, water-cooled, 4-cycle diesel Direct injection, vertical, water-cooled 4-cycle, diesel No. of Cylinders 3 3 Displacement 100.47 in³ 100.5 in³ Rated Engine Speed 2200 rpm 2200 rpm Engine Power (Gross) 24.8 hp 23.3 hp PTO Power 19 hp 18.4 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Water-cooled Water-cooled Air Cleaner Dry paper single element (dual optional) Dry type, single element Fuel System Direct injection Direct injection Alternator 40 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Open center tandem pump, gear type Not Published Implement Flow 5.15 gpm 5.2 gpm Steering Flow 3.11 gpm 3.1 gpm Total Hydraulic Flow 8.26 gpm 8.28 gpm (5.15 + 3.13, computed) Overall Hydraulic Pump Flow 8.26 gpm 8.28 gpm (5.15 + 3.13, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Up to 3: self-canceling detent valve or float detent valve Not Published ▶ Fluid CapacityFuel Tank Capacity 10.0 gal 11.1 gal Coolant Capacity 6.3 qt 6.3 qt Crankcase Capacity 6.0 qt 6.0 qt Transmission / Hydraulic System Capacity HST (4WD): 6.2 gal; DT (2WD): 7.1 gal; DT (4WD): 7.3 gal 6.9 gal Front Axle Fluid Capacity 6.9 qt 4.8 qt ▶ PTO & HitchPTO Type F (2WD), DT (4WD): Transmission driven with overrunning clutch; HST (4WD): Live-continuous running Live-independent hydraulic PTO with PTO brake, wet PTO Rear 540 rpm 540 rpm Mid-PTO Availability No mid-PTO offered Not Published Category, 3-Point Hitch Category I SAE Category I Hitch Lift Capacity 1,918 lb 1,874 lb Hitch Lift Capacity (at 24”) 1,389 lb 1,389 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission (3-range) Hydrostatic transmission (3-range) No. of Speeds 3-range 3-range Max Travel Speed (Forward) 11.5 mph 11.5 mph Max Travel Speed (Reverse) 10.3 mph 10.3 mph Clutch Not Published n/a Differential Lock & Limited Slip Options Rear differential lock standard Rear differential lock, pedal operated ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Integral type power steering Integral type power steering Brakes Wet disc type Mechanical, wet disc type Seat Suspension & Adjustability Suspension seat with fore/aft travel adjustment and suspension tension adjustment Suspension seat with fore/aft travel adjustment and suspension tension adjustment Front Axle Type Bevel gear front axle, non-adjustable tread spacing Cast-iron front axle Front Axle Rating 2,865 lb (4WD, at 43.1 in tread) Not Published Drawbar Capacity 730 lb 730 lb ▶ Dimensions & ManeuverabilityOverall Width 55.1 in 55.1 in Wheelbase 63.3 in 63.4 in Ground Clearance 13.4 in 13.4 in Min. Turn Radius without Brakes 8.2 ft (with brake applied) 8.2 ft (with brake applied) Height to Top of ROPS 91.7 in 91.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 106.3 in (without 3-point hitch) 108.5 in (without 3-point hitch) ▶ WeightTractor Weight (Base) 2,623 lb 2,833 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R4 Industrial Agricultural; Turf; Industrial R1 Agricultural - Front 7.2-16 7.2-16 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front Not Published 25X8.50-14 R3 Turf - Rear Not Published 13.6-16 R4 Industrial - Front 27X8.50-15 27X8.50-15 R4 Industrial - Rear 15-19.5 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System Front Loader (LA525 - 2 Lever Quick Coupler) Front Loader (LA526 - 2 Lever Quick Coupler (OPT)) Loader Model LA525 LA526 Loader Lift Height 94.3 in (at pivot pin) LA526: 94.8 in Loader Lift Capacity (Full Height) 1,082 lb (at pivot pin) LA526: 1,096 lb Loader Breakout Force 2,373 lbf (at pivot pin) Not Published ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours Not Published ▶ ITC Company AccessoriesAccessories that fit
