▶ EngineEngine Manufacturer Kubota Iseki Engine Model D1703-M-DI-E4 Not Published Engine Type Direct injection, vertical, water-cooled, 4-cycle diesel 3-cylinder, liquid-cooled diesel No. of Cylinders 3 3 Displacement 100.47 in³ 91.4 in³ Rated Engine Speed 2200 rpm 2600 rpm Engine Power (Gross) 24.8 hp 24.8 hp PTO Power 19 hp ROPS: 18.2 hp; CAB: 16.9 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Water-cooled Liquid cooled Air Cleaner Dry paper single element (dual optional) Not Published Fuel System Direct injection Not Published Alternator 40 A, 12 V Not Published ▶ HydraulicsPump Type Open center tandem pump, gear type Not Published Implement Flow 5.15 gpm 5.5 gpm Steering Flow 3.11 gpm 3.2 gpm Total Hydraulic Flow 8.26 gpm 8.7 gpm (5.5 + 3.2, computed) Overall Hydraulic Pump Flow 8.26 gpm 8.7 gpm (5.5 + 3.2, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Up to 3: self-canceling detent valve or float detent valve Not Published ▶ Fluid CapacityFuel Tank Capacity 10.0 gal 7.4 gal Coolant Capacity 6.3 qt Not Published Crankcase Capacity 6.0 qt Not Published Transmission / Hydraulic System Capacity HST (4WD): 6.2 gal; DT (2WD): 7.1 gal; DT (4WD): 7.3 gal Not Published Front Axle Fluid Capacity 6.9 qt Not Published ▶ PTO & HitchPTO Type F (2WD), DT (4WD): Transmission driven with overrunning clutch; HST (4WD): Live-continuous running Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability No mid-PTO offered Independent, 2000 rpm (optional) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,918 lb 1,433 lb Hitch Lift Capacity (at 24”) 1,389 lb 1,091 lb Lift Control Type Position control Not Published ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission (3-range) Hydrostatic No. of Speeds 3-range Infinite forward and reverse (3-range) Max Travel Speed (Forward) 11.5 mph Not Published Max Travel Speed (Reverse) 10.3 mph Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Rear differential lock standard Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Integral type power steering Power steering Brakes Wet disc type Not Published Seat Suspension & Adjustability Suspension seat with fore/aft travel adjustment and suspension tension adjustment Not Published Front Axle Type Bevel gear front axle, non-adjustable tread spacing Not Published Front Axle Rating 2,865 lb (4WD, at 43.1 in tread) Not Published Drawbar Capacity 730 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 55.1 in 45.7-52 in Wheelbase 63.3 in Not Published Ground Clearance 13.4 in 9.9-11 in Min. Turn Radius without Brakes 8.2 ft (with brake applied) Not Published Height to Top of ROPS 91.7 in 95.3-97.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 80-82.1 in Overall Length 106.3 in (without 3-point hitch) 116 in ▶ WeightTractor Weight (Base) 2,623 lb ROPS: 2,044 lb; Cab: 2,169 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R4 Industrial Not Published R1 Agricultural - Front 7.2-16 Not Published R1 Agricultural - Rear 11.2-24 Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 27X8.50-15 Not Published R4 Industrial - Rear 15-19.5 Not Published ▶ Loader & AttachmentsQuick Attach Loader System Front Loader (LA525 - 2 Lever Quick Coupler) Skid Steer Loader Model LA525 FL.2106 Loader Lift Height 94.3 in (at pivot pin) FL.2106: 83 in Loader Lift Capacity (Full Height) 1,082 lb (at pivot pin) FL.2106: 1,222 lb Loader Breakout Force 2,373 lbf (at pivot pin) FL.2106: 1,822 lb ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
