▶ EngineEngine Manufacturer Kubota Yanmar Engine Model D1703-M-DI-E4 / D1703-M-DI-E4K 3TNE74 Engine Type Direct injection, vertical, water-cooled 4-cycle, diesel 3-cylinder liquid-cooled diesel, indirect injection No. of Cylinders 3 3 Displacement 100.5 in³ 61.4 in³ Rated Engine Speed 2200 rpm 3000 rpm Engine Power (Gross) 23.3 hp 23 hp PTO Power 18.4 hp 17.7 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dry type, single element Dry type with safety element Fuel System Direct injection Indirect injection, in-line fuel pump with solenoid shutoff Alternator 40 A, 12 V 20 A ▶ HydraulicsPump Type Not Published Not Published Implement Flow 5.2 gpm 3 gpm Steering Flow 3.1 gpm 2.5 gpm Total Hydraulic Flow 8.28 gpm (5.15 + 3.13, computed) 5.5 gpm Overall Hydraulic Pump Flow 8.28 gpm (5.15 + 3.13, computed) 5.5 gpm Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 11.1 gal 5.0 gal Coolant Capacity 6.3 qt 3.2 qt Crankcase Capacity 6.0 qt 2.2 qt Transmission / Hydraulic System Capacity 6.9 gal 3.4 gal Front Axle Fluid Capacity 4.8 qt 2.6 qt ▶ PTO & HitchPTO Type Live-independent hydraulic PTO with PTO brake, wet Independent, wet disk clutch PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Standard, 2100 rpm Category, 3-Point Hitch SAE Category I Category 1 Hitch Lift Capacity 1,874 lb Not Published Hitch Lift Capacity (at 24”) 1,389 lb 701 lb Lift Control Type Position control Not Published ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission (3-range) 2-range hydrostatic No. of Speeds 3-range Infinite forward and reverse, 2 ranges Max Travel Speed (Forward) 11.5 mph 8.4 mph Max Travel Speed (Reverse) 10.3 mph 6.3 mph Clutch n/a Not Published Differential Lock & Limited Slip Options Rear differential lock, pedal operated Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post fixed ROPS; four-wheel drive Steering Integral type power steering Power steering Brakes Mechanical, wet disc type Wet disk Seat Suspension & Adjustability Suspension seat with fore/aft travel adjustment and suspension tension adjustment Not Published Front Axle Type Cast-iron front axle MFWD, standard, all ranges, on-the-go engagement Front Axle Rating Not Published 3,120 lb Drawbar Capacity 730 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 55.1 in 47.2 in Wheelbase 63.4 in 57.1 in Ground Clearance 13.4 in 7.7 in (front axle) Min. Turn Radius without Brakes 8.2 ft (with brake applied) 88.6 in (MFWD off) Height to Top of ROPS 91.7 in 77.6 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 108.5 in (without 3-point hitch) 104.3 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 2,833 lb 1,400 lb (with all fluids) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural; Turf; Industrial 18x8.5-10 front and 26x12.00-12 rear; R1 standard, R3 optional R1 Agricultural - Front 7.2-16 18x8.5-10 R1 Agricultural - Rear 11.2-24 26x12.00-12 R3 Turf - Front 25X8.50-14 18x8.5-10 R3 Turf - Rear 13.6-16 26x12.00-12 R4 Industrial - Front 27X8.50-15 18x8.50-10 R4 Industrial - Rear 15-19.5 26x12.00-12 ▶ Loader & AttachmentsQuick Attach Loader System Front Loader (LA526 - 2 Lever Quick Coupler (OPT)) Not Published Loader Model LA526 210 Loader Lift Height LA526: 94.8 in 210: 68.5 in (at pivot pin) Loader Lift Capacity (Full Height) LA526: 1,096 lb 210: 622 lb (to max height at pivot point) Loader Breakout Force Not Published 210: 1,577 lbf (at pivot point) ▶ WarrantyWarranty Length & Coverage Not Published Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
