▶ EngineEngine Manufacturer Kubota Kubota Engine Model D1703-M-DI-E4 / D1703-M-DI-E4K D1105-E4-TLB-1 Engine Type Direct injection, vertical, water-cooled 4-cycle, diesel 3-cylinder, indirect injection, liquid-cooled diesel No. of Cylinders 3 3 Displacement 100.5 in³ 68.5 in³ Rated Engine Speed 2200 rpm 2800 rpm Engine Power (Gross) 23.3 hp 23.3 hp PTO Power 18.4 hp 19.4 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dry type, single element Single element Fuel System Direct injection Indirect injection Alternator 40 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Not Published Not Published Implement Flow 5.2 gpm 7.0 gpm Steering Flow 3.1 gpm 4.2 gpm Total Hydraulic Flow 8.28 gpm (5.15 + 3.13, computed) 11.1 gpm Overall Hydraulic Pump Flow 8.28 gpm (5.15 + 3.13, computed) 11.1 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Up to 3 ▶ Fluid CapacityFuel Tank Capacity 11.1 gal 8.1 gal Coolant Capacity 6.3 qt 4.7 qt Crankcase Capacity 6.0 qt 3.2 qt Transmission / Hydraulic System Capacity 6.9 gal 6.9 gal Front Axle Fluid Capacity 4.8 qt 5.0 qt ▶ PTO & HitchPTO Type Live-independent hydraulic PTO with PTO brake, wet Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch SAE Category I Category I (optional) Hitch Lift Capacity 1,874 lb 2,139 lb Hitch Lift Capacity (at 24”) 1,389 lb 1,676 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission (3-range) HST Plus hydrostatic transmission, 3-range No. of Speeds 3-range 3-range (infinite) Max Travel Speed (Forward) 11.5 mph 11.1 mph Max Travel Speed (Reverse) 10.3 mph 9.8 mph Clutch n/a Not Published Differential Lock & Limited Slip Options Rear differential lock, pedal operated Rear axle differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Four-post ROPS/FOPS standard Steering Integral type power steering Hydrostatic power steering Brakes Mechanical, wet disc type Wet disc Seat Suspension & Adjustability Suspension seat with fore/aft travel adjustment and suspension tension adjustment Reversible seat; tilt steering standard Front Axle Type Cast-iron front axle Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 730 lb 1,100 lb ▶ Dimensions & ManeuverabilityOverall Width 55.1 in 53.7 in Wheelbase 63.4 in 62.2 in Ground Clearance 13.4 in 13.8 in Min. Turn Radius without Brakes 8.2 ft (with brake applied) 8.2 ft Height to Top of ROPS 91.7 in 89.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 108.5 in (without 3-point hitch) 100.7 in (without 3-point hitch) ▶ WeightTractor Weight (Base) 2,833 lb 2,606 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural; Turf; Industrial Industrial (R4): 23x8.5-14 R4 front, 12.4-16 R4 rear; turf 24x8.50-14 front, 13.6-16 rear R1 Agricultural - Front 7.2-16 Not Published R1 Agricultural - Rear 11.2-24 Not Published R3 Turf - Front 25X8.50-14 24x8.50-14 R3 Turf - Rear 13.6-16 13.6-16 R4 Industrial - Front 27X8.50-15 23x8.50-14 R4 R4 Industrial - Rear 15-19.5 12.4-16 R4 ▶ Loader & AttachmentsQuick Attach Loader System Front Loader (LA526 - 2 Lever Quick Coupler (OPT)) TL500: 2-lever quick coupler standard Loader Model LA526 TL500 Loader Lift Height LA526: 94.8 in TL500: 94.5 in (at pivot pin) Loader Lift Capacity (Full Height) LA526: 1,096 lb TL500: 1,301 lb (at pivot pin) Loader Breakout Force Not Published TL500: 2,343 lbf (at pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
