▶ EngineEngine Manufacturer Kubota Kubota Engine Model D1703-M-DI-E4 / D1703-M-DI-E4K D902 Engine Type Direct injection, vertical, water-cooled 4-cycle, diesel Liquid-cooled, 3-cylinder diesel No. of Cylinders 3 3 Displacement 100.5 in³ 54.8 in³ Rated Engine Speed 2200 rpm 3200 rpm Engine Power (Gross) 23.3 hp 23 hp PTO Power 18.4 hp 17.7 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dry type, single element Not Published Fuel System Direct injection Not Published Alternator 40 A, 12 V Not Published ▶ HydraulicsPump Type Not Published Not Published Implement Flow 5.2 gpm Not Published Steering Flow 3.1 gpm Not Published Total Hydraulic Flow 8.28 gpm (5.15 + 3.13, computed) Not Published Overall Hydraulic Pump Flow 8.28 gpm (5.15 + 3.13, computed) 6.2 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 11.1 gal 6.6 gal Coolant Capacity 6.3 qt 2.8 qt Crankcase Capacity 6.0 qt 3.3 qt Transmission / Hydraulic System Capacity 6.9 gal Not Published Front Axle Fluid Capacity 4.8 qt Not Published ▶ PTO & HitchPTO Type Live-independent hydraulic PTO with PTO brake, wet Live independent, wet hydraulic clutch PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Standard mid-PTO, 2500 rpm Category, 3-Point Hitch SAE Category I Category I (optional) Hitch Lift Capacity 1,874 lb Not Published Hitch Lift Capacity (at 24”) 1,389 lb 680 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission (3-range) Not Published No. of Speeds 3-range Not Published Max Travel Speed (Forward) 11.5 mph Not Published Max Travel Speed (Reverse) 10.3 mph Not Published Clutch n/a Not Published Differential Lock & Limited Slip Options Rear differential lock, pedal operated Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Foldable ROPS Steering Integral type power steering Hydrostatic power steering Brakes Mechanical, wet disc type Wet disc Seat Suspension & Adjustability Suspension seat with fore/aft travel adjustment and suspension tension adjustment Not Published Front Axle Type Cast-iron front axle Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 730 lb 551 lb ▶ Dimensions & ManeuverabilityOverall Width 55.1 in 44.5 in (with turf tires) Wheelbase 63.4 in 55.1 in Ground Clearance 13.4 in 8.7 in (front axle) Min. Turn Radius without Brakes 8.2 ft (with brake applied) Not Published Height to Top of ROPS 91.7 in 87.2 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 108.5 in (without 3-point hitch) 95.5 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 2,833 lb 1,587 lb Weight with ROPS and Loader Not Published 2,475 lb Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural; Turf; Industrial 18x8.5-10 front, 26x12-12 rear (Turf/Industrial) R1 Agricultural - Front 7.2-16 Not Published R1 Agricultural - Rear 11.2-24 Not Published R3 Turf - Front 25X8.50-14 Not Published R3 Turf - Rear 13.6-16 Not Published R4 Industrial - Front 27X8.50-15 18x8.5-10 R4 Industrial - Rear 15-19.5 26x12-12 ▶ Loader & AttachmentsQuick Attach Loader System Front Loader (LA526 - 2 Lever Quick Coupler (OPT)) LA240A loader (4-point mounting, no tools required) Loader Model LA526 LA240A Loader Lift Height LA526: 94.8 in LA240A: 71.3 in (at pivot pin) Loader Lift Capacity (Full Height) LA526: 1,096 lb LA240A: 745 lb (at pivot pin, max. height) Loader Breakout Force Not Published LA240A: 992 lbf ▶ WarrantyWarranty Length & Coverage Not Published Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
