▶ EngineEngine Manufacturer Kubota Kubota Engine Model D1703-M-DI-E4 / D1703-M-DI-E4K D1005 Engine Type Direct injection, vertical, water-cooled 4-cycle, diesel Liquid-cooled, 4-cycle diesel No. of Cylinders 3 3 Displacement 100.5 in³ 61.1 in³ Rated Engine Speed 2200 rpm 3200 rpm Engine Power (Gross) 23.3 hp 23.3 hp PTO Power 18.4 hp 19.2 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Water-cooled Water with pressurized radiator, reverse air-flow design Air Cleaner Dry type, single element Dry element Fuel System Direct injection Direct injection Alternator 40 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Not Published Open center tandem pump gear type Implement Flow 5.2 gpm 5.2 gpm Steering Flow 3.1 gpm 1.0 gpm Total Hydraulic Flow 8.28 gpm (5.15 + 3.13, computed) 6.2 gpm Overall Hydraulic Pump Flow 8.28 gpm (5.15 + 3.13, computed) 6.2 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published None (2-valve rear remote coupler optional) No. of Optional Remote Valves Not Published 2 (optional; ISO 7241-1 series A or B) ▶ Fluid CapacityFuel Tank Capacity 11.1 gal 6.6 gal Coolant Capacity 6.3 qt 3.5 qt Crankcase Capacity 6.0 qt 4.2 qt Transmission / Hydraulic System Capacity 6.9 gal 3.0 gal Front Axle Fluid Capacity 4.8 qt 3.8 qt ▶ PTO & HitchPTO Type Live-independent hydraulic PTO with PTO brake, wet Live independent PTO (with hydraulic clutch) PTO Rear 540 rpm STD (540 rpm) Mid-PTO Availability Not Published STD (2500 rpm) Category, 3-Point Hitch SAE Category I SAE Category I Hitch Lift Capacity 1,874 lb 1,213 lb Hitch Lift Capacity (at 24”) 1,389 lb 680 lb Lift Control Type Position control Quarter-inching valve ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission (3-range) Hydrostatic transmission No. of Speeds 3-range 2 Range (Low-High) Max Travel Speed (Forward) 11.5 mph 8.4 mph Max Travel Speed (Reverse) 10.3 mph 6.5 mph Clutch n/a None (HST) Differential Lock & Limited Slip Options Rear differential lock, pedal operated Rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post foldable ROPS Steering Integral type power steering Hydrostatic type power steering Brakes Mechanical, wet disc type Mechanical, wet disc type Seat Suspension & Adjustability Suspension seat with fore/aft travel adjustment and suspension tension adjustment High-back seat with armrests; fore/aft slide and backrest-tilt adjustment Front Axle Type Cast-iron front axle 4WD: Bevel gear front axle, non-adjustable tread spacing Front Axle Rating Not Published Not Published Drawbar Capacity 730 lb Max. drawbar load @ hitch: 550 lb ▶ Dimensions & ManeuverabilityOverall Width 55.1 in 45.1 in Wheelbase 63.4 in 55.1 in Ground Clearance 13.4 in 6.5 in Min. Turn Radius without Brakes 8.2 ft (with brake applied) 7.5 ft Height to Top of ROPS 91.7 in 83.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 108.5 in (without 3-point hitch) 95.5 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 2,833 lb 1,521 lb (with ROPS) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural; Turf; Industrial R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 7.2-16 18X8.5-10 R1 Agricultural - Rear 11.2-24 26X12-12 R3 Turf - Front 25X8.50-14 18X8.5-10 R3 Turf - Rear 13.6-16 26X12-12 R4 Industrial - Front 27X8.50-15 18X8.5-10 R4 Industrial - Rear 15-19.5 26X12-12 ▶ Loader & AttachmentsQuick Attach Loader System Front Loader (LA526 - 2 Lever Quick Coupler (OPT)) Swift-Tach Loader (LA344S - Two Lever Quick Attach Bucket) Loader Model LA526 LA344S (standard, quick attach); LA344 (pin-on option) Loader Lift Height LA526: 94.8 in 71.0 in (at pivot pin) Loader Lift Capacity (Full Height) LA526: 1,096 lb 739 lb (LA344 pin-on); 613 lb (LA344S quick attach) Loader Breakout Force Not Published 1,407 lbf (LA344 pin-on); 1,286 lbf (LA344S quick attach) ▶ WarrantyWarranty Length & Coverage Not Published Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours ▶ ITC Company AccessoriesAccessories that fit
