▶ EngineEngine Manufacturer Kubota Kubota Engine Model D1703-M-DI-E4 / D1703-M-DI-E4K D1703-M-DI-E4 Engine Type Direct injection, vertical, water-cooled 4-cycle, diesel Direct injection, vertical, water-cooled, 4-cycle diesel No. of Cylinders 3 3 Displacement 100.5 in³ 100.47 in³ Rated Engine Speed 2200 rpm 2200 rpm Engine Power (Gross) 23.3 hp 24.8 hp PTO Power 18.4 hp 19 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Water-cooled Water-cooled Air Cleaner Dry type, single element Dry paper single element (dual optional) Fuel System Direct injection Direct injection Alternator 40 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Not Published Open center tandem pump, gear type Implement Flow 5.2 gpm 5.15 gpm Steering Flow 3.1 gpm 3.11 gpm Total Hydraulic Flow 8.28 gpm (5.15 + 3.13, computed) 8.26 gpm Overall Hydraulic Pump Flow 8.28 gpm (5.15 + 3.13, computed) 8.26 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Up to 3: self-canceling detent valve or float detent valve ▶ Fluid CapacityFuel Tank Capacity 11.1 gal 10.0 gal Coolant Capacity 6.3 qt 6.3 qt Crankcase Capacity 6.0 qt 6.0 qt Transmission / Hydraulic System Capacity 6.9 gal HST (4WD): 6.2 gal; DT (2WD): 7.1 gal; DT (4WD): 7.3 gal Front Axle Fluid Capacity 4.8 qt 6.9 qt ▶ PTO & HitchPTO Type Live-independent hydraulic PTO with PTO brake, wet F (2WD), DT (4WD): Transmission driven with overrunning clutch; HST (4WD): Live-continuous running PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published No mid-PTO offered Category, 3-Point Hitch SAE Category I Category I Hitch Lift Capacity 1,874 lb 1,918 lb Hitch Lift Capacity (at 24”) 1,389 lb 1,389 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission (3-range) Hydrostatic transmission (3-range) No. of Speeds 3-range 3-range Max Travel Speed (Forward) 11.5 mph 11.5 mph Max Travel Speed (Reverse) 10.3 mph 10.3 mph Clutch n/a Not Published Differential Lock & Limited Slip Options Rear differential lock, pedal operated Rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Integral type power steering Integral type power steering Brakes Mechanical, wet disc type Wet disc type Seat Suspension & Adjustability Suspension seat with fore/aft travel adjustment and suspension tension adjustment Suspension seat with fore/aft travel adjustment and suspension tension adjustment Front Axle Type Cast-iron front axle Bevel gear front axle, non-adjustable tread spacing Front Axle Rating Not Published 2,865 lb (4WD, at 43.1 in tread) Drawbar Capacity 730 lb 730 lb ▶ Dimensions & ManeuverabilityOverall Width 55.1 in 55.1 in Wheelbase 63.4 in 63.3 in Ground Clearance 13.4 in 13.4 in Min. Turn Radius without Brakes 8.2 ft (with brake applied) 8.2 ft (with brake applied) Height to Top of ROPS 91.7 in 91.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 108.5 in (without 3-point hitch) 106.3 in (without 3-point hitch) ▶ WeightTractor Weight (Base) 2,833 lb 2,623 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural; Turf; Industrial R1 Agricultural; R4 Industrial R1 Agricultural - Front 7.2-16 7.2-16 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front 25X8.50-14 Not Published R3 Turf - Rear 13.6-16 Not Published R4 Industrial - Front 27X8.50-15 27X8.50-15 R4 Industrial - Rear 15-19.5 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System Front Loader (LA526 - 2 Lever Quick Coupler (OPT)) Front Loader (LA525 - 2 Lever Quick Coupler) Loader Model LA526 LA525 Loader Lift Height LA526: 94.8 in 94.3 in (at pivot pin) Loader Lift Capacity (Full Height) LA526: 1,096 lb 1,082 lb (at pivot pin) Loader Breakout Force Not Published 2,373 lbf (at pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours ▶ ITC Company AccessoriesAccessories that fit
