▶ EngineEngine Manufacturer Kubota Kubota Kubota Kubota Engine Model D1703-M-DI-E4 / D1703-M-DI-E4K V2403-CR-E5 V1505-CR-TE5-D40R5 V1505-CR-TE5-D40R4 Engine Type Direct injection, vertical, water-cooled 4-cycle, diesel Direct injection, vertical, water-cooled 4-cycle, diesel Turbocharged, direct injection, liquid-cooled diesel Turbocharged, direct injection, liquid-cooled diesel No. of Cylinders 3 4 4 4 Displacement 100.5 in³ 148.5 in³ 91.4 in³ 91.4 in³ Rated Engine Speed 2200 rpm 2600 rpm 2700 rpm 2700 rpm Engine Power (Gross) 23.3 hp 48.4 hp 34.9 hp 39.8 hp PTO Power 18.4 hp 39 hp 28.7 hp 32.6 hp Engine Emissions Constraints Not Published Not Published Not Published Not Published Cooling System Type Water-cooled Water-cooled Pressurized radiator Pressurized radiator Air Cleaner Dry type, single element Dry type, primary and secondary element 6 in paper filter (with dual element) 6 in paper filter (with dual element) Fuel System Direct injection Direct injection Direct injection Direct injection Alternator 40 A, 12 V 45 A, 12 V Not Published Not Published ▶ HydraulicsPump Type Not Published Not Published Dual pump Dual pump Implement Flow 5.2 gpm 7.8 gpm 5.4 gpm 5.4 gpm Steering Flow 3.1 gpm 4.7 gpm 4.1 gpm 4.1 gpm Total Hydraulic Flow 8.28 gpm (5.15 + 3.13, computed) 12.5 gpm (7.8 + 4.7, computed) 9.5 gpm 9.5 gpm Overall Hydraulic Pump Flow 8.28 gpm (5.15 + 3.13, computed) 12.5 gpm (7.8 + 4.7, computed) 9.5 gpm 9.5 gpm Hydraulic System Type Open center Open center Open center Open center Rear Remote Hydraulic Flow Not Published Not Published Not Published Not Published No. of Standard Remote Valves Not Published Not Published None None No. of Optional Remote Valves Not Published Optional: double-acting valve, or double-acting valve with float position (float valve as second segment only) Optional, up to 2 Optional, up to 2 ▶ Fluid CapacityFuel Tank Capacity 11.1 gal 13.5 gal 8.5 gal 8.5 gal Coolant Capacity 6.3 qt 6.9 qt 4.5 qt 4.5 qt Crankcase Capacity 6.0 qt 8.7 qt 5.0 qt 5.0 qt Transmission / Hydraulic System Capacity 6.9 gal 10.6 gal 5.5 gal 5.5 gal Front Axle Fluid Capacity 4.8 qt 6.9 qt 4.8 qt 4.8 qt ▶ PTO & HitchPTO Type Live-independent hydraulic PTO with PTO brake, wet Live independent PTO with hydraulic clutch Independent Independent PTO Rear 540 rpm 540 rpm 540 rpm 540 rpm Mid-PTO Availability Not Published Not Published 2460 rpm 2460 rpm Category, 3-Point Hitch SAE Category I SAE Category I Category I Category I Hitch Lift Capacity 1,874 lb 2,870 lb 2,535 lb 2,535 lb Hitch Lift Capacity (at 24”) 1,389 lb 2,320 lb 1,962 lb 1,962 lb Lift Control Type Position control Position control Position control valve Position control valve ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission (3-range) Hydrostatic transmission (3-range) HST (3 ranges) Hydrostatic transmission No. of Speeds 3-range 3-range HST (3 ranges) 3 ranges Max Travel Speed (Forward) 11.5 mph 15.8 mph 17.0 mph 17.0 mph Max Travel Speed (Reverse) 10.3 mph 14.2 mph 13.0 mph 13.0 mph Clutch n/a Not Applicable Not Applicable Not Applicable Differential Lock & Limited Slip Options Rear differential lock, pedal operated Rear differential lock, pedal operated Standard Differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Not Published Not Published Steering Integral type power steering Hydrostatic power steering Hydrostatic power steering Hydrostatic power steering Brakes Mechanical, wet disc type Mechanical, wet disc type Multi-plate wet disk Multi-plate wet disk Seat Suspension & Adjustability Suspension seat with fore/aft travel adjustment and suspension tension adjustment Suspension seat with fore/aft travel adjustment and suspension tension adjustment Deluxe suspension seat (high back, designed to absorb shock) Seat Type: Deluxe; Seat Suspension: Adjustable Front Axle Type Cast-iron front axle Cast-iron front axle Not Published Not Published Front Axle Rating Not Published Not Published Not Published Not Published Drawbar Capacity 730 lb 1,430 lb 1,100 lb 1,100 lb ▶ Dimensions & ManeuverabilityOverall Width 55.1 in 62.2 in 53.7 in 53.7 in Wheelbase 63.4 in 72.6 in 66.7 in 66.7 in Ground Clearance 13.4 in 15.2 in 8.9 in 8.9 in Min. Turn Radius without Brakes 8.2 ft (with brake applied) 8.5 ft (with brake applied) 7.5 ft (with brake applied) 7.5 ft (with brake applied) Height to Top of ROPS 91.7 in 91.7 in 88.2 in 88.2 in Height to Top of ROPS (folded) Not Published Not Published Not Published Not Published Height to Top of Cab Model Not Published Not Published Not Applicable Not Applicable Overall Length 108.5 in (without 3-point hitch) 120.3 in (without 3-point hitch) 116.1 in (with 3-point hitch) 116.1 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 2,833 lb 3,549 lb 2,191 lb 2,191 lb Weight with ROPS and Loader Not Published Not Published Not Published Not Published Weight with Cab and Loader Not Published Not Published Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural; Turf; Industrial Agricultural; Turf; Industrial (R4) R1 Agricultural, R3 Turf, R4 Industrial, R14 R1 Agricultural, R3 Turf, R4 Industrial, R14 R1 Agricultural - Front 7.2-16 8.3-16 180/85D12 180/85D12 R1 Agricultural - Rear 11.2-24 14.9-24 320/85D16 320/85D16 R3 Turf - Front 25X8.50-14 27X10.5-15 24x8.5-14 24X8.50-14 R3 Turf - Rear 13.6-16 44X18-20 13.6-16 13.6-16 R4 Industrial - Front 27X8.50-15 10.0-16.5 23x8.5-14, 23x8.5-12 or 25x8.5-14 23x8.5-14, 23x8.5-12 or 25x8.5-14 R4 Industrial - Rear 15-19.5 17.5L-24 12.4-16, 14-17.5 or 15-19.5 12.4-16, 14-17.5 or 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System Front Loader (LA526 - 2 Lever Quick Coupler (OPT)) LA766 2-Lever Quick Coupler LA545: 2-lever quick coupler, standard; Swift-Tach, optional LA545: 2-lever quick coupler, standard; Swift-Tach, optional Loader Model LA526 LA766 LA545 LA545 Loader Lift Height LA526: 94.8 in 105.2 in (at pivot pin) 87.6 in (at pivot pin) 87.6 in (at pivot pin) Loader Lift Capacity (Full Height) LA526: 1,096 lb 1,676 lb (at pivot pin, max. height) 1,100 lb (at pivot pin) 1,100 lb (at pivot pin) Loader Breakout Force Not Published Not Published Not Published Not Published ▶ WarrantyWarranty Length & Coverage Not Published Basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: powertrain 36 months or 2,000 hours Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet None tagged yet
