▶ EngineEngine Manufacturer Kubota Kubota Engine Model D1703-M-DI-E4 / D1703-M-DI-E4K D1105 Engine Type Direct injection, vertical, water-cooled 4-cycle, diesel E-TVCS, liquid cooled, 3-cylinder diesel No. of Cylinders 3 3 Displacement 100.5 in³ 68.5 in³ Rated Engine Speed 2200 rpm 2600 rpm Engine Power (Gross) 23.3 hp 21.9 hp PTO Power 18.4 hp 19.2 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Water-cooled Liquid Cooled Air Cleaner Dry type, single element Dual paper element Fuel System Direct injection Not Published Alternator 40 A, 12 V 40 A ▶ HydraulicsPump Type Not Published Dual pump Implement Flow 5.2 gpm 4.4 gpm Steering Flow 3.1 gpm 2.6 gpm Total Hydraulic Flow 8.28 gpm (5.15 + 3.13, computed) 7.0 gpm Overall Hydraulic Pump Flow 8.28 gpm (5.15 + 3.13, computed) 7.0 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 0 No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 11.1 gal 6.1 gal Coolant Capacity 6.3 qt 4.0 qt Crankcase Capacity 6.0 qt 3.3 qt Transmission / Hydraulic System Capacity 7.5 gal 3.3 gal Front Axle Fluid Capacity 4.8 qt 0.9 gal ▶ PTO & HitchPTO Type Transmission driven with overrunning clutch Transmission driven with one way clutch PTO Rear 540 rpm 540, 1000 rpm Mid-PTO Availability Not Published 2500 rpm Category, 3-Point Hitch SAE Category I Category I Hitch Lift Capacity 1874 lb 1653 lb Hitch Lift Capacity (at 24”) 1389 lb 1290 lb Lift Control Type Position control Position control valve ▶ Transmission & DrivetrainTransmission Type Constant mesh with synchronized shuttle Gear (9 Forward, 3 Reverse) No. of Speeds 8 forward, 8 reverse 9 Forward, 3 Reverse Max Travel Speed (Forward) 10.7 mph 11.7 mph Max Travel Speed (Reverse) 10.7 mph 6.0 mph Clutch Dry type single stage Dry single plate Differential Lock & Limited Slip Options Rear differential lock, pedal operated Standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Integral type power steering Integral type power steering Brakes Mechanical, wet disc type Multi-plate wet disc Seat Suspension & Adjustability Suspension seat with fore/aft travel adjustment and suspension tension adjustment Fore and aft slide adjustment (position adjust lever) Front Axle Type Cast-iron front axle Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 730 lb 660 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 108.5 in (without 3-point hitch) 93.9 in (without 3-point hitch) Overall Width 55.1 in 44.3 in Wheelbase 63.4 in 61.4 in Ground Clearance 13.4 in 12.0 in Min. Turn Radius without Brakes 8.2 ft (with brake applied) 6.9 ft (with brake applied) Height to Top of ROPS 91.7 in 83.9 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 2811 lb 1521 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial Farm (R1): 6-12 front, 9.5-16 rear; Turf (R3): 23x8.50-12 front, 33x12.5-15 rear; Industrial (R4): 23x8.50-12 front, 12-16.5 rear; R14: 23x8.50-12 front, 12-16.5 rear R1 Agricultural - Front 7.2-16 6-12 R1 Agricultural - Rear 11.2-24 9.5-16 R3 Turf - Front 25X8.50-14 23x8.50-12 R3 Turf - Rear 13.6-16 33x12.5-15 R4 Industrial - Front 27X8.50-15 23x8.50-12 R4 Industrial - Rear 15-19.5 12-16.5 ▶ Loader & AttachmentsQuick Attach Loader System Front Loader (LA526 - 2 Lever Quick Coupler (OPT)) LA435 Swift-Tach Loader; 1-lever Quick Coupler (standard); 2-Lever Quick Coupler (optional) Loader Model LA526 LA435 Loader Lift Height 94.8 in 78.5 in Loader Lift Capacity (Full Height) 1096 lb 948 lb Loader Breakout Force Not Published 2,146 lbf ▶ WarrantyWarranty Length & Coverage Not Published Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. ▶ ITC Company AccessoriesAccessories that fit
