▶ EngineEngine Manufacturer Kubota Kubota Engine Model D1703-M-DI-E4 / D1703-M-DI-E4K D1305-E4-D36R (LX2620HSD); D1305-E4-D26Q (LX2620HSDC); D1305-E4-D36R (LX2620SUHSD) Engine Type Direct injection, vertical, water-cooled 4-cycle, diesel Indirect injection, vertical, water-cooled, 4-cycle diesel No. of Cylinders 3 3 Displacement 100.5 in³ 77.0 in³ Rated Engine Speed 2200 rpm 2500 rpm Engine Power (Gross) 23.3 hp 23.3 hp PTO Power 19.8 hp 19.4 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Water-cooled Pressurized radiator Air Cleaner Dry type, single element 4.5 in paper filter with dual filter Fuel System Direct injection Indirect injection Alternator 40 A, 12 V Not Published ▶ HydraulicsPump Type Not Published Dual pump Implement Flow 5.2 gpm Not Published Steering Flow 3.1 gpm Not Published Total Hydraulic Flow 8.28 gpm (5.15 + 3.13, computed) 8.7 gpm Overall Hydraulic Pump Flow 8.28 gpm (5.15 + 3.13, computed) 8.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 11.1 gal 7.1 gal (LX2620HSD); 8.5 gal (LX2620HSDC); 7.1 gal (LX2620SUHSD) Coolant Capacity 6.3 qt 4.5 qt (LX2620HSD); 5.7 qt (LX2620HSDC); 4.5 qt (LX2620SUHSD) Crankcase Capacity 6.0 qt 4.2 qt Transmission / Hydraulic System Capacity Not Published 4.0 gal Front Axle Fluid Capacity Not Published 5.0 qt ▶ PTO & HitchPTO Type Transmission driven with overrunning clutch Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published 2500 rpm (LX2620HSD); 2500 rpm (LX2620HSDC); optional (LX2620SUHSD) Category, 3-Point Hitch SAE Category I Category I Hitch Lift Capacity Not Published 2,139 lb Hitch Lift Capacity (at 24”) 1,389 lb 1,676 lb Lift Control Type Position control Position control valve ▶ Transmission & DrivetrainTransmission Type Constant mesh with synchronized shuttle Hydrostatic transmission (HST), 3 ranges No. of Speeds 8 forward, 8 reverse 3 ranges Max Travel Speed (Forward) 10.7 mph 11.2 mph Max Travel Speed (Reverse) 10.7 mph 8.4 mph Clutch Dry type single stage Not Published Differential Lock & Limited Slip Options Rear differential lock, pedal operated Differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Integral type power steering Hydrostatic power steering Brakes Mechanical, wet disc type Multi-plate wet disc Seat Suspension & Adjustability Suspension seat with fore/aft travel adjustment and suspension tension adjustment LX2620HSD, LX2620HSDC: deluxe seat, adjustable suspension; LX2620SUHSD: standard seat, normal suspension Front Axle Type Cast-iron front axle Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 730 lb 1,100 lb ▶ Dimensions & ManeuverabilityOverall Width 55.1 in 53.7 in Wheelbase 63.8 in 65.6 in Ground Clearance 13.6 in 14.6 in Min. Turn Radius without Brakes 7.9 ft (with brake applied) 6.9 ft (with brake applied) Height to Top of ROPS 91.7 in 88.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 84.6 in Overall Length 110.6 in (without 3-point hitch) 101.8 in (LX2620HSD); 103.9 in (LX2620HSDC); 101.8 in (LX2620SUHSD) (without 3-point hitch) (all with R1 tires) ▶ WeightTractor Weight (Base) 2,601 lb 1,775 lb (LX2620HSD); 2,249 lb (LX2620HSDC); 1,775 lb (LX2620SUHSD) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural; Turf R1 Agricultural, R3 Turf, R4 Industrial (R14 hybrid also offered) R1 Agricultural - Front 5.0-15 180/85D12 R1 Agricultural - Rear 11.2-24 320/85D16 R3 Turf - Front 23X8.50-12 24x8.50-14 R3 Turf - Rear 13.6-16 13.6-16 R4 Industrial - Front Not Published 23x8.5-14, 23x8.5-12 or 25x8.5-14 R4 Industrial - Rear Not Published 12.4-16, 14-17.5 or 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System Front Loader (LA526 - 2 Lever Quick Coupler (OPT)) LA535: 2-lever quick coupler standard; Swift-tach optional Loader Model LA526 LA535 Loader Lift Height 94.8 in LA535: 84 in (at pivot pin) Loader Lift Capacity (Full Height) 1,096 lb LA535: 1,067 lb (at pivot pin) Loader Breakout Force Not Published Not Published ▶ WarrantyWarranty Length & Coverage Not Published Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
