▶ EngineEngine Manufacturer Kubota Mitsubishi Engine Model D1703-M-DI-E4 / D1703-M-DI-E4K MVL3E3 Engine Type Direct injection, vertical, water-cooled 4-cycle, diesel Four Stroke, Naturally Aspired, Indirect Injection, Water-Cooled Diesel Engine No. of Cylinders 3 3 Displacement 100.5 in³ 67.2 in³ Rated Engine Speed 2200 rpm 3000 rpm Engine Power (Gross) 23.3 hp 22.9 hp PTO Power 18.4 hp 16.8 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Water-cooled Water-Cooled Air Cleaner Dry type, single element Not Published Fuel System Direct injection Indirect Injection Alternator 40 A, 12 V 55 A, 12 V ▶ HydraulicsPump Type Not Published Not Published Implement Flow 5.2 gpm 7.6 gpm Steering Flow 3.1 gpm 3.8 gpm Total Hydraulic Flow 8.28 gpm (5.15 + 3.13, computed) 11.2 gpm Overall Hydraulic Pump Flow 8.28 gpm (5.15 + 3.13, computed) 11.2 gpm Hydraulic System Type Open center Open Center, full-live hydraulic with position control Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Single or dual ▶ Fluid CapacityFuel Tank Capacity 11.1 gal 6.6 gal Coolant Capacity 6.3 qt Not Published Crankcase Capacity 6.0 qt Not Published Transmission / Hydraulic System Capacity 7.4 gal Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Transmission driven with overrunning clutch Independent Wet Clutch PTO Rear 540 rpm 540 rpm @ 2837 rpm Mid-PTO Availability Not Published Optional; 2500 rpm @ 2837 rpm Category, 3-Point Hitch SAE Category I CAT 1 with check chains Hitch Lift Capacity 1874 lb Not Published Hitch Lift Capacity (at 24”) 1389 lb 771 lb Lift Control Type Position control Position Control ▶ Transmission & DrivetrainTransmission Type Constant mesh with synchronized shuttle HST - 2 Range No. of Speeds 8 forward, 8 reverse Infinite forward and reverse (2 ranges) Max Travel Speed (Forward) 10.7 mph 7.3 mph Max Travel Speed (Reverse) 10.7 mph Not Published Clutch Dry type single stage Not Published Differential Lock & Limited Slip Options Rear differential lock, pedal operated Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Integral type power steering Hydrostatic Power Steering Brakes Mechanical, wet disc type Single Pedal Seat Suspension & Adjustability Suspension seat with fore/aft travel adjustment and suspension tension adjustment Not Published Front Axle Type Cast-iron front axle Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 730 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 110.6 in (without 3-point hitch) 100.4 in Overall Width 55.1 in 46.3 in Wheelbase 63.8 in 55.1 in Ground Clearance 13.6 in 6.7 in Min. Turn Radius without Brakes 7.9 ft (with brake applied) 7.2 ft (with brake applied) Height to Top of ROPS 91.7 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 80.5 in ▶ WeightTractor Weight (Base) 2601 lb 1962 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published 2368 lb ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf R3 Turf, R4 Industrial R1 Agricultural - Front 5.0-15 Not Published R1 Agricultural - Rear 11.2-24 Not Published R3 Turf - Front 23X8.50-12 18x8.5-10 R3 Turf - Rear 13.6-16 26x12-12 R4 Industrial - Front Not Published 18x8.5-10 R4 Industrial - Rear Not Published 26x12-12 ▶ Loader & AttachmentsQuick Attach Loader System Front Loader (LA526 - 2 Lever Quick Coupler (OPT)) L11: Front loader skid-steer couplers for superfast hookups Loader Model LA526 L11 Loader Lift Height 94.8 in L11: 68 in Loader Lift Capacity (Full Height) 1096 lb L11: 794 lb Loader Breakout Force Not Published L11: 1433 lb ▶ WarrantyWarranty Length & Coverage Not Published 7-Year Limited Powertrain Warranty ▶ ITC Company AccessoriesAccessories that fit None tagged yet
