▶ EngineEngine Manufacturer Kubota Yanmar Engine Model F (2WD), DT (4WD): D1402-DI-A; GST (4WD): D1402-DI-AE 3TNV88C-NJT2 Engine Type Direct injection, vertical, water-cooled, 4-cycle diesel Diesel, naturally aspirated No. of Cylinders 3 3 Displacement 85.1 in³ 100.2 in³ Rated Engine Speed 2600 rpm 2500 rpm Engine Power (Gross) 29.5 hp 30.7 hp PTO Power 23.5 hp 25 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Water-cooled, pressurized radiator Water pump Air Cleaner Paper element Dry type with safety element Fuel System Direct injection High pressure common rail direct injection Alternator 35 A, 12 V 55 A, 12 V ▶ HydraulicsPump Type Not Published Implement/steering pump: tandem gear pump; hydrostatic pump: PV axial-piston pump Implement Flow 6.8 gpm 5.3 gpm Steering Flow 2.8 gpm 4.0 gpm Total Hydraulic Flow Not Published 9.3 gpm Overall Hydraulic Pump Flow Not Published 9.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Up to 3 Not Published ▶ Fluid CapacityFuel Tank Capacity 7.7 gal 7.5 gal Coolant Capacity 4.9 qt 5.2 qt Crankcase Capacity 6.0 qt 4.7 qt Transmission / Hydraulic System Capacity F (2WD), DT (4WD): 7.5 gal; GST (4WD): 7.1 gal 5.5 gal Front Axle Fluid Capacity 6.8 qt (4WD) 4 qt ▶ PTO & HitchPTO Type Overrunning clutch on single clutch tractors; live PTO with dual clutch if equipped Independent PTO Rear 540/1000 rpm 540 rpm Mid-PTO Availability Optional mid-PTO, 1080/2000 rpm (USA No. 5, Kubota 10-tooth) Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,425 lb Not Published Hitch Lift Capacity (at 24”) 1,810 lb 1,356 lb Lift Control Type Position control (draft control optional) Position control ▶ Transmission & DrivetrainTransmission Type F (2WD), DT (4WD): 8F/8R mechanical shuttle; GST (4WD): 8F/8R Glide Shift Hydrostatic (2-range) No. of Speeds 8F/8R Infinite (2-range HST) Max Travel Speed (Forward) F (2WD), DT (4WD): 13.5 mph; GST (4WD): 13.3 mph Not Published Max Travel Speed (Reverse) F (2WD), DT (4WD): 12.2 mph; GST (4WD): 11.9 mph Not Published Clutch F (2WD), DT (4WD): dry single plate or 2-plate (live PTO if equipped); GST (4WD): dry single plate Not Published Differential Lock & Limited Slip Options Rear differential lock (bevel gear differential) Not Published ▶ Chassis, Steering & ControlsFrame Type Two-post ROPS Not Published Steering F (2WD), DT (4WD): manual recirculating-ball, or integral power steering where fitted; GST (4WD): integral power steering Power steering Brakes Wet disc type Wet disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published 4WD (MFWD) Front Axle Rating Not Published 1,760 lb Drawbar Capacity 1,100 lb 880 lb (maximum vertical load) ▶ Dimensions & ManeuverabilityOverall Width 51.4 in 56.9 in (min. rear tread, standard R1 tires); 61.7 in (max. rear tread, larger R4 tires) Wheelbase 64.6 in 62.8 in Ground Clearance F (2WD): 14.6 in; DT (4WD), GST (4WD): 13.6 in 12.7 in (R4 tires) Min. Turn Radius without Brakes 7.5 ft Not Published Height to Top of ROPS 79.9 in 95.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 109.1 in (without 3-point hitch) 115.9 in (with 3-point hitch) ▶ WeightTractor Weight (Base) F (2WD): 2,250 lb; DT (4WD): 2,470 lb; GST (4WD): 2,557 lb 2,222 lb Weight with ROPS and Loader Not Published 2,972 lb Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag: 5.00-15 (2WD) or 7-16 (4WD) front, 11.2-24 rear R1 Bar, R3 Turf, R4 Industrial R1 Agricultural - Front F (2WD): 5.00-15; DT (4WD), GST (4WD): 7-16 7-14 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front Not Published 27X8.50-15 R3 Turf - Rear Not Published 41X14-20 R4 Industrial - Front Not Published 25X8.50-14 or 27X8.50-15 R4 Industrial - Rear Not Published 15-19.5 or 43x16-20 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Quick-change attachment carrier Loader Model BF400G; LA450A 300E Loader Lift Height BF400G: 93.7 in; LA450A: 95 in 84.0 in (at pivot pin) Loader Lift Capacity (Full Height) BF400G: 882 lb; LA450A: 992 lb 1,186 lb (at pivot pin) Loader Breakout Force BF400G: 1,654 lbf; LA450A: 1,863 lbf 1,704 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Basic 24 months or 2,000 hours; powertrain 72 months or 2,000 hours
