▶ EngineEngine Manufacturer Kubota Daedong Engine Model F (2WD), DT (4WD): D1402-DI-A; GST (4WD): D1402-DI-AE CK30: 3A150LWM; CK30 HST: 3A150LWH Engine Type Direct injection, vertical, water-cooled, 4-cycle diesel 3 cylinder, in-line vertical, water-cooled 4-cycle diesel No. of Cylinders 3 3 Displacement 85.1 in³ 91.5 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 29.5 hp 30 hp PTO Power 23.5 hp CK30: 23 hp; CK30 HST: 22 hp Engine Emissions Constraints Not Published Tier 2 Cooling System Type Water-cooled, pressurized radiator Water-cooled Air Cleaner Paper element Not Published Fuel System Direct injection Not Published Alternator 35 A, 12 V 50 A, 12 V ▶ HydraulicsPump Type Not Published Gear (tandem) Implement Flow 6.7 gpm Not Published Steering Flow 2.8 gpm Not Published Total Hydraulic Flow Not Published 12.7 gpm Overall Hydraulic Pump Flow Not Published 12.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 0 No. of Optional Remote Valves Up to 3 2 ▶ Fluid CapacityFuel Tank Capacity 7.7 gal 7.9 gal Coolant Capacity 4.9 qt Not Published Crankcase Capacity 6.0 qt 6.1 qt Transmission / Hydraulic System Capacity F (2WD), DT (4WD): 7.5 gal; GST (4WD): 7.1 gal CK30: 7.1 gal; CK30 HST: 7.9 gal Front Axle Fluid Capacity 6.8 qt (4WD) Not Published ▶ PTO & HitchPTO Type Continuous running (live PTO with dual clutch if equipped) Live PTO Rear 540/1000 rpm 540 rpm (1,000 rpm optional) Mid-PTO Availability Optional mid-PTO, 1080/2000 rpm (USA No. 5, Kubota 10-tooth) Optional, 2,000 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2425 lb Not Published Hitch Lift Capacity (at 24”) 1810 lb 1,764 lb Lift Control Type Position control (draft control optional) Position control ▶ Transmission & DrivetrainTransmission Type F (2WD), DT (4WD): Mechanical shuttle, 8F/8R; GST (4WD): Glide Shift Transmission, 8F/8R CK30: Synchro shuttle; CK30 HST: Hydrostatic No. of Speeds 8F/8R CK30: 8F/8R; CK30 HST: Infinite, 3 range Max Travel Speed (Forward) F (2WD), DT (4WD): 13.5 mph; GST (4WD): 13.3 mph CK30: 14.91 mph; CK30 HST: 13.07 mph Max Travel Speed (Reverse) F (2WD), DT (4WD): 12.2 mph; GST (4WD): 11.9 mph CK30: 13.14 mph; CK30 HST: 9.15 mph Clutch F (2WD), DT (4WD): Dry single plate or two plate (live PTO if equipped); GST (4WD): Dry single plate CK30: Dry dual; CK30 HST: Dry single Differential Lock & Limited Slip Options Rear differential lock (bevel gear differential) Mechanical rear differential lock (standard) ▶ Chassis, Steering & ControlsFrame Type Two-post ROPS Not Published Steering F (2WD), DT (4WD): Recirculating ball manual steering or integral power steering (if equipped); GST (4WD): Integral type power steering Hydrostatic power steering Brakes Wet disc type Wet disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published 4WD, bevel gear type Front Axle Rating Not Published Not Published Drawbar Capacity 1100 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 109.1 in (w/o 3P) (without 3-point hitch) 122.2 in Overall Width 51.4 in 54.6 in Wheelbase 64.6 in 66.1 in Ground Clearance F (2WD): 14.6 in; DT (4WD), GST (4WD): 13.6 in 13.82 in Min. Turn Radius without Brakes 7.5 ft 9.5 ft (with brake applied) Height to Top of ROPS 79.9 in 96.8 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) F (2WD): 2250 lb; DT (4WD): 2470 lb; GST (4WD): 2557 lb CK30: 3,184 lb; CK30 HST: 3,142 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag: 5.00-15 (2WD) or 7-16 (4WD) front, 11.2-24 rear Front AG 7-14 (Turf 27x8.50-15, Industrial 25x8.50-14); Rear AG 11.2-24 (Turf 41x14.00-20, Industrial 15-19.5) R1 Agricultural - Front F (2WD): 5.00-15; DT (4WD), GST (4WD): 7-16 7-14 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front Not Published 27x8.50-15 R3 Turf - Rear Not Published 41x14.00-20 R4 Industrial - Front Not Published 25x8.50-14 R4 Industrial - Rear Not Published 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model BF400G; LA450A KL130 Loader Lift Height BF400G: 93.7 in; LA450A: 95 in KL130: 92.5 in Loader Lift Capacity (Full Height) BF400G: 882 lb; LA450A: 992 lb KL130: 1,155 lb (at pivot pins, full height) Loader Breakout Force BF400G: 1654 lbf; LA450A: 1863 lbf KL130: 2,046 lb (at pivot pins) ▶ WarrantyWarranty Length & Coverage Not Published Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
