▶ EngineEngine Manufacturer Kubota TYM Engine Model F (2WD), DT (4WD): D1402-DI-A; GST (4WD): D1402-DI-AE T1700N3 Engine Type Direct injection, vertical, water-cooled, 4-cycle diesel 3-cylinder, naturally aspirated diesel No. of Cylinders 3 3 Displacement 85.1 in³ 104.5 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 29.5 hp 30 hp PTO Power 23.5 hp 25 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Water-cooled, pressurized radiator Not Published Air Cleaner Paper element Dry element Fuel System Direct injection IDI (indirect injection) Alternator 35 A, 12 V 50 A, 12 V ▶ HydraulicsPump Type Not Published Dual gear pump Implement Flow 6.7 gpm 7.7 gpm Steering Flow 2.8 gpm 4.2 gpm Total Hydraulic Flow Not Published 11.9 gpm Overall Hydraulic Pump Flow Not Published 11.9 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Loader: 2 / Rear: 0 No. of Optional Remote Valves Up to 3 Up to 4 ▶ Fluid CapacityFuel Tank Capacity 7.7 gal 7.1 gal Coolant Capacity 4.9 qt 5.3 qt Crankcase Capacity 6.0 qt 4.5 qt Transmission / Hydraulic System Capacity F (2WD), DT (4WD): 7.5 gal; GST (4WD): 7.1 gal 3015R: 9 gal; 3015H: 9.8 gal Front Axle Fluid Capacity 6.8 qt (4WD) 6.8 qt ▶ PTO & HitchPTO Type Continuous running (live PTO with dual clutch if equipped) Independent PTO Rear 540/1000 rpm 540 rpm Mid-PTO Availability Optional mid-PTO, 1080/2000 rpm (USA No. 5, Kubota 10-tooth) Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2425 lb 3,306 lb Hitch Lift Capacity (at 24”) 1810 lb 2,425 lb Lift Control Type Position control (draft control optional) Position control ▶ Transmission & DrivetrainTransmission Type F (2WD), DT (4WD): Mechanical shuttle, 8F/8R; GST (4WD): Glide Shift Transmission, 8F/8R 3015R: Synchromesh; 3015H: HST No. of Speeds 8F/8R 3015R: F12 x R12; 3015H: 3-Range Max Travel Speed (Forward) F (2WD), DT (4WD): 13.5 mph; GST (4WD): 13.3 mph 3015R: 14.4 mph; 3015H: 18.8 mph Max Travel Speed (Reverse) F (2WD), DT (4WD): 12.2 mph; GST (4WD): 11.9 mph 3015R: 14.3 mph; 3015H: 18.7 mph Clutch F (2WD), DT (4WD): Dry single plate or two plate (live PTO if equipped); GST (4WD): Dry single plate 3015R: Dry single plate; 3015H: None (HST) Differential Lock & Limited Slip Options Rear differential lock (bevel gear differential) Differential lock (standard) ▶ Chassis, Steering & ControlsFrame Type Two-post ROPS Not Published Steering F (2WD), DT (4WD): Recirculating ball manual steering or integral power steering (if equipped); GST (4WD): Integral type power steering Hydrostatic power steering Brakes Wet disc type Wet, multi-disc Seat Suspension & Adjustability Not Published Suspension seat Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 1100 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 109.1 in (w/o 3P) (without 3-point hitch) 120.9 in Overall Width 51.4 in 56.3 in Wheelbase 64.6 in 65.7 in Ground Clearance F (2WD): 14.6 in; DT (4WD), GST (4WD): 13.6 in 14.4 in Min. Turn Radius without Brakes 7.5 ft L: 124.8 in; R: 121.3 in Height to Top of ROPS 79.9 in 97.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) F (2WD): 2250 lb; DT (4WD): 2470 lb; GST (4WD): 2557 lb 3015R: 3,183 lb; 3015H: 3,163 lb Weight with ROPS and Loader Not Published HST: 4,171 lb; Gear: 4,191 lb Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag: 5.00-15 (2WD) or 7-16 (4WD) front, 11.2-24 rear R1 Agricultural 8-16 / 12.4-24; R3 Turf 27x8.5-15 / 41x14.00; R4 Industrial 10-16.5 / 420/70-24; optional R1 8.0-16 / 12.4-24 and R4 25x8.50-14 / 15x19.5 R1 Agricultural - Front F (2WD): 5.00-15; DT (4WD), GST (4WD): 7-16 8-16 R1 Agricultural - Rear 11.2-24 12.4-24 R3 Turf - Front Not Published 27x8.5-15, 6PR R3 Turf - Rear Not Published 41x14.00, 4PR R4 Industrial - Front Not Published 10-16.5, 6PR R4 Industrial - Rear Not Published 420/70-24, 6PR ▶ Loader & AttachmentsQuick Attach Loader System Not Published BL150: Quick attach assembly (lever-lock) Loader Model BF400G; LA450A BL150 Loader Lift Height BF400G: 93.7 in; LA450A: 95 in BL150: 104.9 in Loader Lift Capacity (Full Height) BF400G: 882 lb; LA450A: 992 lb BL150: 2,200 lb Loader Breakout Force BF400G: 1654 lbf; LA450A: 1863 lbf BL150: 3,422 lb ▶ WarrantyWarranty Length & Coverage Not Published 24 months or 2,000 hours bumper-to-bumper (parts and labor); 72 months or 3,000 hours powertrain (non-commercial use, 20 to 70 engine hp); 12 months on front-end loaders, backhoes and mid-mount mowers ▶ ITC Company AccessoriesAccessories that fit None tagged yet
