▶ EngineEngine Manufacturer Kubota Kubota Engine Model Not Published D1305-E3-D22 Engine Type Not Published E-TVCS, liquid-cooled, 3-cylinder diesel No. of Cylinders 3 3 Displacement 91.5 in³ 77.0 in³ Rated Engine Speed 2800 rpm 2800 rpm Engine Power (Gross) 30 hp 29 hp PTO Power F (2WD gear), DT (4WD gear): 25 hp; HST (4WD): 23.5 hp 21 hp Engine Emissions Constraints Tier 2 Not Published Cooling System Type Liquid-cooled Liquid-cooled, pressurized radiator Air Cleaner Not Published Not Published Fuel System Indirect injection (E-TVCS) Indirect injection (E-TVCS) Alternator 40 A, 12 V 14.5 A, 12 V ▶ HydraulicsPump Type Not Published Dual pump (3-point + power steering) Implement Flow 6.5 gpm 4.7 gpm Steering Flow 4.0 gpm 3.6 gpm Total Hydraulic Flow 10.5 gpm (6.5 + 4.0, computed) 8.3 gpm (4.7 + 3.6, computed) Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 1 or 2 No. of Optional Remote Valves Up to 3 Not Published ▶ Fluid CapacityFuel Tank Capacity 9.0 gal 6.9 gal (6.9 U.S. gal, all models) Coolant Capacity Not Published 4.1 qt Crankcase Capacity Not Published 3.7 qt Transmission / Hydraulic System Capacity 7.3 gal 4.0 gal Front Axle Fluid Capacity 4.8 qt Not Published ▶ PTO & HitchPTO Type F (2WD gear), DT (4WD gear): transmission-driven, live-continuous running; HST (4WD): live-continuous with overrunning clutch Live PTO Rear 540 rpm 540/960 rpm Mid-PTO Availability Not Published Optional mid-PTO, 2500 rpm (USA No. 5, Kubota 10-tooth) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1998 lb 1356 lb Hitch Lift Capacity (at 24”) 1435 lb 1058 lb Lift Control Type Position control Position control valve, quarter inching valve ▶ Transmission & DrivetrainTransmission Type Not Published Main-hydrostatic transmission, 3-range No. of Speeds F (2WD gear), DT (4WD gear): 8F/4R; HST (4WD): 3-range 3-range (3 forward, 3 reverse) Max Travel Speed (Forward) F (2WD gear), DT (4WD gear): 13.7 mph; HST (4WD): 14.7 mph 12.6 mph Max Travel Speed (Reverse) F (2WD gear), DT (4WD gear): 4.9 mph; HST (4WD): 13.2 mph 10.0 mph Clutch F (2WD gear), DT (4WD gear): dry-type single stage; HST (4WD): dry-type single stage Not Published Differential Lock & Limited Slip Options Rear differential lock standard Rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Two-post ROPS (foldable ROPS optional) Two-post foldable ROPS (sunshade optional) Steering Integral type power steering Integral type power steering Brakes Wet disc type Wet disk type Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch F (2WD gear): 110.6 in; DT (4WD gear), HST (4WD): 106.5 in (w/o 3P) (without 3-point hitch) 95.1 in (w/o 3P) (without 3-point hitch) Overall Width 51.4 in 49.0 in Wheelbase F (2WD): 63.4 in; DT (4WD), HST (4WD): 63.3 in 61.5 in Ground Clearance F (2WD gear): 13.6 in; DT (4WD gear), HST (4WD): 13.4 in 12.8 in Min. Turn Radius without Brakes F (2WD gear): 7.9 ft; DT (4WD gear), HST (4WD): 8.2 ft (w/brake) (with brake applied) 6.9 ft (w/brake) (with brake applied) Height to Top of ROPS 85.0 in 85.0 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) F (2WD gear): 2359 lb; DT (4WD gear): 2536 lb; HST (4WD): 2600 lb 1554 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options F (2WD gear): 5-15 front, 11.2-24 rear; DT (4WD gear), HST (4WD): 7-16 front, 11.2-24 rear Standard farm 7-12 front, 11.2-16 rear R1 Agricultural - Front F (2WD gear): 5-15; DT (4WD gear), HST (4WD): 7-16 7-12 R1 Agricultural - Rear 11.2-24 11.2-16 R3 Turf - Front 2WD: 23x8.50-12; 4WD: 25x8.50-14 Not Published R3 Turf - Rear 13.6-16 Not Published R4 Industrial - Front 27x8.50-15 (4WD) 23x8.50-12 R4 Industrial - Rear 15-19.5 R4 (4WD) 12-16.5 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model LA463 LA364 Loader Lift Height LA463: 95.3 in LA364: 78.6 in Loader Lift Capacity (Full Height) LA463: 1142 lb LA364: 952 lb Loader Breakout Force LA463: 1858 lbf (at 19.7 in) (19.7 in forward of pivot pin) LA364: 2144 lbf ▶ WarrantyWarranty Length & Coverage Not Published Not Published
