▶ EngineEngine Manufacturer Kubota Kubota Engine Model Not Published F (2WD), DT (4WD): D1402-DI-A; GST (4WD): D1402-DI-AE Engine Type Not Published Direct injection, vertical, water-cooled, 4-cycle diesel No. of Cylinders 3 3 Displacement 91.5 in³ 85.1 in³ Rated Engine Speed 2800 rpm 2600 rpm Engine Power (Gross) 30 hp 29.5 hp PTO Power F (2WD gear), DT (4WD gear): 25 hp; HST (4WD): 23.5 hp 23.5 hp Engine Emissions Constraints Tier 2 Not Published Cooling System Type Liquid-cooled Water-cooled, pressurized radiator Air Cleaner Not Published Paper element Fuel System Indirect injection (E-TVCS) Direct injection Alternator 40 A, 12 V 35 A, 12 V ▶ HydraulicsPump Type Not Published Not Published Implement Flow 6.5 gpm 6.7 gpm Steering Flow 4.0 gpm 2.8 gpm Total Hydraulic Flow 10.5 gpm (6.5 + 4.0, computed) Not Published Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Up to 3 Up to 3 ▶ Fluid CapacityFuel Tank Capacity 9.0 gal 7.7 gal Coolant Capacity Not Published 4.9 qt Crankcase Capacity Not Published 6.0 qt Transmission / Hydraulic System Capacity 7.3 gal F (2WD), DT (4WD): 7.5 gal; GST (4WD): 7.1 gal Front Axle Fluid Capacity 4.8 qt 6.8 qt (4WD) ▶ PTO & HitchPTO Type F (2WD gear), DT (4WD gear): transmission-driven, live-continuous running; HST (4WD): live-continuous with overrunning clutch Continuous running (live PTO with dual clutch if equipped) PTO Rear 540 rpm 540/1000 rpm Mid-PTO Availability Not Published Optional mid-PTO, 1080/2000 rpm (USA No. 5, Kubota 10-tooth) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1998 lb 2425 lb Hitch Lift Capacity (at 24”) 1435 lb 1810 lb Lift Control Type Position control Position control (draft control optional) ▶ Transmission & DrivetrainTransmission Type Not Published F (2WD), DT (4WD): Mechanical shuttle, 8F/8R; GST (4WD): Glide Shift Transmission, 8F/8R No. of Speeds F (2WD gear), DT (4WD gear): 8F/4R; HST (4WD): 3-range 8F/8R Max Travel Speed (Forward) F (2WD gear), DT (4WD gear): 13.7 mph; HST (4WD): 14.7 mph F (2WD), DT (4WD): 13.5 mph; GST (4WD): 13.3 mph Max Travel Speed (Reverse) F (2WD gear), DT (4WD gear): 4.9 mph; HST (4WD): 13.2 mph F (2WD), DT (4WD): 12.2 mph; GST (4WD): 11.9 mph Clutch F (2WD gear), DT (4WD gear): dry-type single stage; HST (4WD): dry-type single stage F (2WD), DT (4WD): Dry single plate or two plate (live PTO if equipped); GST (4WD): Dry single plate Differential Lock & Limited Slip Options Rear differential lock standard Rear differential lock (bevel gear differential) ▶ Chassis, Steering & ControlsFrame Type Two-post ROPS (foldable ROPS optional) Two-post ROPS Steering Integral type power steering F (2WD), DT (4WD): Recirculating ball manual steering or integral power steering (if equipped); GST (4WD): Integral type power steering Brakes Wet disc type Wet disc type Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1100 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch F (2WD gear): 110.6 in; DT (4WD gear), HST (4WD): 106.5 in (w/o 3P) (without 3-point hitch) 109.1 in (w/o 3P) (without 3-point hitch) Overall Width 51.4 in 51.4 in Wheelbase F (2WD): 63.4 in; DT (4WD), HST (4WD): 63.3 in 64.6 in Ground Clearance F (2WD gear): 13.6 in; DT (4WD gear), HST (4WD): 13.4 in F (2WD): 14.6 in; DT (4WD), GST (4WD): 13.6 in Min. Turn Radius without Brakes F (2WD gear): 7.9 ft; DT (4WD gear), HST (4WD): 8.2 ft (w/brake) (with brake applied) 7.5 ft Height to Top of ROPS 85.0 in 79.9 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) F (2WD gear): 2359 lb; DT (4WD gear): 2536 lb; HST (4WD): 2600 lb F (2WD): 2250 lb; DT (4WD): 2470 lb; GST (4WD): 2557 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options F (2WD gear): 5-15 front, 11.2-24 rear; DT (4WD gear), HST (4WD): 7-16 front, 11.2-24 rear Ag: 5.00-15 (2WD) or 7-16 (4WD) front, 11.2-24 rear R1 Agricultural - Front F (2WD gear): 5-15; DT (4WD gear), HST (4WD): 7-16 F (2WD): 5.00-15; DT (4WD), GST (4WD): 7-16 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front 2WD: 23x8.50-12; 4WD: 25x8.50-14 Not Published R3 Turf - Rear 13.6-16 Not Published R4 Industrial - Front 27x8.50-15 (4WD) Not Published R4 Industrial - Rear 15-19.5 R4 (4WD) Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model LA463 BF400G; LA450A Loader Lift Height LA463: 95.3 in BF400G: 93.7 in; LA450A: 95 in Loader Lift Capacity (Full Height) LA463: 1142 lb BF400G: 882 lb; LA450A: 992 lb Loader Breakout Force LA463: 1858 lbf (at 19.7 in) (19.7 in forward of pivot pin) BF400G: 1654 lbf; LA450A: 1863 lbf ▶ WarrantyWarranty Length & Coverage Not Published Not Published
