▶ EngineEngine Manufacturer Kubota Yanmar Engine Model Not Published 3TNV88-BMJT Engine Type Not Published 3-cylinder liquid-cooled diesel, direct injection No. of Cylinders 3 3 Displacement 91.5 in³ 100.1 in³ Rated Engine Speed Not Published 2600 rpm Engine Power (Gross) 32.1 hp 32.4 hp PTO Power 25.8 hp 25 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Not Published Liquid-cooled Air Cleaner Not Published Dry type with safety element Fuel System Indirect injection Direct injection, self bleeding, in-line fuel pump with electric shutoff Alternator Not Published 40 A ▶ HydraulicsPump Type Single pump (position-control) Dual tandem gear pump Implement Flow 8.3 gpm 8.6 gpm Steering Flow 4.9 gpm 5.3 gpm Total Hydraulic Flow 13.2 gpm 13.9 gpm Overall Hydraulic Pump Flow 8.3 gpm 13.9 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves 3 Not Published ▶ Fluid CapacityFuel Tank Capacity 10.6 gal 13.5 gal (open station); 11.8 gal (cab) Coolant Capacity 6.3 qt 5.6 qt (open station); 7.4 qt (cab) Crankcase Capacity 6.0 qt 5.1 qt Transmission / Hydraulic System Capacity 11.1 gal 6.8 gal (eHydro); 6.3 gal (PowrReverser) Front Axle Fluid Capacity Not Published 1.2 gal ▶ PTO & HitchPTO Type Independent, hydraulic clutch Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional mid-PTO, independent, 2000 rpm Optional, 2100 rpm Category, 3-Point Hitch Category I Category 1 Hitch Lift Capacity 3750 lb (at lift points) Not Published Hitch Lift Capacity (at 24”) 2650 lb 2200 lb Lift Control Type Position control (with optional draft control) Position control ▶ Transmission & DrivetrainTransmission Type F (2WD), DT (4WD): 8-speed fully synchronized main and shuttle (16-speed with creep option) eHydro 3-range hydrostatic (4WD); PowrReverser 12F/12R power shuttle (4WD) No. of Speeds 8F/8R (16F/16R with creep option) Infinite forward and reverse, 3 ranges (eHydro); 12 forward, 12 reverse (PowrReverser) Max Travel Speed (Forward) Not Published 19 mph (eHydro); 16.4 mph (PowrReverser) Max Travel Speed (Reverse) Not Published 19 mph (eHydro); 16.4 mph (PowrReverser) Clutch Dry type single stage Multiple stage wet disc, 4.4 in (PowrReverser) Differential Lock & Limited Slip Options Not Published Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post folding ROPS; cab optional; MFWD standard Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disk type Wet disk Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published Mechanical front wheel drive (MFWD), standard, all ranges Front Axle Rating Not Published 1587 to 3197 lb Drawbar Capacity Not Published 562 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 119.1 in (without 3P) (without 3-point hitch) 120.2 in Overall Width 56.3 in (minimum tread) 52.4 in (minimum, R1 tires); 68.4 in (maximum, R1 tires) Wheelbase 71.1 in 68 in Ground Clearance 14.6 in Not Published Min. Turn Radius without Brakes 8.9 ft (w/brake) (with brake applied) Not Published Height to Top of ROPS 88.8 in (with ROPS) 93.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 89.4 in ▶ WeightTractor Weight (Base) 3265 lb (with ROPS) 2900 lb (open station); 3570 lb (cab) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard Front: 7-16; Rear: 12.4-24 R1 bar tread, R3 turf, R4 industrial and golf tires available on all models R1 Agricultural - Front 7-16 7.00-14 R1 Agricultural - Rear 12.4-24 11.2-24 R3 Turf - Front Not Published 27x8.50-15 R3 Turf - Rear Not Published 41x14.00-20 R4 Industrial - Front Not Published 25x8.50-14 or 27x8.50-15 R4 Industrial - Rear Not Published 43x16.00-20 or 15.00-19.5 ▶ Loader & AttachmentsQuick Attach Loader System LA513 and LA723 loaders offered John Deere quick-attach (Quik-Park); skid-steer style carrier optional on 300CX Loader Model LA513; LA723 300X; 300CX; H160; H165; 300R; 320R Loader Lift Height LA513: 96.5 in; LA723: 102.4 in 300X: 90 in; 300CX: 102 in; H160: 90 in; H165: 102 in; 300R: 90 in; 320R: 102 in Loader Lift Capacity (Full Height) LA513: 1345 lb; LA723: 1870 lb 300X: 1360 lb; 300CX: 1598 lb; H160: 1360 lb; H165: 1598 lb; 300R: 1360 lb; 320R: 1598 lb (to maximum height at pivot pin) Loader Breakout Force LA513: 2160 lbf (at 19.7 in); LA723: 2605 lbf (at 19.7 in) (19.7 in forward of pivot pin) 300X: 2855 lbf; 300CX: 3327 lbf; H160: 2855 lbf; H165: 3327 lbf; 300R: 2855 lbf; 320R: 3327 lbf (at pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
