▶ EngineEngine Manufacturer Kubota Kubota Engine Model Not Published F (2WD), DT (4WD): D1402-DI-A; GST (4WD): D1402-DI-AE Engine Type Not Published Direct injection, vertical, water-cooled, 4-cycle diesel No. of Cylinders 3 3 Displacement 91.5 in³ 85.1 in³ Rated Engine Speed Not Published 2600 rpm Engine Power (Gross) 32.1 hp 29.5 hp PTO Power 25.8 hp 23.5 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Not Published Water-cooled, pressurized radiator Air Cleaner Not Published Paper element Fuel System Indirect injection Direct injection Alternator Not Published 35 A, 12 V ▶ HydraulicsPump Type Single pump (position-control) Not Published Implement Flow 8.3 gpm 6.7 gpm Steering Flow 4.9 gpm 2.8 gpm Total Hydraulic Flow 13.2 gpm Not Published Overall Hydraulic Pump Flow 8.3 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves 3 Up to 3 ▶ Fluid CapacityFuel Tank Capacity 10.6 gal 7.7 gal Coolant Capacity 6.3 qt 4.9 qt Crankcase Capacity 6.0 qt 6.0 qt Transmission / Hydraulic System Capacity 11.1 gal F (2WD), DT (4WD): 7.5 gal; GST (4WD): 7.1 gal Front Axle Fluid Capacity Not Published 6.8 qt (4WD) ▶ PTO & HitchPTO Type Independent, hydraulic clutch Continuous running (live PTO with dual clutch if equipped) PTO Rear 540 rpm 540/1000 rpm Mid-PTO Availability Optional mid-PTO, independent, 2000 rpm Optional mid-PTO, 1080/2000 rpm (USA No. 5, Kubota 10-tooth) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 3750 lb (at lift points) 2425 lb Hitch Lift Capacity (at 24”) 2650 lb 1810 lb Lift Control Type Position control (with optional draft control) Position control (draft control optional) ▶ Transmission & DrivetrainTransmission Type F (2WD), DT (4WD): 8-speed fully synchronized main and shuttle (16-speed with creep option) F (2WD), DT (4WD): Mechanical shuttle, 8F/8R; GST (4WD): Glide Shift Transmission, 8F/8R No. of Speeds 8F/8R (16F/16R with creep option) 8F/8R Max Travel Speed (Forward) Not Published F (2WD), DT (4WD): 13.5 mph; GST (4WD): 13.3 mph Max Travel Speed (Reverse) Not Published F (2WD), DT (4WD): 12.2 mph; GST (4WD): 11.9 mph Clutch Dry type single stage F (2WD), DT (4WD): Dry single plate or two plate (live PTO if equipped); GST (4WD): Dry single plate Differential Lock & Limited Slip Options Not Published Rear differential lock (bevel gear differential) ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post ROPS Steering Hydrostatic power steering F (2WD), DT (4WD): Recirculating ball manual steering or integral power steering (if equipped); GST (4WD): Integral type power steering Brakes Wet disk type Wet disc type Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1100 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 119.1 in (without 3P) (without 3-point hitch) 109.1 in (w/o 3P) (without 3-point hitch) Overall Width 56.3 in (minimum tread) 51.4 in Wheelbase 71.1 in 64.6 in Ground Clearance 14.6 in F (2WD): 14.6 in; DT (4WD), GST (4WD): 13.6 in Min. Turn Radius without Brakes 8.9 ft (w/brake) (with brake applied) 7.5 ft Height to Top of ROPS 88.8 in (with ROPS) 79.9 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 3265 lb (with ROPS) F (2WD): 2250 lb; DT (4WD): 2470 lb; GST (4WD): 2557 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard Front: 7-16; Rear: 12.4-24 Ag: 5.00-15 (2WD) or 7-16 (4WD) front, 11.2-24 rear R1 Agricultural - Front 7-16 F (2WD): 5.00-15; DT (4WD), GST (4WD): 7-16 R1 Agricultural - Rear 12.4-24 11.2-24 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System LA513 and LA723 loaders offered Not Published Loader Model LA513; LA723 BF400G; LA450A Loader Lift Height LA513: 96.5 in; LA723: 102.4 in BF400G: 93.7 in; LA450A: 95 in Loader Lift Capacity (Full Height) LA513: 1345 lb; LA723: 1870 lb BF400G: 882 lb; LA450A: 992 lb Loader Breakout Force LA513: 2160 lbf (at 19.7 in); LA723: 2605 lbf (at 19.7 in) (19.7 in forward of pivot pin) BF400G: 1654 lbf; LA450A: 1863 lbf ▶ WarrantyWarranty Length & Coverage Not Published Not Published
