▶ EngineEngine Manufacturer Kubota YANMAR Engine Model Not Published 3TNV88C-MLST Engine Type Not Published 3-cylinder, liquid-cooled, diesel, naturally aspirated, CRDI No. of Cylinders 3 3 Displacement 91.5 in³ 100.2 in³ Rated Engine Speed Not Published 2600 rpm Engine Power (Gross) 32.1 hp 31.7 hp PTO Power 25.8 hp 26.2 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Not Published Liquid-cooled Air Cleaner Not Published Dry Fuel System Indirect injection CRDI (common rail direct injection) Alternator Not Published 55 A, 12 V ▶ HydraulicsPump Type Single pump (position-control) Gear pump Implement Flow 8.3 gpm 6.7 gpm Steering Flow 4.9 gpm 5.0 gpm Total Hydraulic Flow 13.2 gpm 11.7 gpm Overall Hydraulic Pump Flow 8.3 gpm 11.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 1 pair No. of Optional Remote Valves 3 Not Published ▶ Fluid CapacityFuel Tank Capacity 10.6 gal 10.6 gal Coolant Capacity 6.3 qt Not Published Crankcase Capacity 6.0 qt Not Published Transmission / Hydraulic System Capacity 11.1 gal Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent, hydraulic clutch Independent PTO Rear 540 rpm Standard (540 rpm) Mid-PTO Availability Optional mid-PTO, independent, 2000 rpm Available (option) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 3750 lb (at lift points) 1,808 lb Hitch Lift Capacity (at 24”) 2650 lb 1433 lb Lift Control Type Position control (with optional draft control) Position control ▶ Transmission & DrivetrainTransmission Type F (2WD), DT (4WD): 8-speed fully synchronized main and shuttle (16-speed with creep option) HST No. of Speeds 8F/8R (16F/16R with creep option) 3 ranges Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Dry type single stage Not Published Differential Lock & Limited Slip Options Not Published Mechanical differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disk type Wet, multi-disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 119.1 in (without 3P) (without 3-point hitch) 125 in Overall Width 56.3 in (minimum tread) 66 in Wheelbase 71.1 in 69 in Ground Clearance 14.6 in Not Published Min. Turn Radius without Brakes 8.9 ft (w/brake) (with brake applied) 11.5 ft (3.5 m) Height to Top of ROPS 88.8 in (with ROPS) 95 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 3265 lb (with ROPS) 3,254 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Standard Front: 7-16; Rear: 12.4-24 R1 agricultural, R4 industrial, R3 turf and VT (versa turf); VT same size as R4 R1 Agricultural - Front 7-16 7-14 R1 Agricultural - Rear 12.4-24 11.2-24 R3 Turf - Front Not Published 25x8.50-14 R3 Turf - Rear Not Published 41x14.00-20 R4 Industrial - Front Not Published 27x8.50-15 R4 Industrial - Rear Not Published 43x16.00-20 ▶ Loader & AttachmentsQuick Attach Loader System LA513 and LA723 loaders offered LL3003: ISO 24410 Quick Attaching Coupler Loader Model LA513; LA723 LL3003, LL3004 Loader Lift Height LA513: 96.5 in; LA723: 102.4 in LL3003, LL3004: 94.3 in Loader Lift Capacity (Full Height) LA513: 1345 lb; LA723: 1870 lb LL3003, LL3004: 2,063 lb Loader Breakout Force LA513: 2160 lbf (at 19.7 in); LA723: 2605 lbf (at 19.7 in) (19.7 in forward of pivot pin) LL3003, LL3004: 3,723 lb ▶ WarrantyWarranty Length & Coverage Not Published 6-year limited powertrain warranty; 2-year bumper-to-bumper warranty
