▶ EngineEngine Manufacturer Kubota Yanmar Engine Model F (2WD gear), DT (4WD gear): D1803-CR-E4-LB1; HST (4WD): D1803-CR-E4-LB2 3TNV88C-MJT Engine Type Liquid-cooled, 3-cylinder, 4-cycle, multi-valve diesel, naturally aspirated, common rail direct injection Diesel, turbocharged No. of Cylinders 3 3 Displacement 111.4 in³ 97.6 in³ Rated Engine Speed 2700 rpm 2600 rpm Engine Power (Gross) 33 hp 31.8 hp PTO Power F (2WD gear), DT (4WD gear): 27.7 hp; HST (4WD): 26.2 hp 24.3 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled, water with pressurized radiator Water pump Air Cleaner Dry paper single element Dry type with safety element Fuel System Common rail (CRS) direct injection, electronic fuel injection High pressure common rail direct injection (HPCR) Alternator 40 A, 12 V 75 A, 12 V ▶ HydraulicsPump Type Open center tandem pump, gear type Implement/steering pump: Dual gear; hydrostatic pump: PV axial piston Implement Flow 6.3 gpm 8.6 gpm Steering Flow 3.8 gpm 5.9 gpm Total Hydraulic Flow 10.1 gpm 14.4 gpm Overall Hydraulic Pump Flow 10.1 gpm 14.4 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Up to 3 (self canceling detent valve or float detent valve options) Up to 6 rear remotes ▶ Fluid CapacityFuel Tank Capacity 11.1 gal Open station: 13.5 gal; Cab: 11.8 gal Coolant Capacity 6.3 qt 1.4 gal Crankcase Capacity 7.1 qt 1.1 gal Transmission / Hydraulic System Capacity F (2WD gear): 7.4 gal; DT (4WD gear): 7.5 gal; HST (4WD): 6.2 gal 6.8 gal Front Axle Fluid Capacity 4.8 qt 1.3 gal ▶ PTO & HitchPTO Type Live independent PTO with hydraulic clutch Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability No mid-PTO offered Optional (2100 rpm) Category, 3-Point Hitch Category I Limited Category I Hitch Lift Capacity 1998 lb 2530 lb at hitch ball Hitch Lift Capacity (at 24”) 1433 lb 2,194 lb at 24 in behind link arms Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type F (2WD gear), DT (4WD gear): Synchronized shuttle gear transmission, 8F/8R; HST (4WD): Hydrostatic transmission, 3-range three-range, infinitely variable No. of Speeds F (2WD gear), DT (4WD gear): 8F/8R; HST (4WD): 3-range infinite in 3 ranges Max Travel Speed (Forward) F (2WD gear), DT (4WD gear): 13.2 mph; HST (4WD): 14.1 mph 18.50 mph Max Travel Speed (Reverse) F (2WD gear), DT (4WD gear): 13.1 mph; HST (4WD): 12.7 mph 18.50 mph Clutch Dry type single stage Not Applicable Differential Lock & Limited Slip Options Rear differential lock standard Differential lock: Yes ▶ Chassis, Steering & ControlsFrame Type Two-post foldable ROPS (factory certified) with retractable seat belt Foldable ROPS; cab or open station configurations available Steering Integral power steering Hydrostatic power steering Brakes Mechanical wet disc type, pedals can be locked together Multi-plate wet disk Seat Suspension & Adjustability Not Published Standard seat: height/level/fore-aft adjustments; Deluxe seat: weight (air pressure) & fore-aft adjustments Front Axle Type F (2WD gear): Tubular steel, non-adjustable tread spacing; DT (4WD gear), HST (4WD): Bevel gear front axle, non-adjustable tread spacing Mechanical front wheel drive (MFWD) Front Axle Rating 2865 lb (at 41.3 in tread, 2WD and 4WD models) 3196 lb Drawbar Capacity 730 lb 899 lbf ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch F (2WD gear): 119.1 in; DT (4WD gear), HST (4WD): 116.3 in 120.2 in Overall Width 55.1 in 69.1 in Wheelbase 63.3 in 68.0 in Ground Clearance F (2WD gear): 13.6 in; DT (4WD gear), HST (4WD): 13.5 in 12.2 in Min. Turn Radius without Brakes F (2WD gear): 8.9 ft; DT (4WD gear), HST (4WD): 10.5 ft 8.8 ft (2.68 m, MFWD off) Height to Top of ROPS 91.7 in 93.3 in Height to Top of ROPS (folded) Not Published 72.0 in Height to Top of Cab Model Not Published 85.0 in ▶ WeightTractor Weight (Base) F (2WD gear): 2557 lb; DT (4WD gear): 2734 lb; HST (4WD): 2778 lb 2900 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural (standard); R3 Turf; R4 Industrial (4WD) R1 Bar, R3 Turf, R4 Industrial R1 Agricultural - Front F (2WD gear): 5-15 (7.5L-15 optional); DT (4WD gear), HST (4WD): 7.2-16 7-14 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front F (2WD gear): 23x8.5-12; DT (4WD gear), HST (4WD): 25x8.5-14 27X8.50-15 R3 Turf - Rear 13.6-16 41X14-20 R4 Industrial - Front 27x8.5-15 (4WD) 25X8.5-14 or 27X8.5-15 R4 Industrial - Rear 15-19.5 (4WD) 15-19.5 or 43X16-20 ▶ Loader & AttachmentsQuick Attach Loader System LA525: 2-Lever Quick Coupler, no tools required to attach and detach loader Quik-Park mounting system Loader Model LA525 H160 Loader Lift Height LA525: 94.3 in 90 in Loader Lift Capacity (Full Height) LA525: 1131 lb 1,360 lb at pivot; 999 lb @ 19.7 in ahead of pivot Loader Breakout Force LA525: 2462 lbf 2,855 lb at pivot; 2,032 lb @ 19.7 in ▶ WarrantyWarranty Length & Coverage 24 months or 1500 hours (general) 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine)
