▶ EngineEngine Manufacturer Kubota Yanmar Engine Model F (2WD gear), DT (4WD gear): D1803-CR-E4-LB1; HST (4WD): D1803-CR-E4-LB2 3TNE84 Engine Type 3-cylinder, multi-valve, naturally aspirated, common-rail, liquid-cooled diesel 3-cylinder liquid-cooled diesel, direct injection No. of Cylinders 3 3 Displacement 111.4 in³ 91.3 in³ Rated Engine Speed 2700 rpm 2700 rpm Engine Power (Gross) 33 hp 32.2 hp PTO Power F (2WD gear), DT (4WD gear): 27.7 hp; HST (4WD): 26.2 hp 27 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled, water with pressurized radiator Liquid-cooled Air Cleaner Dry paper single element Dry type with safety element Fuel System Common-rail, direct injection, electronic control Direct injection, self-bleeding in-line fuel pump, electric shutoff Alternator 40 A, 12 V 40 A ▶ HydraulicsPump Type Open center tandem pump, gear type Dual gear pump Implement Flow 6.3 gpm 8.3 gpm Steering Flow 3.8 gpm 5.0 gpm Total Hydraulic Flow 10.1 gpm 13.3 gpm Overall Hydraulic Pump Flow 10.1 gpm 13.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 2 No. of Optional Remote Valves Up to 3: self-canceling detent valve or float detent valve Not Published ▶ Fluid CapacityFuel Tank Capacity 11.1 gal 10.0 gal Coolant Capacity 6.3 qt 6.1 qt Crankcase Capacity 7.1 qt 4.5 qt Transmission / Hydraulic System Capacity F (2WD gear): 7.4 gal; DT (4WD gear): 7.5 gal; HST (4WD): 6.2 gal 6.3 gal (gear); 6.9 gal (hydrostatic) Front Axle Fluid Capacity 4.8 qt 4.7 qt ▶ PTO & HitchPTO Type F (2WD gear), DT (4WD gear): Transmission driven with overrunning clutch; HST (4WD): Live-continuous running Independent, wet disk clutch and brake PTO Rear 540 rpm 540 rpm Mid-PTO Availability No mid-PTO offered Available, 2100 rpm Category, 3-Point Hitch Category I Category 1 Hitch Lift Capacity 1,874 lb (at lift points) Not Published Hitch Lift Capacity (at 24”) 1,433 lb 2,200 lb Lift Control Type Position control Not Published ▶ Transmission & DrivetrainTransmission Type F (2WD gear), DT (4WD gear): manual transmission with synchronized shuttle; HST (4WD): hydrostatic transmission SyncShift 9F/3R gear (2WD and 4WD); SyncReverser 12F/12R (4WD only); hydrostatic 3-range (2WD and 4WD) No. of Speeds F (2WD gear), DT (4WD gear): 8F/8R; HST (4WD): 3-range 9 forward, 3 reverse (SyncShift); 12 forward, 12 reverse (SyncReverser); infinite forward and reverse, 3 ranges (hydrostatic) Max Travel Speed (Forward) F (2WD gear), DT (4WD gear): 13.2 mph; HST (4WD): 14.1 mph 15.6 mph (SyncShift); 15.6 mph (SyncReverser); 15.5 mph (hydrostatic) Max Travel Speed (Reverse) F (2WD gear), DT (4WD gear): 13.1 mph; HST (4WD): 12.7 mph 7.7 mph (SyncShift); 15.5 mph (hydrostatic) Clutch Dry type single stage 1 multi-disk wet clutch, 4.88 in (SyncShift); 2 multi-disk wet clutches, 4.88 in (SyncReverser) Differential Lock & Limited Slip Options Rear differential lock standard Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Two-post foldable ROPS (factory certified) with retractable seat belt Standard ROPS or folding ROPS; 2WD or MFWD Steering Integral power steering Power steering, cylinder-assisted Brakes Mechanical wet disc type, pedals can be locked together Wet disk Seat Suspension & Adjustability Not Published Not Published Front Axle Type F (2WD gear): tubular steel, non-adjustable tread spacing; DT (4WD gear), HST (4WD): bevel-gear front axle, non-adjustable tread spacing 2WD standard; MFWD optional, all ranges Front Axle Rating 2,865 lb (at 41.3 in tread, 2WD and 4WD models) 1,588 to 3,197 lb Drawbar Capacity 730 lb 562 lb ▶ Dimensions & ManeuverabilityOverall Width 55.1 in 50.0 in (minimum); 66.7 in (maximum) Wheelbase 63.3 in 68.0 in Ground Clearance F (2WD gear): 13.6 in; DT (4WD gear), HST (4WD): 13.5 in 13.4 in (rear axle) Min. Turn Radius without Brakes F (2WD gear): 8.9 ft; DT (4WD gear), HST (4WD): 10.5 ft Not Published Height to Top of ROPS 97.1 in 84.0 in (standard ROPS); 90.0 in (folding ROPS) Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length F (2WD gear): 119.1 in; DT (4WD gear), HST (4WD): 116.3 in (with 3-point hitch) 117 in (with 3-point hitch) ▶ WeightTractor Weight (Base) F (2WD gear): 2,557 lb; DT (4WD gear): 2,734 lb; HST (4WD): 2,778 lb 2,600 lb (2WD); 2,900 lb (MFWD) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural (standard); R3 Turf; R4 Industrial (4WD) Front: 5.00-15 F2 (2WD), 7.00-14 or 7.00-16 R1, 25x8.50-14 R4, 27x8.50-15 R3, 25-10.50LLx15 golf; rear: 11.2-24 or 12.4-24 R1, 11.2-24 or 41x14.00-20 R3, 15.00-19.5 R4, 41LLx18.00-16 golf R1 Agricultural - Front F (2WD gear): 5-15 (7.5L-15 optional); DT (4WD gear), HST (4WD): 7.2-16 5.00-15 (2WD, F2); 7.00-14 or 7.00-16 (MFWD) R1 Agricultural - Rear 11.2-24 11.2-24 or 12.4-24 R3 Turf - Front F (2WD gear): 23x8.5-12; DT (4WD gear), HST (4WD): 25x8.5-14 27x8.50-15 (2WD); 7.00-14 (MFWD) R3 Turf - Rear 13.6-16 41x14.00-20 or 11.2-24 R4 Industrial - Front 27x8.5-15 (4WD) 25x8.50-14 R4 Industrial - Rear 15-19.5 (4WD) 15.00-19.5 ▶ Loader & AttachmentsQuick Attach Loader System LA525: 2-lever quick coupler, tool-free attach and detach Not Published Loader Model LA525 420; 430 Loader Lift Height LA525: 94.3 in (at pivot pin) 420: 87.6 in; 430: 101.4 in Loader Lift Capacity (Full Height) LA525: 1,131 lb (at pivot pin, maximum height) 420: 1,195 lb; 430: 1,258 lb (to max height at pivot point) Loader Breakout Force LA525: 2,462 lbf (at bucket pivot pin) 420: 2,693 lbf; 430: 3,299 lbf (at pivot point) ▶ WarrantyWarranty Length & Coverage 24 months or 1500 hours (general) Not Published
