▶ EngineEngine Manufacturer Kubota KIOTI (Daedong) Engine Model F (2WD gear), DT (4WD gear): D1803-CR-E4-LB1; HST (4WD): D1803-CR-E4-LB2 3A165LXE Engine Type 3-cylinder, multi-valve, naturally aspirated, common-rail, liquid-cooled diesel Not Published No. of Cylinders 3 3 Displacement 111.4 in³ 100.5 in³ Rated Engine Speed 2700 rpm 2600 rpm Engine Power (Gross) 33 hp 34 hp PTO Power F (2WD gear), DT (4WD gear): 27.7 hp; HST (4WD): 26.2 hp 28.3 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled, water with pressurized radiator Not Published Air Cleaner Dry paper single element Dual stage air filter cartridge Fuel System Common-rail, direct injection, electronic control Not Published Alternator 40 A, 12 V Not Published ▶ HydraulicsPump Type Open center tandem pump, gear type Not Published Implement Flow 6.3 gpm 7.8 gpm Steering Flow 3.8 gpm 4.7 gpm Total Hydraulic Flow 10.1 gpm 12.5 gpm Overall Hydraulic Pump Flow 10.1 gpm 12.5 gpm Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 1 No. of Optional Remote Valves Up to 3: self-canceling detent valve or float detent valve 1 ▶ Fluid CapacityFuel Tank Capacity 11.1 gal 11.5 gal Coolant Capacity 6.3 qt Not Published Crankcase Capacity 7.1 qt Not Published Transmission / Hydraulic System Capacity F (2WD gear): 7.4 gal; DT (4WD gear): 7.5 gal; HST (4WD): 6.2 gal Not Published Front Axle Fluid Capacity 4.8 qt Not Published ▶ PTO & HitchPTO Type F (2WD gear), DT (4WD gear): Transmission driven with overrunning clutch; HST (4WD): Live-continuous running Hydraulic independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability No mid-PTO offered Optional (2,000 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,874 lb (at lift points) 2,270 lb Hitch Lift Capacity (at 24”) 1,433 lb Not Published Lift Control Type Position control Position, Draft and Mixed control ▶ Transmission & DrivetrainTransmission Type F (2WD gear), DT (4WD gear): manual transmission with synchronized shuttle; HST (4WD): hydrostatic transmission Synchronized shuttle No. of Speeds F (2WD gear), DT (4WD gear): 8F/8R; HST (4WD): 3-range 8F/8R (16F/16R with optional creeper gear) Max Travel Speed (Forward) F (2WD gear), DT (4WD gear): 13.2 mph; HST (4WD): 14.1 mph 13.93 mph Max Travel Speed (Reverse) F (2WD gear), DT (4WD gear): 13.1 mph; HST (4WD): 12.7 mph Not Published Clutch Dry type single stage Dry single plate Differential Lock & Limited Slip Options Rear differential lock standard Rear differential lock (mechanical) ▶ Chassis, Steering & ControlsFrame Type Two-post foldable ROPS (factory certified) with retractable seat belt Not Published Steering Integral power steering Hydraulic power steering Brakes Mechanical wet disc type, pedals can be locked together Wet disc Seat Suspension & Adjustability Not Published Adjustable seat Front Axle Type F (2WD gear): tubular steel, non-adjustable tread spacing; DT (4WD gear), HST (4WD): bevel-gear front axle, non-adjustable tread spacing 4WD (MFWD) Front Axle Rating 2,865 lb (at 41.3 in tread, 2WD and 4WD models) Not Published Drawbar Capacity 730 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 55.1 in 57.1 in Wheelbase 63.3 in 65.7 in Ground Clearance F (2WD gear): 13.6 in; DT (4WD gear), HST (4WD): 13.5 in 11.4 in Min. Turn Radius without Brakes F (2WD gear): 8.9 ft; DT (4WD gear), HST (4WD): 10.5 ft 125.9 in Height to Top of ROPS 97.1 in 92.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length F (2WD gear): 119.1 in; DT (4WD gear), HST (4WD): 116.3 in (with 3-point hitch) 126.3 in (with 3-point hitch) ▶ WeightTractor Weight (Base) F (2WD gear): 2,557 lb; DT (4WD gear): 2,734 lb; HST (4WD): 2,778 lb 3,475 lb (with ag tires) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural (standard); R3 Turf; R4 Industrial (4WD) R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front F (2WD gear): 5-15 (7.5L-15 optional); DT (4WD gear), HST (4WD): 7.2-16 7-16 R1 Agricultural - Rear 11.2-24 12.4-24 R3 Turf - Front F (2WD gear): 23x8.5-12; DT (4WD gear), HST (4WD): 25x8.5-14 27x8.5-15 R3 Turf - Rear 13.6-16 41x14-20 R4 Industrial - Front 27x8.5-15 (4WD) 27x10.5-15 R4 Industrial - Rear 15-19.5 (4WD) 43x16-20 ▶ Loader & AttachmentsQuick Attach Loader System LA525: 2-lever quick coupler, tool-free attach and detach Not Published Loader Model LA525 KL1450 Loader Lift Height LA525: 94.3 in (at pivot pin) KL1450: 103.5 in Loader Lift Capacity (Full Height) LA525: 1,131 lb (at pivot pin, maximum height) KL1450: 1,350 lb (at pivot pin) Loader Breakout Force LA525: 2,462 lbf (at bucket pivot pin) KL1450: 2,100 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage 24 months or 1500 hours (general) Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
