▶ EngineEngine Manufacturer Kubota Kubota Engine Model F (2WD gear), DT (4WD gear): D1803-CR-E4-LB1; HST (4WD): D1803-CR-E4-LB2 D1703-M-DI-E4 Engine Type Liquid-cooled, 3-cylinder, 4-cycle, multi-valve diesel, naturally aspirated, common rail direct injection Direct injection, vertical, water-cooled, 4-cycle diesel No. of Cylinders 3 3 Displacement 111.4 in³ 100.47 in³ Rated Engine Speed 2700 rpm 2200 rpm Engine Power (Gross) 33 hp 24.8 hp PTO Power F (2WD gear), DT (4WD gear): 27.7 hp; HST (4WD): 26.2 hp 19 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled, water with pressurized radiator Water-cooled Air Cleaner Dry paper single element Dry paper single element (dual optional) Fuel System Common rail (CRS) direct injection, electronic fuel injection Direct injection Alternator 40 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Open center tandem pump, gear type Open center tandem pump, gear type Implement Flow 6.3 gpm 5.15 gpm Steering Flow 3.8 gpm 3.13 gpm Total Hydraulic Flow 10.1 gpm 8.26 gpm Overall Hydraulic Pump Flow 10.1 gpm 8.26 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Up to 3 (self canceling detent valve or float detent valve options) Up to 3 (self canceling detent valve or float detent valve options) ▶ Fluid CapacityFuel Tank Capacity 11.1 gal 10.0 gal Coolant Capacity 6.3 qt 6.3 qt Crankcase Capacity 7.1 qt 6.0 qt Transmission / Hydraulic System Capacity F (2WD gear): 7.4 gal; DT (4WD gear): 7.5 gal; HST (4WD): 6.2 gal 6.2 gal Front Axle Fluid Capacity 4.8 qt 4.8 qt ▶ PTO & HitchPTO Type Live independent PTO with hydraulic clutch Live-continuous running PTO Rear 540 rpm 540 rpm Mid-PTO Availability No mid-PTO offered No mid-PTO offered Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1998 lb 1918 lb Hitch Lift Capacity (at 24”) 1433 lb 1389 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type F (2WD gear), DT (4WD gear): Synchronized shuttle gear transmission, 8F/8R; HST (4WD): Hydrostatic transmission, 3-range Hydrostatic transmission (3-range) No. of Speeds F (2WD gear), DT (4WD gear): 8F/8R; HST (4WD): 3-range 3-range Max Travel Speed (Forward) F (2WD gear), DT (4WD gear): 13.2 mph; HST (4WD): 14.1 mph 11.5 mph Max Travel Speed (Reverse) F (2WD gear), DT (4WD gear): 13.1 mph; HST (4WD): 12.7 mph 10.3 mph Clutch Dry type single stage Not Applicable Differential Lock & Limited Slip Options Rear differential lock standard Rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Two-post foldable ROPS (factory certified) with retractable seat belt Not Published Steering Integral power steering Integral type power steering Brakes Mechanical wet disc type, pedals can be locked together Wet disc type Seat Suspension & Adjustability Not Published Suspension seat with fore/aft travel adjustment and suspension tension adjustment Front Axle Type F (2WD gear): Tubular steel, non-adjustable tread spacing; DT (4WD gear), HST (4WD): Bevel gear front axle, non-adjustable tread spacing Bevel gear front axle, non-adjustable tread spacing Front Axle Rating 2865 lb (at 41.3 in tread, 2WD and 4WD models) 2865 lb (at 43.1 in tread) Drawbar Capacity 730 lb 730 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch F (2WD gear): 119.1 in; DT (4WD gear), HST (4WD): 116.3 in 106.3 in (without 3-point hitch) Overall Width 55.1 in 55.1 in Wheelbase 63.3 in 63.3 in Ground Clearance F (2WD gear): 13.6 in; DT (4WD gear), HST (4WD): 13.5 in 13.4 in Min. Turn Radius without Brakes F (2WD gear): 8.9 ft; DT (4WD gear), HST (4WD): 10.5 ft 8.2 ft (with brake applied) Height to Top of ROPS 91.7 in 91.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) F (2WD gear): 2557 lb; DT (4WD gear): 2734 lb; HST (4WD): 2778 lb 2623 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural (standard); R3 Turf; R4 Industrial (4WD) R1 Agricultural; R4 Industrial R1 Agricultural - Front F (2WD gear): 5-15 (7.5L-15 optional); DT (4WD gear), HST (4WD): 7.2-16 7.2-16 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front F (2WD gear): 23x8.5-12; DT (4WD gear), HST (4WD): 25x8.5-14 Not Published R3 Turf - Rear 13.6-16 Not Published R4 Industrial - Front 27x8.5-15 (4WD) 27X8.50-15 R4 Industrial - Rear 15-19.5 (4WD) 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System LA525: 2-Lever Quick Coupler, no tools required to attach and detach loader Front Loader (LA525 - 2 Lever Quick Coupler) Loader Model LA525 LA525 Loader Lift Height LA525: 94.3 in 94.3 in Loader Lift Capacity (Full Height) LA525: 1131 lb 1131 lb Loader Breakout Force LA525: 2462 lbf 2373 lbf ▶ WarrantyWarranty Length & Coverage 24 months or 1500 hours (general) Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. ▶ ITC Company AccessoriesAccessories that fit None tagged yet
