▶ EngineEngine Manufacturer Kubota Kubota Engine Model F (2WD gear), DT (4WD gear): D1803-CR-E4-LB1; HST (4WD): D1803-CR-E4-LB2 F (2WD), DT (4WD): D1402-DI-A; GST (4WD): D1402-DI-AE Engine Type Liquid-cooled, 3-cylinder, 4-cycle, multi-valve diesel, naturally aspirated, common rail direct injection Direct injection, vertical, water-cooled, 4-cycle diesel No. of Cylinders 3 3 Displacement 111.4 in³ 85.1 in³ Rated Engine Speed 2700 rpm 2600 rpm Engine Power (Gross) 33 hp 29.5 hp PTO Power F (2WD gear), DT (4WD gear): 27.7 hp; HST (4WD): 26.2 hp 23.5 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled, water with pressurized radiator Water-cooled, pressurized radiator Air Cleaner Dry paper single element Paper element Fuel System Common rail (CRS) direct injection, electronic fuel injection Direct injection Alternator 40 A, 12 V 35 A, 12 V ▶ HydraulicsPump Type Open center tandem pump, gear type Not Published Implement Flow 6.3 gpm 6.7 gpm Steering Flow 3.8 gpm 2.8 gpm Total Hydraulic Flow 10.1 gpm Not Published Overall Hydraulic Pump Flow 10.1 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Up to 3 (self canceling detent valve or float detent valve options) Up to 3 ▶ Fluid CapacityFuel Tank Capacity 11.1 gal 7.7 gal Coolant Capacity 6.3 qt 4.9 qt Crankcase Capacity 7.1 qt 6.0 qt Transmission / Hydraulic System Capacity F (2WD gear): 7.4 gal; DT (4WD gear): 7.5 gal; HST (4WD): 6.2 gal F (2WD), DT (4WD): 7.5 gal; GST (4WD): 7.1 gal Front Axle Fluid Capacity 4.8 qt 6.8 qt (4WD) ▶ PTO & HitchPTO Type Live independent PTO with hydraulic clutch Continuous running (live PTO with dual clutch if equipped) PTO Rear 540 rpm 540/1000 rpm Mid-PTO Availability No mid-PTO offered Optional mid-PTO, 1080/2000 rpm (USA No. 5, Kubota 10-tooth) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1998 lb 2425 lb Hitch Lift Capacity (at 24”) 1433 lb 1810 lb Lift Control Type Position control Position control (draft control optional) ▶ Transmission & DrivetrainTransmission Type F (2WD gear), DT (4WD gear): Synchronized shuttle gear transmission, 8F/8R; HST (4WD): Hydrostatic transmission, 3-range F (2WD), DT (4WD): Mechanical shuttle, 8F/8R; GST (4WD): Glide Shift Transmission, 8F/8R No. of Speeds F (2WD gear), DT (4WD gear): 8F/8R; HST (4WD): 3-range 8F/8R Max Travel Speed (Forward) F (2WD gear), DT (4WD gear): 13.2 mph; HST (4WD): 14.1 mph F (2WD), DT (4WD): 13.5 mph; GST (4WD): 13.3 mph Max Travel Speed (Reverse) F (2WD gear), DT (4WD gear): 13.1 mph; HST (4WD): 12.7 mph F (2WD), DT (4WD): 12.2 mph; GST (4WD): 11.9 mph Clutch Dry type single stage F (2WD), DT (4WD): Dry single plate or two plate (live PTO if equipped); GST (4WD): Dry single plate Differential Lock & Limited Slip Options Rear differential lock standard Rear differential lock (bevel gear differential) ▶ Chassis, Steering & ControlsFrame Type Two-post foldable ROPS (factory certified) with retractable seat belt Two-post ROPS Steering Integral power steering F (2WD), DT (4WD): Recirculating ball manual steering or integral power steering (if equipped); GST (4WD): Integral type power steering Brakes Mechanical wet disc type, pedals can be locked together Wet disc type Seat Suspension & Adjustability Not Published Not Published Front Axle Type F (2WD gear): Tubular steel, non-adjustable tread spacing; DT (4WD gear), HST (4WD): Bevel gear front axle, non-adjustable tread spacing Not Published Front Axle Rating 2865 lb (at 41.3 in tread, 2WD and 4WD models) Not Published Drawbar Capacity 730 lb 1100 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch F (2WD gear): 119.1 in; DT (4WD gear), HST (4WD): 116.3 in 109.1 in (w/o 3P) (without 3-point hitch) Overall Width 55.1 in 51.4 in Wheelbase 63.3 in 64.6 in Ground Clearance F (2WD gear): 13.6 in; DT (4WD gear), HST (4WD): 13.5 in F (2WD): 14.6 in; DT (4WD), GST (4WD): 13.6 in Min. Turn Radius without Brakes F (2WD gear): 8.9 ft; DT (4WD gear), HST (4WD): 10.5 ft 7.5 ft Height to Top of ROPS 91.7 in 79.9 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) F (2WD gear): 2557 lb; DT (4WD gear): 2734 lb; HST (4WD): 2778 lb F (2WD): 2250 lb; DT (4WD): 2470 lb; GST (4WD): 2557 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural (standard); R3 Turf; R4 Industrial (4WD) Ag: 5.00-15 (2WD) or 7-16 (4WD) front, 11.2-24 rear R1 Agricultural - Front F (2WD gear): 5-15 (7.5L-15 optional); DT (4WD gear), HST (4WD): 7.2-16 F (2WD): 5.00-15; DT (4WD), GST (4WD): 7-16 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front F (2WD gear): 23x8.5-12; DT (4WD gear), HST (4WD): 25x8.5-14 Not Published R3 Turf - Rear 13.6-16 Not Published R4 Industrial - Front 27x8.5-15 (4WD) Not Published R4 Industrial - Rear 15-19.5 (4WD) Not Published ▶ Loader & AttachmentsQuick Attach Loader System LA525: 2-Lever Quick Coupler, no tools required to attach and detach loader Not Published Loader Model LA525 BF400G; LA450A Loader Lift Height LA525: 94.3 in BF400G: 93.7 in; LA450A: 95 in Loader Lift Capacity (Full Height) LA525: 1131 lb BF400G: 882 lb; LA450A: 992 lb Loader Breakout Force LA525: 2462 lbf BF400G: 1654 lbf; LA450A: 1863 lbf ▶ WarrantyWarranty Length & Coverage 24 months or 1500 hours (general) Not Published
