▶ EngineEngine Manufacturer Kubota Shibaura Engine Model F (2WD gear), DT (4WD gear): D1803-CR-E4-LB1; HST (4WD): D1803-CR-E4-LB2 N843T-F Engine Type Liquid-cooled, 3-cylinder, 4-cycle, multi-valve diesel, naturally aspirated, common rail direct injection 3-cylinder diesel, liquid-cooled, turbocharged No. of Cylinders 3 3 Displacement 111.4 in³ 91.5 in³ Rated Engine Speed 2700 rpm 2600 rpm Engine Power (Gross) 33 hp 34 hp PTO Power F (2WD gear), DT (4WD gear): 27.7 hp; HST (4WD): 26.2 hp Gear: 29 hp; HST: 27.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled, water with pressurized radiator Liquid-cooled Air Cleaner Dry paper single element Not Published Fuel System Common rail (CRS) direct injection, electronic fuel injection Turbocharged, indirect low-pressure injection Alternator 40 A, 12 V Not Published ▶ HydraulicsPump Type Open center tandem pump, gear type Gear-type pump Implement Flow 6.3 gpm Not Published Steering Flow 3.8 gpm 3.8 gpm Total Hydraulic Flow 10.1 gpm 10.5 gpm Overall Hydraulic Pump Flow 10.1 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 6.7 gpm No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Up to 3 (self canceling detent valve or float detent valve options) Up to 2 ▶ Fluid CapacityFuel Tank Capacity 11.1 gal 10.0 gal Coolant Capacity 6.3 qt 1.32 gal Crankcase Capacity 7.1 qt 1.22 gal Transmission / Hydraulic System Capacity F (2WD gear): 7.4 gal; DT (4WD gear): 7.5 gal; HST (4WD): 6.2 gal 10.04 gal Front Axle Fluid Capacity 4.8 qt 1.48 gal ▶ PTO & HitchPTO Type Live independent PTO with hydraulic clutch Not Published PTO Rear 540 rpm 540 rpm (1-3/8 in 6-spline) Mid-PTO Availability No mid-PTO offered Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1998 lb 2,205 lb Hitch Lift Capacity (at 24”) 1433 lb 1,600 lb Lift Control Type Position control Not Published ▶ Transmission & DrivetrainTransmission Type F (2WD gear), DT (4WD gear): Synchronized shuttle gear transmission, 8F/8R; HST (4WD): Hydrostatic transmission, 3-range 9 x 3 mechanical shift constant mesh gears or 3-range hydrostatic No. of Speeds F (2WD gear), DT (4WD gear): 8F/8R; HST (4WD): 3-range Gear: 9F / 3R; HST: 3-range infinite Max Travel Speed (Forward) F (2WD gear), DT (4WD gear): 13.2 mph; HST (4WD): 14.1 mph Not Published Max Travel Speed (Reverse) F (2WD gear), DT (4WD gear): 13.1 mph; HST (4WD): 12.7 mph Not Published Clutch Dry type single stage Gear: dry single disc Differential Lock & Limited Slip Options Rear differential lock standard Mechanical engagement via heel pedal ▶ Chassis, Steering & ControlsFrame Type Two-post foldable ROPS (factory certified) with retractable seat belt Not Published Steering Integral power steering Power steering Brakes Mechanical wet disc type, pedals can be locked together Internal wet brakes, single brake pedal on HST, two brake pedals on gear models Seat Suspension & Adjustability Not Published Suspended vinyl seat with retractable seatbelt, fixed steering wheel Front Axle Type F (2WD gear): Tubular steel, non-adjustable tread spacing; DT (4WD gear), HST (4WD): Bevel gear front axle, non-adjustable tread spacing Cast steel 4WD front axle with center drive line and bevel-gear final drives Front Axle Rating 2865 lb (at 41.3 in tread, 2WD and 4WD models) Not Published Drawbar Capacity 730 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch F (2WD gear): 119.1 in; DT (4WD gear), HST (4WD): 116.3 in 116.0 in (w/o 3-point linkage) (without 3-point hitch) Overall Width 55.1 in 52.4 in Wheelbase 63.3 in 65.9 in Ground Clearance F (2WD gear): 13.6 in; DT (4WD gear), HST (4WD): 13.5 in Not Published Min. Turn Radius without Brakes F (2WD gear): 8.9 ft; DT (4WD gear), HST (4WD): 10.5 ft Not Published Height to Top of ROPS 91.7 in 97.6 in Height to Top of ROPS (folded) Not Published 63.8 in Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) F (2WD gear): 2557 lb; DT (4WD gear): 2734 lb; HST (4WD): 2778 lb Gear: 2,734 lb; HST: 2,767 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural (standard); R3 Turf; R4 Industrial (4WD) R3 Turf, R4 Industrial R1 Agricultural - Front F (2WD gear): 5-15 (7.5L-15 optional); DT (4WD gear), HST (4WD): 7.2-16 Not Published R1 Agricultural - Rear 11.2-24 Not Published R3 Turf - Front F (2WD gear): 23x8.5-12; DT (4WD gear), HST (4WD): 25x8.5-14 27x8.50-15 R3 Turf - Rear 13.6-16 38x14.00-20 R4 Industrial - Front 27x8.5-15 (4WD) 27x8.50-15 R4 Industrial - Rear 15-19.5 (4WD) 15x19.5 ▶ Loader & AttachmentsQuick Attach Loader System LA525: 2-Lever Quick Coupler, no tools required to attach and detach loader L105E: skid steer or pin-type implement attachments Loader Model LA525 L105E Loader Lift Height LA525: 94.3 in L105E: 95.7 in Loader Lift Capacity (Full Height) LA525: 1131 lb L105E: 1,210 lb Loader Breakout Force LA525: 2462 lbf L105E: 1,460 lb ▶ WarrantyWarranty Length & Coverage 24 months or 1500 hours (general) 5-year powertrain warranty
