▶ EngineEngine Manufacturer Kubota Shibaura Engine Model F (2WD gear), DT (4WD gear): D1803-CR-E4-LB1; HST (4WD): D1803-CR-E4-LB2 Not Published Engine Type Liquid-cooled, 3-cylinder, 4-cycle, multi-valve diesel, naturally aspirated, common rail direct injection 3-cylinder turbocharged diesel, liquid-cooled No. of Cylinders 3 3 Displacement 111.4 in³ 91.3 in³ Rated Engine Speed 2700 rpm 2600 rpm Engine Power (Gross) 33 hp 34.1 hp PTO Power F (2WD gear), DT (4WD gear): 27.7 hp; HST (4WD): 26.2 hp 29 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled, water with pressurized radiator Liquid-cooled Air Cleaner Dry paper single element Dry Fuel System Common rail (CRS) direct injection, electronic fuel injection Indirect injection Alternator 40 A, 12 V Not Published ▶ HydraulicsPump Type Open center tandem pump, gear type Dual engine-driven gear pumps Implement Flow 6.3 gpm Not Published Steering Flow 3.8 gpm Not Published Total Hydraulic Flow 10.1 gpm 9.7 gpm Overall Hydraulic Pump Flow 10.1 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Up to 3 (self canceling detent valve or float detent valve options) 2 ▶ Fluid CapacityFuel Tank Capacity 11.1 gal Not Published Coolant Capacity 6.3 qt Not Published Crankcase Capacity 7.1 qt Not Published Transmission / Hydraulic System Capacity F (2WD gear): 7.4 gal; DT (4WD gear): 7.5 gal; HST (4WD): 6.2 gal Not Published Front Axle Fluid Capacity 4.8 qt Not Published ▶ PTO & HitchPTO Type Live independent PTO with hydraulic clutch 8x8 Synchro Shuttle: independent; HST: transmission driven PTO Rear 540 rpm 540 rpm (1-3/8 in 6-spline) Mid-PTO Availability No mid-PTO offered Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1998 lb Not Published Hitch Lift Capacity (at 24”) 1433 lb 1,598 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type F (2WD gear), DT (4WD gear): Synchronized shuttle gear transmission, 8F/8R; HST (4WD): Hydrostatic transmission, 3-range 8 x 8 synchro shuttle or 3-range hydrostatic No. of Speeds F (2WD gear), DT (4WD gear): 8F/8R; HST (4WD): 3-range 8x8 Synchro Shuttle: 8F / 8R; HST: 3-range infinite Max Travel Speed (Forward) F (2WD gear), DT (4WD gear): 13.2 mph; HST (4WD): 14.1 mph Not Published Max Travel Speed (Reverse) F (2WD gear), DT (4WD gear): 13.1 mph; HST (4WD): 12.7 mph Not Published Clutch Dry type single stage Not Published Differential Lock & Limited Slip Options Rear differential lock standard Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Two-post foldable ROPS (factory certified) with retractable seat belt Not Published Steering Integral power steering Power steering Brakes Mechanical wet disc type, pedals can be locked together Wet disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type F (2WD gear): Tubular steel, non-adjustable tread spacing; DT (4WD gear), HST (4WD): Bevel gear front axle, non-adjustable tread spacing Not Published Front Axle Rating 2865 lb (at 41.3 in tread, 2WD and 4WD models) Not Published Drawbar Capacity 730 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch F (2WD gear): 119.1 in; DT (4WD gear), HST (4WD): 116.3 in Not Published Overall Width 55.1 in Not Published Wheelbase 63.3 in Not Published Ground Clearance F (2WD gear): 13.6 in; DT (4WD gear), HST (4WD): 13.5 in Not Published Min. Turn Radius without Brakes F (2WD gear): 8.9 ft; DT (4WD gear), HST (4WD): 10.5 ft Not Published Height to Top of ROPS 91.7 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) F (2WD gear): 2557 lb; DT (4WD gear): 2734 lb; HST (4WD): 2778 lb Not Published Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural (standard); R3 Turf; R4 Industrial (4WD) R1 Agricultural, R4 Industrial R1 Agricultural - Front F (2WD gear): 5-15 (7.5L-15 optional); DT (4WD gear), HST (4WD): 7.2-16 7-16 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front F (2WD gear): 23x8.5-12; DT (4WD gear), HST (4WD): 25x8.5-14 Not Published R3 Turf - Rear 13.6-16 Not Published R4 Industrial - Front 27x8.5-15 (4WD) 27x8.50-15 R4 Industrial - Rear 15-19.5 (4WD) 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System LA525: 2-Lever Quick Coupler, no tools required to attach and detach loader FLx2407: pin-on (skid steer quick attach optional) Loader Model LA525 FLx2407 Loader Lift Height LA525: 94.3 in FLx2407: 94.3 in Loader Lift Capacity (Full Height) LA525: 1131 lb FLx2407: 1,450 lb Loader Breakout Force LA525: 2462 lbf FLx2407: 2,288 lb ▶ WarrantyWarranty Length & Coverage 24 months or 1500 hours (general) 5-year powertrain warranty
