▶ EngineEngine Manufacturer Kubota Yanmar Engine Model D1803-CR-E5 3TNV88C-NJT2 Engine Type Direct injection, vertical, water-cooled 4-cycle, diesel Diesel, naturally aspirated No. of Cylinders 3 3 Displacement 111.4 in³ 100.2 in³ Rated Engine Speed 2700 rpm 2500 rpm Engine Power (Gross) 33 hp 30.7 hp PTO Power 26.1 hp 25 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Water-cooled Water pump Air Cleaner Dry type, single element Dry type with safety element Fuel System Direct injection High pressure common rail direct injection Alternator 45 A, 12 V 55 A, 12 V ▶ HydraulicsPump Type Not Published Implement/steering pump: tandem gear pump; hydrostatic pump: PV axial-piston pump Implement Flow 6.3 gpm 5.3 gpm Steering Flow 3.8 gpm 4.0 gpm Total Hydraulic Flow 10.1 gpm (6.3 + 3.8, computed) 9.3 gpm Overall Hydraulic Pump Flow 10.1 gpm (6.3 + 3.8, computed) 9.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 11.1 gal 7.5 gal Coolant Capacity 6.3 qt 5.2 qt Crankcase Capacity 7.1 qt 4.7 qt Transmission / Hydraulic System Capacity 6.9 gal 5.5 gal Front Axle Fluid Capacity 4.8 qt 4 qt ▶ PTO & HitchPTO Type Live independent PTO with hydraulic clutch Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch SAE Category I Category I Hitch Lift Capacity 1,998 lb Not Published Hitch Lift Capacity (at 24”) 1,435 lb 1,356 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission (3-range) Hydrostatic (2-range) No. of Speeds 3-range Infinite (2-range HST) Max Travel Speed (Forward) 14.1 mph Not Published Max Travel Speed (Reverse) 12.7 mph Not Published Clutch Not Applicable Not Published Differential Lock & Limited Slip Options Rear differential lock, pedal operated Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Integral type power steering Power steering Brakes Mechanical, wet disc type Wet disc Seat Suspension & Adjustability Suspension seat with fore/aft travel adjustment and suspension tension adjustment Not Published Front Axle Type Cast-iron front axle 4WD (MFWD) Front Axle Rating Not Published 1,760 lb Drawbar Capacity 730 lb 880 lb (maximum vertical load) ▶ Dimensions & ManeuverabilityOverall Width 55.1 in 56.9 in (min. rear tread, standard R1 tires); 61.7 in (max. rear tread, larger R4 tires) Wheelbase 63.4 in 62.8 in Ground Clearance 13.4 in 12.7 in (R4 tires) Min. Turn Radius without Brakes 8.2 ft (with brake applied) Not Published Height to Top of ROPS 91.7 in 95.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 108.5 in (without 3-point hitch) 115.9 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 2,778 lb 2,222 lb Weight with ROPS and Loader Not Published 2,972 lb Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial R1 Bar, R3 Turf, R4 Industrial R1 Agricultural - Front 7.2-16 7-14 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front 25X8.50-14 27X8.50-15 R3 Turf - Rear 13.6-16 41X14-20 R4 Industrial - Front 27X8.50-15 25X8.50-14 or 27X8.50-15 R4 Industrial - Rear 15-19.5 15-19.5 or 43x16-20 ▶ Loader & AttachmentsQuick Attach Loader System Front Loader (LA526 - 2 Lever Quick Coupler (OPT)) Quick-change attachment carrier Loader Model LA526 300E Loader Lift Height 94.8 in 84.0 in (at pivot pin) Loader Lift Capacity (Full Height) 1,144 lb 1,186 lb (at pivot pin) Loader Breakout Force Not Published 1,704 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours Basic 24 months or 2,000 hours; powertrain 72 months or 2,000 hours ▶ ITC Company AccessoriesAccessories that fit None tagged yet
