Kubota L3302 vs Yanmar YT235 | Side-by-side comparison | ITC Resource Center
ITC Resource Center
Tractor Comparison
Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
No photo
—
KubotaL3302
No photo
—
YanmarYT235
Comparison loaded for 2 tractors.
Spec
KubotaL3302
YanmarYT235
PTO Power
DT (4WD): 28.0 hp (20.9 kW); HST (4WD): 26.1 hp (19.5 kW)
27 hp (20.1 kW)
Alternator
Not Published
12 V, 40 A
Air Cleaner
Not Published
Dual stage cyclonic (resin 5.5 in.)
Engine Type
Direct injection, vertical, water-cooled 4-cycle, diesel
3-cylinder, naturally aspirated diesel
Fuel System
Direct injection
Common rail direct injection
Displacement
111.4 in³ (1826 cc)
100.1 in³ (1,642 cc)
No. of Cylinders
3
3
Rated Engine Speed
2700 rpm
2,800 rpm
Cooling System Type
Water-cooled
Liquid cooled
Engine Manufacturer
Kubota
YANMAR
Engine Emissions Constraints
Not Published
Tier 4
Engine Power (Gross vs. Net HP)
Gross: 33.0 hp (24.6 kW); Net: 31.8 hp (23.7 kW)
Gross: 34.2 hp (26.1 kW)
Tractor Weight with Loader
Not Published
3,471 lb (1,575 kg)
Weight with Cab and Loader
Not Applicable
Not Applicable
Weight with ROPS and Loader
Not Published
3,471 lb (1,575 kg)
Pump Type
Not Published
Not Published
Steering Flow
14.5 L/min (3.8 gpm)
15.5 L/min (4.1 gpm)
Implement Flow
23.9 L/min (6.3 gpm)
26.8 L/min (7.1 gpm)
Total Hydraulic Flow
38.4 L/min (10.1 gpm)
42.3 L/min (11.2 gpm)
Hydraulic System Type
Not Published
Open center
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
38.4 L/min (10.1 gpm)
42.3 L/min (11.2 gpm)
No. of Optional Remote Valves
Not Published
Not Published
No. of Standard Remote Valves
Not Published
Not Published
R3 Turf - Rear
13.6-16
13.6x16
R3 Turf - Front
25X8.50-14
25x8.5-14
Tire Size & Options
R1 Agricultural; R3 Turf; R4 Industrial
R1 Agricultural; R3 Turf; R4 Industrial
R4 Industrial - Rear
15-19.5
15-19.6
R4 Industrial - Front
27X8.50-15
25x8.5-14
R1 Agricultural - Rear
11.2-24
9.5-22
R1 Agricultural - Front
7.2-16
6.0-14
PTO Rear
540 rpm
540 rpm
PTO Type
DT (4WD): Transmission driven with overrunning clutch; HST (4WD): Live independent PTO with hydraulic clutch
Independent (electro-hydraulic)
Lift Control Type
Position control
Position control
Hitch Lift Capacity
1998 lb (906 kg)
2,205 lb (1,000 kg)
Mid-PTO Availability
Not Published
Standard
Category, 3-Point Hitch
SAE Category I
Category I
Hitch Lift Capacity (at 24”)
1435 lb (651 kg)
1,764 lb (800 kg)
Rear 3-Point Hitch Lift Capacity
1998 lb (906 kg)
2,205 lb (1,000 kg)
Coolant Capacity
Not Published
Not Published
Crankcase Capacity
Not Published
Not Published
Fuel Tank Capacity
13.5 gal (51 L)
7.4 gal (28 L)
Front Axle Fluid Capacity
Not Published
Not Published
Transmission / Hydraulic System Capacity
Not Published
Not Published
Loader Lift Height
94.3 in (2394 mm)
84 in (2,134 mm)
Loader Breakout Force
Not Published
2,105 lb (955 kg)
Price for Backhoe Option
BH77: $9,803 MSRP
B75: $13,261
Price for Mid-Mount Mower
Not Applicable
M60F: $4,051
Quick Attach Loader System
Front Loader (LA526 — 2 Lever Quick Coupler (OPT))
YL310: Skid steer style bucket attachment
Loader Lift Capacity (Full Height)
1144.4 lb (519 kg)
1,300 lb (590 kg)
Clutch
DT (4WD): Dry type single stage; HST (4WD): Not Applicable
Non-Commercial Home & Residential Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use — Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours.
Tractor: 24 months or 2,000 hours; Powertrain: 10 years or 3,000 hours; Attachments: 1-year limited warranty
