▶ EngineEngine Manufacturer Kubota Yanmar Engine Model D1803-CR-E5 3TNE84 Engine Type Direct injection, vertical, water-cooled 4-cycle, diesel 3-cylinder liquid-cooled diesel, direct injection No. of Cylinders 3 3 Displacement 111.4 in³ 91.3 in³ Rated Engine Speed 2700 rpm 2700 rpm Engine Power (Gross) 33 hp 32.2 hp PTO Power 28 hp 27 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dry type, single element Dry type with safety element Fuel System Direct injection Direct injection, self-bleeding in-line fuel pump, electric shutoff Alternator 45 A, 12 V 40 A ▶ HydraulicsPump Type Not Published Dual gear pump Implement Flow 6.3 gpm 8.3 gpm Steering Flow 3.8 gpm 5.0 gpm Total Hydraulic Flow 10.1 gpm (6.3 + 3.8, computed) 13.3 gpm Overall Hydraulic Pump Flow 10.1 gpm (6.3 + 3.8, computed) 13.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 2 No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 11.1 gal 10.0 gal Coolant Capacity 6.3 qt 6.1 qt Crankcase Capacity 7.1 qt 4.5 qt Transmission / Hydraulic System Capacity Not Published 6.3 gal (gear); 6.9 gal (hydrostatic) Front Axle Fluid Capacity 4.8 qt 4.7 qt ▶ PTO & HitchPTO Type Transmission driven with overrunning clutch Independent, wet disk clutch and brake PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Available, 2100 rpm Category, 3-Point Hitch SAE Category I Category 1 Hitch Lift Capacity 1,998 lb Not Published Hitch Lift Capacity (at 24”) 1,435 lb 2,200 lb Lift Control Type Position control Not Published ▶ Transmission & DrivetrainTransmission Type Gear shift with synchronized shuttle SyncShift 9F/3R gear (2WD and 4WD); SyncReverser 12F/12R (4WD only); hydrostatic 3-range (2WD and 4WD) No. of Speeds 8 forward, 8 reverse 9 forward, 3 reverse (SyncShift); 12 forward, 12 reverse (SyncReverser); infinite forward and reverse, 3 ranges (hydrostatic) Max Travel Speed (Forward) 13.2 mph 15.6 mph (SyncShift); 15.6 mph (SyncReverser); 15.5 mph (hydrostatic) Max Travel Speed (Reverse) 13.2 mph 7.7 mph (SyncShift); 15.5 mph (hydrostatic) Clutch Dry type single stage 1 multi-disk wet clutch, 4.88 in (SyncShift); 2 multi-disk wet clutches, 4.88 in (SyncReverser) Differential Lock & Limited Slip Options Rear differential lock, pedal operated Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Standard ROPS or folding ROPS; 2WD or MFWD Steering Integral type power steering Power steering, cylinder-assisted Brakes Mechanical, wet disc type Wet disk Seat Suspension & Adjustability Suspension seat with fore/aft travel adjustment and suspension tension adjustment Not Published Front Axle Type Cast-iron front axle 2WD standard; MFWD optional, all ranges Front Axle Rating Not Published 1,588 to 3,197 lb Drawbar Capacity 730 lb 562 lb ▶ Dimensions & ManeuverabilityOverall Width 55.1 in 50.0 in (minimum); 66.7 in (maximum) Wheelbase 63.4 in 68.0 in Ground Clearance 13.4 in 13.4 in (rear axle) Min. Turn Radius without Brakes 8.2 ft (with brake applied) Not Published Height to Top of ROPS 91.7 in 84.0 in (standard ROPS); 90.0 in (folding ROPS) Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 108.5 in (without 3-point hitch) 117 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 2,734 lb 2,600 lb (2WD); 2,900 lb (MFWD) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial Front: 5.00-15 F2 (2WD), 7.00-14 or 7.00-16 R1, 25x8.50-14 R4, 27x8.50-15 R3, 25-10.50LLx15 golf; rear: 11.2-24 or 12.4-24 R1, 11.2-24 or 41x14.00-20 R3, 15.00-19.5 R4, 41LLx18.00-16 golf R1 Agricultural - Front 7.2-16 5.00-15 (2WD, F2); 7.00-14 or 7.00-16 (MFWD) R1 Agricultural - Rear 11.2-24 11.2-24 or 12.4-24 R3 Turf - Front 25X8.50-14 27x8.50-15 (2WD); 7.00-14 (MFWD) R3 Turf - Rear 13.6-16 41x14.00-20 or 11.2-24 R4 Industrial - Front 27X8.50-15 25x8.50-14 R4 Industrial - Rear 15-19.5 15.00-19.5 ▶ Loader & AttachmentsQuick Attach Loader System Front Loader (LA526 - 2 Lever Quick Coupler (OPT)) Not Published Loader Model LA526 420; 430 Loader Lift Height 94.8 in 420: 87.6 in; 430: 101.4 in Loader Lift Capacity (Full Height) 1,144 lb 420: 1,195 lb; 430: 1,258 lb (to max height at pivot point) Loader Breakout Force Not Published 420: 2,693 lbf; 430: 3,299 lbf (at pivot point) ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
