▶ EngineEngine Manufacturer Kubota Kubota Engine Model D1803-CR-E5 Not Published Engine Type Direct injection, vertical, water-cooled 4-cycle, diesel Not Published No. of Cylinders 3 3 Displacement 111.4 in³ 91.5 in³ Rated Engine Speed 2700 rpm Not Published Engine Power (Gross) 33 hp 32.1 hp PTO Power 28 hp 25.8 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Water-cooled Not Published Air Cleaner Dry type, single element Not Published Fuel System Direct injection Indirect injection Alternator 45 A, 12 V Not Published ▶ HydraulicsPump Type Not Published Single pump (position-control) Implement Flow 6.3 gpm 8.3 gpm Steering Flow 3.8 gpm 4.9 gpm Total Hydraulic Flow 10.1 gpm (6.3 + 3.8, computed) 13.2 gpm Overall Hydraulic Pump Flow 10.1 gpm (6.3 + 3.8, computed) 13.2 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published 3 ▶ Fluid CapacityFuel Tank Capacity 11.1 gal 10.6 gal Coolant Capacity 6.3 qt 6.3 qt Crankcase Capacity 7.1 qt 6.0 qt Transmission / Hydraulic System Capacity Not Published 11.1 gal Front Axle Fluid Capacity 4.8 qt Not Published ▶ PTO & HitchPTO Type Transmission driven with overrunning clutch Independent, hydraulic clutch PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Optional mid-PTO, independent, 2000 rpm Category, 3-Point Hitch SAE Category I Category I Hitch Lift Capacity 1,998 lb 3,750 lb (at lift points) Hitch Lift Capacity (at 24”) 1,435 lb 2,650 lb Lift Control Type Position control Position control (with optional draft control) ▶ Transmission & DrivetrainTransmission Type Gear shift with synchronized shuttle F (2WD), DT (4WD): 8-speed fully synchronized main and shuttle (16-speed with creep option) No. of Speeds 8 forward, 8 reverse 8F/8R (16F/16R with creep option) Max Travel Speed (Forward) 13.2 mph Not Published Max Travel Speed (Reverse) 13.2 mph Not Published Clutch Dry type single stage Dry type single stage Differential Lock & Limited Slip Options Rear differential lock, pedal operated Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Integral type power steering Hydrostatic power steering Brakes Mechanical, wet disc type Wet disk type Seat Suspension & Adjustability Suspension seat with fore/aft travel adjustment and suspension tension adjustment Not Published Front Axle Type Cast-iron front axle Not Published Front Axle Rating Not Published Not Published Drawbar Capacity 730 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 55.1 in 56.3 in (minimum tread) Wheelbase 63.4 in 71.1 in Ground Clearance 13.4 in 14.6 in Min. Turn Radius without Brakes 8.2 ft (with brake applied) 8.9 ft (with brake applied) Height to Top of ROPS 91.7 in 88.8 in (with ROPS) Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 108.5 in (without 3-point hitch) 119.1 in (without 3-point hitch) ▶ WeightTractor Weight (Base) 2,734 lb 3,265 lb (with ROPS) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial Standard Front: 7-16; Rear: 12.4-24 R1 Agricultural - Front 7.2-16 7-16 R1 Agricultural - Rear 11.2-24 12.4-24 R3 Turf - Front 25X8.50-14 Not Published R3 Turf - Rear 13.6-16 Not Published R4 Industrial - Front 27X8.50-15 Not Published R4 Industrial - Rear 15-19.5 Not Published ▶ Loader & AttachmentsQuick Attach Loader System Front Loader (LA526 - 2 Lever Quick Coupler (OPT)) LA513 and LA723 loaders offered Loader Model LA526 LA513; LA723 Loader Lift Height 94.8 in LA513: 96.5 in; LA723: 102.4 in Loader Lift Capacity (Full Height) 1,144 lb LA513: 1,345 lb; LA723: 1,870 lb Loader Breakout Force Not Published LA513: 2,160 lbf (at 19.7 in); LA723: 2,605 lbf (at 19.7 in) (19.7 in forward of pivot pin) ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
