▶ EngineEngine Manufacturer Kubota Kubota Engine Model D1803-CR-E5 F (2WD gear), DT (4WD gear): D1803-CR-E4-LB1; HST (4WD): D1803-CR-E4-LB2 Engine Type Direct injection, vertical, water-cooled 4-cycle, diesel 3-cylinder, multi-valve, naturally aspirated, common-rail, liquid-cooled diesel No. of Cylinders 3 3 Displacement 111.4 in³ 111.4 in³ Rated Engine Speed 2700 rpm 2700 rpm Engine Power (Gross) 33 hp 33 hp PTO Power 28 hp F (2WD gear), DT (4WD gear): 27.7 hp; HST (4WD): 26.2 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Water-cooled Liquid-cooled, water with pressurized radiator Air Cleaner Dry type, single element Dry paper single element Fuel System Direct injection Common-rail, direct injection, electronic control Alternator 45 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Not Published Open center tandem pump, gear type Implement Flow 6.3 gpm 6.3 gpm Steering Flow 3.8 gpm 3.8 gpm Total Hydraulic Flow 10.1 gpm (6.3 + 3.8, computed) 10.1 gpm Overall Hydraulic Pump Flow 10.1 gpm (6.3 + 3.8, computed) 10.1 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Up to 3: self-canceling detent valve or float detent valve ▶ Fluid CapacityFuel Tank Capacity 11.1 gal 11.1 gal Coolant Capacity 6.3 qt 6.3 qt Crankcase Capacity 7.1 qt 7.1 qt Transmission / Hydraulic System Capacity Not Published F (2WD gear): 7.4 gal; DT (4WD gear): 7.5 gal; HST (4WD): 6.2 gal Front Axle Fluid Capacity 4.8 qt 4.8 qt ▶ PTO & HitchPTO Type Transmission driven with overrunning clutch F (2WD gear), DT (4WD gear): Transmission driven with overrunning clutch; HST (4WD): Live-continuous running PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published No mid-PTO offered Category, 3-Point Hitch SAE Category I Category I Hitch Lift Capacity 1,998 lb 1,874 lb (at lift points) Hitch Lift Capacity (at 24”) 1,435 lb 1,433 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Gear shift with synchronized shuttle F (2WD gear), DT (4WD gear): manual transmission with synchronized shuttle; HST (4WD): hydrostatic transmission No. of Speeds 8 forward, 8 reverse F (2WD gear), DT (4WD gear): 8F/8R; HST (4WD): 3-range Max Travel Speed (Forward) 13.2 mph F (2WD gear), DT (4WD gear): 13.2 mph; HST (4WD): 14.1 mph Max Travel Speed (Reverse) 13.2 mph F (2WD gear), DT (4WD gear): 13.1 mph; HST (4WD): 12.7 mph Clutch Dry type single stage Dry type single stage Differential Lock & Limited Slip Options Rear differential lock, pedal operated Rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post foldable ROPS (factory certified) with retractable seat belt Steering Integral type power steering Integral power steering Brakes Mechanical, wet disc type Mechanical wet disc type, pedals can be locked together Seat Suspension & Adjustability Suspension seat with fore/aft travel adjustment and suspension tension adjustment Not Published Front Axle Type Cast-iron front axle F (2WD gear): tubular steel, non-adjustable tread spacing; DT (4WD gear), HST (4WD): bevel-gear front axle, non-adjustable tread spacing Front Axle Rating Not Published 2,865 lb (at 41.3 in tread, 2WD and 4WD models) Drawbar Capacity 730 lb 730 lb ▶ Dimensions & ManeuverabilityOverall Width 55.1 in 55.1 in Wheelbase 63.4 in 63.3 in Ground Clearance 13.4 in F (2WD gear): 13.6 in; DT (4WD gear), HST (4WD): 13.5 in Min. Turn Radius without Brakes 8.2 ft (with brake applied) F (2WD gear): 8.9 ft; DT (4WD gear), HST (4WD): 10.5 ft Height to Top of ROPS 91.7 in 97.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 108.5 in (without 3-point hitch) F (2WD gear): 119.1 in; DT (4WD gear), HST (4WD): 116.3 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 2,734 lb F (2WD gear): 2,557 lb; DT (4WD gear): 2,734 lb; HST (4WD): 2,778 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural (standard); R3 Turf; R4 Industrial (4WD) R1 Agricultural - Front 7.2-16 F (2WD gear): 5-15 (7.5L-15 optional); DT (4WD gear), HST (4WD): 7.2-16 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front 25X8.50-14 F (2WD gear): 23x8.5-12; DT (4WD gear), HST (4WD): 25x8.5-14 R3 Turf - Rear 13.6-16 13.6-16 R4 Industrial - Front 27X8.50-15 27x8.5-15 (4WD) R4 Industrial - Rear 15-19.5 15-19.5 (4WD) ▶ Loader & AttachmentsQuick Attach Loader System Front Loader (LA526 - 2 Lever Quick Coupler (OPT)) LA525: 2-lever quick coupler, tool-free attach and detach Loader Model LA526 LA525 Loader Lift Height 94.8 in LA525: 94.3 in (at pivot pin) Loader Lift Capacity (Full Height) 1,144 lb LA525: 1,131 lb (at pivot pin, maximum height) Loader Breakout Force Not Published LA525: 2,462 lbf (at bucket pivot pin) ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours 24 months or 1500 hours (general) ▶ ITC Company AccessoriesAccessories that fit None tagged yet
