▶ EngineEngine Manufacturer Kubota Yanmar Engine Model D1803-CR-E4-GL1 3TNV88C-DKTF Engine Type Liquid-cooled, 4-cycle multi valve, diesel, Naturally Aspirated 4-cycle diesel, water-cooled (natural aspiration) No. of Cylinders 3 3 Displacement 111.4 in³ 100.2 in³ Rated Engine Speed 2600 rpm 3000 rpm Engine Power (Gross) 37 hp 37 hp PTO Power 28 hp 30.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Dry paper, dual element Dual dry Fuel System Electronic CRS (Common Rail System) CRDI Alternator 40 A, 12 V 70 A, 12 V ▶ HydraulicsPump Type Tandem pump - gear type Dual Gear Pump Implement Flow 8.1 gpm 6.3 gpm Steering Flow 4.7 gpm 4.6 gpm Total Hydraulic Flow 12.8 gpm 10.9 gpm Overall Hydraulic Pump Flow 12.8 gpm 10.9 gpm Hydraulic System Type Open center Separate reservoir, independent fully live Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None standard (up to 3 optional) 1 No. of Optional Remote Valves Optional, up to 3 (double-acting valve or float detent valve options, any position) 1 ▶ Fluid CapacityFuel Tank Capacity 13.5 gal 9.0 gal Coolant Capacity 7.9 qt 7.4 qt Crankcase Capacity 7.1 qt 6.0 qt Transmission / Hydraulic System Capacity 11.1 gal 9.25 gal Front Axle Fluid Capacity 6.9 qt 8.7 qt ▶ PTO & HitchPTO Type Live independent (hydraulic clutch) Independent PTO Rear 540 rpm @ 2476 engine rpm 540 rpm Mid-PTO Availability Optional 2000 (option) Category, 3-Point Hitch SAE Category 1 Category I Hitch Lift Capacity 3,750 lb 2,646 lb Hitch Lift Capacity (at 24”) 2646 lb 1,764 lb Lift Control Type Position control Position ▶ Transmission & DrivetrainTransmission Type Hydrostatic Partial synchromesh shuttle shift (high/low selector) No. of Speeds 3-Range, 6 speeds (H-DS), infinitely variable in each 12F/12R Max Travel Speed (Forward) 16.5 mph 21.8 mph Max Travel Speed (Reverse) 15.8 mph Not Published Clutch Not Published single plate dry clutch (8.86" diameter) Differential Lock & Limited Slip Options Rear differential lock, standard 4WD, Differential Lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic Brakes Wet disc type, mechanically activated Wet Disc Seat Suspension & Adjustability Deluxe suspension seat with swivel (standard); Air-Ride seat (optional) Not Published Front Axle Type 4WD: Bevel gear front axle, non-adjustable tread spacing 4WD front axle, center-pivot, reverse Eliot type Front Axle Rating Not Published Not Published Drawbar Capacity 1,433 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 115.0 in (without 3-point hitch) 128 in Overall Width 59.8 in 58.0 in Wheelbase 71.1 in 66.1 in Ground Clearance 13.5 in 12.8 in Min. Turn Radius without Brakes 8.9 ft (with brake applied) 116 in Height to Top of ROPS 97.2 in Not Applicable Height to Top of ROPS (folded) Not Published Not Applicable Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 3494 lb n/a Weight with ROPS and Loader Not Published Not Applicable Weight with Cab and Loader Not Published 4,469 lb ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 7.0-16 8.0-16 R1 Agricultural - Rear 12.4-24 12.4-24 R3 Turf - Front 27x10.50-15 27X10.5-15 R3 Turf - Rear 41x18LL-16.1 41x14-20 R4 Industrial - Front 10-16.5 27X10.5-15 R4 Industrial - Rear 420/70-24 12.5X20 ▶ Loader & AttachmentsQuick Attach Loader System LA555: Mechanical 2-Lever Quick Coupler (standard); LA805: Mechanical 2-Lever Quick Coupler (standard); Hydraulic 2-Lever Quick Coupler (optional); Single Lever Hose Quick Coupler (optional) L102: Skid-steer compatible quick-attach Loader Model LA555 or LA805 L102 Loader Lift Height LA555: 96.4 in; LA805: 104.7 in 102 in Loader Lift Capacity (Full Height) LA555: 1190 lb; LA805: 1715 lb 2,116 lb Loader Breakout Force LA555: 2030 lb; LA805: 2549 lb (19.7 in forward of pivot pin) 3,435 lb ▶ WarrantyWarranty Length & Coverage Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. Full-machine: 24 months/2,000 hours; Powertrain: 96 months/3,000 hours (whichever comes first) ▶ ITC Company AccessoriesAccessories that fit
