▶ EngineEngine Manufacturer Kubota Yanmar Engine Model D1803-CR-E4-GL1 3TNV88-CR Engine Type Naturally aspirated, multi-valve, liquid-cooled diesel Natural aspiration No. of Cylinders 3 3 Displacement 111.4 in³ 100.2 in³ Rated Engine Speed 2700 rpm 3000 rpm Engine Power (Gross) 37 hp 36.9 hp PTO Power 29.5 hp 30.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry paper, dual element Dual dry Fuel System Electronic CRS (Common Rail System) Common Rail Direct Injection Alternator 40 A, 12 V 70 A, 12 V ▶ HydraulicsPump Type Tandem pump - gear type Dual gear pump Implement Flow 8.3 gpm 6.4 gpm Steering Flow 4.9 gpm 4.6 gpm Total Hydraulic Flow 13.2 gpm 11.0 gpm Overall Hydraulic Pump Flow 13.2 gpm 11.0 gpm Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None standard (up to 3 optional) 1 No. of Optional Remote Valves Optional, up to 3: double-acting valve or float detent valve, any position 1 ▶ Fluid CapacityFuel Tank Capacity 13.5 gal 9.0 gal Coolant Capacity 7.9 qt 7.4 qt Crankcase Capacity 7.1 qt 6.0 qt Transmission / Hydraulic System Capacity 11.1 gal 9.25 gal Front Axle Fluid Capacity 6.9 qt 8.7 qt ▶ PTO & HitchPTO Type Live independent (hydraulic clutch) Independent PTO Rear Not Published 540 rpm Mid-PTO Availability Optional No mid-PTO offered Category, 3-Point Hitch SAE Category I Category I Hitch Lift Capacity 3,750 lb 2,646 lb Hitch Lift Capacity (at 24”) 2,646 lb 1,764 lb Lift Control Type Position control Position ▶ Transmission & DrivetrainTransmission Type Glide Shift 12F/12R Syncro Shuttle No. of Speeds 12Fx8R 12 forward, 12 reverse Max Travel Speed (Forward) 16.5 mph 15.0 mph Max Travel Speed (Reverse) 15.8 mph Not Published Clutch Not Published Single plate dry clutch (8.86 in diameter); hydraulic clutch assembly for Independent PTO models Differential Lock & Limited Slip Options Rear differential lock, standard 4WD, differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Unit frame: engine, clutch housing, transmission and front axle support bolted into one rigid assembly Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disc type, mechanically activated Wet disc Seat Suspension & Adjustability Deluxe suspension seat with swivel (standard); Air-Ride seat (optional) Suspension seat with armrests and retractable seat belt, standard Front Axle Type 4WD: Bevel gear front axle, non-adjustable tread spacing Center-pivot, reverse Elliot type (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity 1,433 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 59.8 in 58.0 in Wheelbase 71.1 in 64.5 in Ground Clearance 13.5 in 12.8 in Min. Turn Radius without Brakes 8.9 ft (with brake applied) 116 in Height to Top of ROPS 97.2 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 92.5 in Overall Length 115.0 in (without 3-point hitch) 128 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 3,494 lb 3,417 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial Titan (USA): R4 Industrial (Std), R1 Agricultural (Opt), R3 Turf (Opt), R14 (Opt) R1 Agricultural - Front Not Published 7-16 R1 Agricultural - Rear 12.4-24 11.2x24 R3 Turf - Front 27x10.50-15 28x8.5-15 R3 Turf - Rear 41x18LL-16.1 41x14-20 R4 Industrial - Front 10-16.5 10-16.5 R4 Industrial - Rear 420/70-24 43x16-20 ▶ Loader & AttachmentsQuick Attach Loader System LA555: 2-lever mechanical quick coupler (standard); LA805: 2-lever mechanical quick coupler (standard); 2-lever hydraulic quick coupler (optional); single-lever hose coupler (optional) L102: Skid-steer compatible quick-attach Loader Model LA555 or LA805 L102 Loader Lift Height LA555: 96.4 in; LA805: 104.7 in L102: 102 in Loader Lift Capacity (Full Height) LA555: 1,190 lb; LA805: 1,715 lb (at pivot pin) L102: 2,116 lb to full height Loader Breakout Force LA555: 2,030 lb; LA805: 2,549 lb L102: 3,435 lb ▶ WarrantyWarranty Length & Coverage Not Published Basic 2 years or 2,000 hours; powertrain 8 years or 3,000 hours, no deductible, parts and labor ▶ ITC Company AccessoriesAccessories that fit
