▶ EngineEngine Manufacturer Kubota Kubota Engine Model D1803-CR-E4-GL2 D1803-CR-E4-GL2 Engine Type Liquid-cooled, 4-cycle multi valve, diesel, Naturally Aspirated Liquid-cooled, 4-cycle multi valve, diesel, Naturally Aspirated No. of Cylinders 3 3 Displacement 111.4 in³ 111.4 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 37 hp 37 hp PTO Power 28 hp 28 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry paper, dual element Dry paper, dual element Fuel System Electronic CRS (Common Rail System) Electronic CRS (Common Rail System) Alternator 60 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Tandem pump - gear type Tandem pump - gear type Implement Flow 8.1 gpm 8.1 gpm Steering Flow 4.7 gpm 4.7 gpm Total Hydraulic Flow 12.8 gpm 12.8 gpm Overall Hydraulic Pump Flow 12.8 gpm 12.8 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None standard (up to 3 optional) None standard (up to 3 optional) No. of Optional Remote Valves Optional, up to 3 (double-acting valve or float detent valve options, any position) Optional, up to 3 (double-acting valve or float detent valve options, any position) ▶ Fluid CapacityFuel Tank Capacity 13.5 gal 13.5 gal Coolant Capacity 7.9 qt 7.9 qt Crankcase Capacity 7.1 qt 7.1 qt Transmission / Hydraulic System Capacity 11.1 gal 11.1 gal Front Axle Fluid Capacity 6.9 qt 6.9 qt ▶ PTO & HitchPTO Type Live independent (hydraulic clutch) Live independent (hydraulic clutch) PTO Rear 540 rpm @ 2476 engine rpm 540 rpm @ 2476 engine rpm Mid-PTO Availability Optional Optional Category, 3-Point Hitch SAE Category 1 SAE Category 1 Hitch Lift Capacity 3,750 lb 3,750 lb Hitch Lift Capacity (at 24”) 2646 lb 2646 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic Hydrostatic No. of Speeds 3-Range, 6 speeds (H-DS), infinitely variable in each 3-Range, 6 speeds (H-DS), infinitely variable in each Max Travel Speed (Forward) 16.5 mph 16.5 mph Max Travel Speed (Reverse) 14.9 mph 14.9 mph Clutch Not Published Not Published Differential Lock & Limited Slip Options Rear differential lock, standard Rear differential lock, standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disc type, mechanically activated Wet disc type, mechanically activated Seat Suspension & Adjustability Deluxe suspension seat with swivel (standard); Air-Ride seat (optional) Deluxe suspension seat with swivel (standard); Air-Ride seat (optional) Front Axle Type 4WD: Bevel gear front axle, non-adjustable tread spacing 4WD: Bevel gear front axle, non-adjustable tread spacing Front Axle Rating Not Published Not Published Drawbar Capacity 1,433 lb 1,433 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 115.0 in (without 3-point hitch) 115.0 in (without 3-point hitch) Overall Width 59.8 in 59.8 in Wheelbase 71.1 in 71.1 in Ground Clearance 13.5 in 13.5 in Min. Turn Radius without Brakes 8.9 ft (with brake applied) 8.9 ft (with brake applied) Height to Top of ROPS Not Published 97.2 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 3880 lb 3505 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front 7.0-16 7.0-16 R1 Agricultural - Rear 12.4-24 12.4-24 R3 Turf - Front 27x10.50-15 27x10.50-15 R3 Turf - Rear 41x18LL-16.1 41x18LL-16.1 R4 Industrial - Front 10-16.5 10-16.5 R4 Industrial - Rear 420/70-24 420/70-24 ▶ Loader & AttachmentsQuick Attach Loader System LA555: Mechanical 2-Lever Quick Coupler (standard); LA805: Mechanical 2-Lever Quick Coupler (standard); Hydraulic 2-Lever Quick Coupler (optional); Single Lever Hose Quick Coupler (optional) LA555: Mechanical 2-Lever Quick Coupler (standard); LA805: Mechanical 2-Lever Quick Coupler (standard); Hydraulic 2-Lever Quick Coupler (optional); Single Lever Hose Quick Coupler (optional) Loader Model LA555 or LA805 LA555 or LA805 Loader Lift Height LA555: 96.4 in; LA805: 104.7 in LA555: 96.4 in; LA805: 104.7 in Loader Lift Capacity (Full Height) LA555: 1190 lb; LA805: 1715 lb LA555: 1190 lb; LA805: 1715 lb Loader Breakout Force LA555: 2030 lb; LA805: 2549 lb (19.7 in forward of pivot pin) LA555: 2030 lb; LA805: 2549 lb (19.7 in forward of pivot pin) ▶ WarrantyWarranty Length & Coverage Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. ▶ ITC Company AccessoriesAccessories that fit
