▶ EngineEngine Manufacturer Kubota Kubota Engine Model V1903-A Not Published Engine Type Indirect injection, vertical, water-cooled, 4-cycle diesel Indirect injection, liquid-cooled diesel No. of Cylinders 4 3 Displacement 113.3 in³ 111.4 in³ Rated Engine Speed 2600 rpm 2700 rpm Engine Power (Gross) 38.5 hp 35.7 hp PTO Power 31 hp F (2WD gear), DT (4WD gear): 30 hp; HST (4WD): 28.5 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Not Published Not Published Fuel System Indirect injection Indirect injection Alternator Not Published 40 A, 12 V ▶ HydraulicsPump Type Not Published Not Published Implement Flow 7.8 gpm 6.3 gpm Steering Flow Not Published 3.8 gpm Total Hydraulic Flow Not Published 10.1 gpm (6.3 + 3.8, computed) Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Up to 3 ▶ Fluid CapacityFuel Tank Capacity 9.2 gal 9.0 gal Coolant Capacity 7.9 qt Not Published Crankcase Capacity 6.3 qt Not Published Transmission / Hydraulic System Capacity 10.3 gal F (2WD): 7.1 gal; DT (4WD): 7.3 gal; HST (4WD): 6.2 gal Front Axle Fluid Capacity Not Published 4.8 qt ▶ PTO & HitchPTO Type Independent F (2WD gear), DT (4WD gear): live-continuous running; HST (4WD): live-continuous with overrunning clutch PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional mid-PTO, 2000 rpm (USA No. 5, Kubota 10-tooth involute spline) Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,870 lb 1,998 lb Hitch Lift Capacity (at 24”) 2,310 lb 1,435 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type F (2WD), DT (4WD): synchronized shuttle and synchronized transmission, 8F/8R; GST (4WD): Glide Shift, 8F/8R F (2WD gear), DT (4WD gear): sliding gear and constant mesh, 8F/4R; HST (4WD): hydrostatic transmission, 3-range No. of Speeds 8F/8R F (2WD gear), DT (4WD gear): 8F/4R; HST (4WD): 3-range Max Travel Speed (Forward) 14.3 mph F (2WD gear), DT (4WD gear): 13.2 mph; HST (4WD): 14.1 mph Max Travel Speed (Reverse) 13.1 mph F (2WD gear), DT (4WD gear): 4.7 mph; HST (4WD): 12.7 mph Clutch Dry type single stage F (2WD gear), DT (4WD gear): dry-type, dual-stage; HST (4WD): dry-type, single-stage Differential Lock & Limited Slip Options Not Published Rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Two-post ROPS Foldable ROPS (standard on all models) Steering Hydrostatic power steering Integral type power steering Brakes Wet disc type Wet disc type Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published 4WD: Bevel gear front axle Front Axle Rating Not Published Not Published Drawbar Capacity 1,430 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 56.1 in 51.4 in Wheelbase F (2WD): 71.3 in; DT (4WD), GST (4WD): 71.1 in 63.3 in Ground Clearance 13.2 in F (2WD gear): 13.6 in; DT (4WD gear), HST (4WD): 13.4 in Min. Turn Radius without Brakes F (2WD), DT (4WD): 8.2 ft; GST (4WD): 8.5 ft (with brake applied) F (2WD gear): 7.9 ft; DT (4WD gear), HST (4WD): 8.2 ft (with brake applied) Height to Top of ROPS 83.5 in 85.0 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 118.1 in (without 3-point hitch) F (2WD gear): 110.6 in; DT (4WD gear), HST (4WD): 106.5 in (without 3-point hitch) ▶ WeightTractor Weight (Base) F (2WD): 2,800 lb; DT (4WD): 2,955 lb; GST (4WD): 2,965 lb (with ROPS) F (2WD gear): 2,403 lb; DT (4WD gear): 2,580 lb; HST (4WD): 2,600 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Ag: 6.00-16 (2WD) or 8.3-16 (4WD) front, 13.6-24 rear AG standard; turf and industrial optional R1 Agricultural - Front F (2WD): 6.00-16; DT (4WD), GST (4WD): 8.3-16 F (2WD gear): 5-15; DT (4WD gear), HST (4WD): 7-16 R1 Agricultural - Rear 13.6-24 11.2-24 R3 Turf - Front Not Published 25x8.50-14 (4WD) R3 Turf - Rear Not Published 13.6-16 R4 Industrial - Front Not Published 27x8.50-15 (4WD) R4 Industrial - Rear Not Published 15-19.5 R4 (4WD) ▶ Loader & AttachmentsQuick Attach Loader System Not Published LA463: quick attach/detach loader (mounting pins and hose couplers from the seat); skid steer-type quick coupler optional Loader Model LA680; LA681 LA463 Loader Lift Height LA680: 102.4 in; LA681: 102.4 in LA463: 95.3 in (at pivot pin) Loader Lift Capacity (Full Height) LA680: 1,499 lb; LA681: 1,499 lb LA463: 1,142 lb (at pivot pin) Loader Breakout Force LA680: 2,557 lbf; LA681: 2,557 lbf Not Published ▶ WarrantyWarranty Length & Coverage Not Published Not Published
