▶ EngineEngine Manufacturer Kubota Kubota Engine Model F (2WD gear), DT (4WD gear): D1803-CR-E4-LB3; HST (4WD): D1803-CR-E4-LB4 D1803-CR-E4-GL2 Engine Type Liquid-cooled, 3-cylinder, 4-cycle, multi-valve diesel, naturally aspirated, common rail direct injection Liquid-cooled, 4-cycle multi valve, diesel, Naturally Aspirated No. of Cylinders 3 3 Displacement 111.4 in³ 111.4 in³ Rated Engine Speed 2700 rpm 2600 rpm Engine Power (Gross) 37.5 hp 37 hp PTO Power F (2WD gear), DT (4WD gear): 32.1 hp; HST (4WD): 30.6 hp 28 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled, water with pressurized radiator Liquid-cooled Air Cleaner Dry paper single element Dry paper, dual element Fuel System Common rail (CRS) direct injection, electronic fuel injection Electronic CRS (Common Rail System) Alternator 40 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Open center tandem pump, gear type Tandem pump - gear type Implement Flow 6.3 gpm 8.1 gpm Steering Flow 3.8 gpm 4.7 gpm Total Hydraulic Flow 10.1 gpm 12.8 gpm Overall Hydraulic Pump Flow 10.1 gpm 12.8 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published None standard (up to 3 optional) No. of Optional Remote Valves Up to 3 (self canceling detent valve or float detent valve options) Optional, up to 3 (double-acting valve or float detent valve options, any position) ▶ Fluid CapacityFuel Tank Capacity 11.1 gal 13.5 gal Coolant Capacity 6.3 qt 7.9 qt Crankcase Capacity 7.1 qt 7.1 qt Transmission / Hydraulic System Capacity F (2WD gear): 7.4 gal; DT (4WD gear): 7.5 gal; HST (4WD): 6.2 gal 11.1 gal Front Axle Fluid Capacity 4.8 qt 6.9 qt ▶ PTO & HitchPTO Type Live independent PTO with hydraulic clutch Live independent (hydraulic clutch) PTO Rear 540 rpm 540 rpm @ 2476 engine rpm Mid-PTO Availability No mid-PTO offered Optional Category, 3-Point Hitch Category I SAE Category I Hitch Lift Capacity 1998 lb 3,750 lb Hitch Lift Capacity (at 24”) 1433 lb 2646 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type F (2WD gear), DT (4WD gear): Synchronized shuttle gear transmission, 8F/8R; HST (4WD): Hydrostatic transmission, 3-range Hydrostatic No. of Speeds F (2WD gear), DT (4WD gear): 8F/8R; HST (4WD): 3-range 3-Range, 6 speeds (H-DS), infinitely variable in each Max Travel Speed (Forward) F (2WD gear), DT (4WD gear): 13.2 mph; HST (4WD): 14.1 mph 16.5 mph Max Travel Speed (Reverse) F (2WD gear), DT (4WD gear): 13.1 mph; HST (4WD): 12.7 mph 14.9 mph Clutch F (2WD gear), DT (4WD gear): Dry type dual stage; HST (4WD): Dry type single stage Not Published Differential Lock & Limited Slip Options Rear differential lock standard Rear differential lock, standard ▶ Chassis, Steering & ControlsFrame Type Two-post foldable ROPS (factory certified) with retractable seat belt Not Published Steering Integral power steering Hydrostatic power steering Brakes Mechanical wet disc type, pedals can be locked together Wet disc type, mechanically activated Seat Suspension & Adjustability Not Published Deluxe suspension seat with swivel (standard); Air-Ride seat (optional) Front Axle Type F (2WD gear): Tubular steel, non-adjustable tread spacing; DT (4WD gear), HST (4WD): Bevel gear front axle, non-adjustable tread spacing 4WD: Bevel gear front axle, non-adjustable tread spacing Front Axle Rating 2865 lb (at 41.3 in tread, 2WD and 4WD models) Not Published Drawbar Capacity 730 lb 1,433 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch F (2WD gear): 119.1 in; DT (4WD gear), HST (4WD): 116.3 in 115.0 in (without 3-point hitch) Overall Width 55.1 in 59.8 in Wheelbase 63.3 in 71.1 in Ground Clearance F (2WD gear): 13.6 in; DT (4WD gear), HST (4WD): 13.5 in 13.5 in Min. Turn Radius without Brakes F (2WD gear): 8.9 ft; DT (4WD gear), HST (4WD): 10.5 ft 8.9 ft (with brake applied) Height to Top of ROPS 91.7 in 97.2 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) F (2WD gear): 2590 lb; DT (4WD gear): 2767 lb; HST (4WD): 2778 lb 3505 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural (standard); R3 Turf; R4 Industrial (4WD) R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front F (2WD gear): 5-15 (7.5L-15 optional); DT (4WD gear), HST (4WD): 7.2-16 7.0-16 R1 Agricultural - Rear 11.2-24 12.4-24 R3 Turf - Front F (2WD gear): 23x8.5-12; DT (4WD gear), HST (4WD): 25x8.5-14 27x10.50-15 R3 Turf - Rear 13.6-16 41x18LL-16.1 R4 Industrial - Front 27x8.5-15 (4WD) 10-16.5 R4 Industrial - Rear 15-19.5 (4WD) 420/70-24 ▶ Loader & AttachmentsQuick Attach Loader System LA525: 2-Lever Quick Coupler, no tools required to attach and detach loader LA555: Mechanical 2-Lever Quick Coupler (standard); LA805: Mechanical 2-Lever Quick Coupler (standard); Hydraulic 2-Lever Quick Coupler (optional); Single Lever Hose Quick Coupler (optional) Loader Model LA525 LA555 or LA805 Loader Lift Height LA525: 94.3 in LA555: 96.4 in; LA805: 104.7 in Loader Lift Capacity (Full Height) LA525: 1131 lb LA555: 1190 lb; LA805: 1715 lb Loader Breakout Force LA525: 2462 lbf LA555: 2030 lb; LA805: 2549 lb (19.7 in forward of pivot pin) ▶ WarrantyWarranty Length & Coverage 24 months or 1500 hours (general) Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. ▶ ITC Company AccessoriesAccessories that fit None tagged yet
