▶ EngineEngine Manufacturer Kubota Kubota Engine Model F (2WD gear), DT (4WD gear): D1803-CR-E4-LB3; HST (4WD): D1803-CR-E4-LB4 V1903-A Engine Type 3-cylinder, multi-valve, naturally aspirated, common-rail, liquid-cooled diesel Indirect injection, vertical, water-cooled, 4-cycle diesel No. of Cylinders 3 4 Displacement 111.4 in³ 113.3 in³ Rated Engine Speed 2700 rpm 2600 rpm Engine Power (Gross) 37.5 hp 38.5 hp PTO Power F (2WD gear), DT (4WD gear): 32.1 hp; HST (4WD): 30.6 hp 31 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled, water with pressurized radiator Water-cooled Air Cleaner Dry paper single element Not Published Fuel System Common-rail, direct injection, electronic control Indirect injection Alternator 40 A Not Published ▶ HydraulicsPump Type Open center tandem pump, gear type Not Published Implement Flow 6.3 gpm 7.8 gpm Steering Flow 3.8 gpm Not Published Total Hydraulic Flow 10.1 gpm Not Published Overall Hydraulic Pump Flow 10.1 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Up to 3: self-canceling detent valve or float detent valve Not Published ▶ Fluid CapacityFuel Tank Capacity 11.1 gal 9.2 gal Coolant Capacity 6.3 qt 7.9 qt Crankcase Capacity 7.1 qt 6.3 qt Transmission / Hydraulic System Capacity F (2WD gear): 7.4 gal; DT (4WD gear): 7.5 gal; HST (4WD): 6.2 gal 10.3 gal Front Axle Fluid Capacity 4.8 qt Not Published ▶ PTO & HitchPTO Type Live-continuous running Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability No mid-PTO offered Optional mid-PTO, 2000 rpm (USA No. 5, Kubota 10-tooth involute spline) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,874 lb (at lift points) 2,870 lb Hitch Lift Capacity (at 24”) 1,433 lb 2,310 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type F (2WD gear), DT (4WD gear): synchronized shuttle, 8F/8R; HST (4WD): hydrostatic, 3-range F (2WD), DT (4WD): synchronized shuttle and synchronized transmission, 8F/8R; GST (4WD): Glide Shift, 8F/8R No. of Speeds F (2WD gear), DT (4WD gear): 8F/8R; HST (4WD): 3-range 8F/8R Max Travel Speed (Forward) F (2WD gear), DT (4WD gear): 13.2 mph; HST (4WD): 14.1 mph 14.3 mph Max Travel Speed (Reverse) F (2WD gear), DT (4WD gear): 13.1 mph; HST (4WD): 12.7 mph 13.1 mph Clutch F (2WD gear), DT (4WD gear), HST (4WD): dry type single stage Dry type single stage Differential Lock & Limited Slip Options Rear differential lock standard Not Published ▶ Chassis, Steering & ControlsFrame Type Two-post foldable ROPS (factory certified) with retractable seat belt Two-post ROPS Steering Integral power steering Hydrostatic power steering Brakes Mechanical wet disc type, pedals can be locked together Wet disc type Seat Suspension & Adjustability Not Published Not Published Front Axle Type F (2WD gear): tubular steel, non-adjustable tread spacing; DT (4WD gear), HST (4WD): bevel-gear front axle, non-adjustable tread spacing Not Published Front Axle Rating 2,865 lb (at 41.3 in tread, 2WD and 4WD models) Not Published Drawbar Capacity 730 lb 1,430 lb ▶ Dimensions & ManeuverabilityOverall Width 55.1 in 56.1 in Wheelbase 63.3 in F (2WD): 71.3 in; DT (4WD), GST (4WD): 71.1 in Ground Clearance F (2WD gear): 13.6 in; DT (4WD gear), HST (4WD): 13.5 in 13.2 in Min. Turn Radius without Brakes F (2WD gear): 8.9 ft; DT (4WD gear), HST (4WD): 10.5 ft F (2WD), DT (4WD): 8.2 ft; GST (4WD): 8.5 ft (with brake applied) Height to Top of ROPS 97.1 in 83.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length F (2WD gear): 119.1 in; DT (4WD gear), HST (4WD): 116.3 in (with 3-point hitch) 118.1 in (without 3-point hitch) ▶ WeightTractor Weight (Base) F (2WD gear): 2,557 lb; DT (4WD gear): 2,734 lb; HST (4WD): 2,778 lb F (2WD): 2,800 lb; DT (4WD): 2,955 lb; GST (4WD): 2,965 lb (with ROPS) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural (standard); R3 Turf; R4 Industrial (4WD) Ag: 6.00-16 (2WD) or 8.3-16 (4WD) front, 13.6-24 rear R1 Agricultural - Front F (2WD gear): 5-15 (7.5L-15 optional); DT (4WD gear), HST (4WD): 7.2-16 F (2WD): 6.00-16; DT (4WD), GST (4WD): 8.3-16 R1 Agricultural - Rear 11.2-24 13.6-24 R3 Turf - Front F (2WD gear): 23x8.5-12; DT (4WD gear), HST (4WD): 25x8.5-14 Not Published R3 Turf - Rear 13.6-16 Not Published R4 Industrial - Front 27x8.5-15 (4WD) Not Published R4 Industrial - Rear 15-19.5 (4WD) Not Published ▶ Loader & AttachmentsQuick Attach Loader System LA525: 2-lever quick coupler, tool-free attach and detach Not Published Loader Model LA525 LA680; LA681 Loader Lift Height LA525: 94.3 in (at pivot pin) LA680: 102.4 in; LA681: 102.4 in Loader Lift Capacity (Full Height) LA525: 1,131 lb (at pivot pin) LA680: 1,499 lb; LA681: 1,499 lb Loader Breakout Force LA525: 2,462 lbf (bucket pivot pin) LA680: 2,557 lbf; LA681: 2,557 lbf ▶ WarrantyWarranty Length & Coverage 24 months or 1500 hours (general) Not Published
