▶ EngineEngine Manufacturer Kubota Kubota Engine Model F (2WD gear), DT (4WD gear): D1803-CR-E4-LB3; HST (4WD): D1803-CR-E4-LB4 D1803 Engine Type Liquid-cooled, 3-cylinder, 4-cycle, multi-valve diesel, naturally aspirated, common rail direct injection Diesel, 3-cylinder, liquid-cooled No. of Cylinders 3 3 Displacement 111.4 in³ 111.4 in³ Rated Engine Speed 2700 rpm 2700 rpm Engine Power (Gross) 37.5 hp 37.4 hp PTO Power F (2WD gear), DT (4WD gear): 32.1 hp; HST (4WD): 30.6 hp Gear: 31.5 hp; HST: 30 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled, water with pressurized radiator Not Published Air Cleaner Dry paper single element Not Published Fuel System Common rail (CRS) direct injection, electronic fuel injection Not Published Alternator 40 A, 12 V Not Published ▶ HydraulicsPump Type Open center tandem pump, gear type Not Published Implement Flow 6.3 gpm 6.3 gpm Steering Flow 3.8 gpm Not Published Total Hydraulic Flow 10.1 gpm Not Published Overall Hydraulic Pump Flow 10.1 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Up to 3 (self canceling detent valve or float detent valve options) Not Published ▶ Fluid CapacityFuel Tank Capacity 11.1 gal 10 gal Coolant Capacity 6.3 qt Not Published Crankcase Capacity 7.1 qt Not Published Transmission / Hydraulic System Capacity F (2WD gear): 7.4 gal; DT (4WD gear): 7.5 gal; HST (4WD): 6.2 gal Gear: 7.1 gal; HST: 6.2 gal Front Axle Fluid Capacity 4.8 qt Not Published ▶ PTO & HitchPTO Type Live independent PTO with hydraulic clutch Not Published PTO Rear 540 rpm 540 rpm Mid-PTO Availability No mid-PTO offered Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,998 lb Not Published Hitch Lift Capacity (at 24”) 1,433 lb Not Published Lift Control Type Position control Not Published ▶ Transmission & DrivetrainTransmission Type F (2WD gear), DT (4WD gear): Synchronized shuttle gear transmission, 8F/8R; HST (4WD): Hydrostatic transmission, 3-range Gear: 8-speed constant mesh; HST: hydrostatic No. of Speeds F (2WD gear), DT (4WD gear): 8F/8R; HST (4WD): 3-range Gear: 8F/4R; HST: infinite (3-range) Max Travel Speed (Forward) F (2WD gear), DT (4WD gear): 13.2 mph; HST (4WD): 14.1 mph Not Published Max Travel Speed (Reverse) F (2WD gear), DT (4WD gear): 13.1 mph; HST (4WD): 12.7 mph Not Published Clutch F (2WD gear), DT (4WD gear): Dry type dual stage; HST (4WD): Dry type single stage Not Published Differential Lock & Limited Slip Options Rear differential lock standard Rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Two-post foldable ROPS (factory certified) with retractable seat belt Not Published Steering Integral power steering Hydrostatic power steering Brakes Mechanical wet disc type, pedals can be locked together Wet disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type F (2WD gear): Tubular steel, non-adjustable tread spacing; DT (4WD gear), HST (4WD): Bevel gear front axle, non-adjustable tread spacing Bevel gear front axle Front Axle Rating 2,865 lb (at 41.3 in tread, 2WD and 4WD models) Not Published Drawbar Capacity 730 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch F (2WD gear): 119.1 in; DT (4WD gear), HST (4WD): 116.3 in 2WD: 110.6 in; 4WD: 106.3 in Overall Width 55.1 in 55.1 in Wheelbase 63.3 in 63.3 in Ground Clearance F (2WD gear): 13.6 in; DT (4WD gear), HST (4WD): 13.5 in 2WD: 13.6 in; 4WD: 13.4 in Min. Turn Radius without Brakes F (2WD gear): 8.9 ft; DT (4WD gear), HST (4WD): 10.5 ft Not Published Height to Top of ROPS 91.7 in 91.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) F (2WD gear): 2,590 lb; DT (4WD gear): 2,767 lb; HST (4WD): 2,778 lb 2WD gear: 2,480 lb; 4WD gear: 2,657 lb; 4WD hydro: 2,668 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural (standard); R3 Turf; R4 Industrial (4WD) 2WD: 5.00-15 front; 4WD: 7.2-16 front; 11.2-24 rear R1 Agricultural - Front F (2WD gear): 5-15 (7.5L-15 optional); DT (4WD gear), HST (4WD): 7.2-16 2WD: 5.00-15; 4WD: 7.2-16 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front F (2WD gear): 23x8.5-12; DT (4WD gear), HST (4WD): 25x8.5-14 2WD: 23x8.50-12; 4WD: 25x8.50-14 R3 Turf - Rear 13.6-16 13.6-16 R4 Industrial - Front 27x8.5-15 (4WD) 27x8.50-15 (4WD) R4 Industrial - Rear 15-19.5 (4WD) 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System LA525: 2-Lever Quick Coupler, no tools required to attach and detach loader LA524 quick attach loader Loader Model LA525 LA524 Loader Lift Height LA525: 94.3 in LA524: 94.3 in Loader Lift Capacity (Full Height) LA525: 1,131 lb LA524: 1,131 lb (at pin) Loader Breakout Force LA525: 2,462 lbf LA524: 2,462 lbf (at pin) ▶ WarrantyWarranty Length & Coverage 24 months or 1500 hours (general) Not Published
