▶ EngineEngine Manufacturer Kubota Yanmar Engine Model F (2WD gear), DT (4WD gear): D1803-CR-E4-LB3; HST (4WD): D1803-CR-E4-LB4 3TNV88-CR Engine Type 3-cylinder, multi-valve, naturally aspirated, common-rail, liquid-cooled diesel 3-cylinder, naturally aspirated diesel No. of Cylinders 3 3 Displacement 111.4 in³ 100.2 in³ Rated Engine Speed 2700 rpm 3000 rpm Engine Power (Gross) 37.5 hp 36.9 hp PTO Power F (2WD gear), DT (4WD gear): 32.1 hp; HST (4WD): 30.6 hp 30.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled, water with pressurized radiator Liquid-cooled Air Cleaner Dry paper single element Dual dry Fuel System Common-rail, direct injection, electronic control CRDI Alternator 40 A 50 A, 12 V ▶ HydraulicsPump Type Open center tandem pump, gear type Dual gear pump Implement Flow 6.3 gpm 6.1 gpm Steering Flow 3.8 gpm 4.4 gpm Total Hydraulic Flow 10.1 gpm 10.5 gpm Overall Hydraulic Pump Flow 10.1 gpm 10.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published None No. of Optional Remote Valves Up to 3: self-canceling detent valve or float detent valve 1 or 2 (single or double rear remote with detent, accessory) ▶ Fluid CapacityFuel Tank Capacity 11.1 gal 9.0 gal Coolant Capacity 6.3 qt 7.4 qt Crankcase Capacity 7.1 qt 6 qt Transmission / Hydraulic System Capacity F (2WD gear): 7.4 gal; DT (4WD gear): 7.5 gal; HST (4WD): 6.2 gal 8.5 gal Front Axle Fluid Capacity 4.8 qt 8.7 qt ▶ PTO & HitchPTO Type Live-continuous running Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability No mid-PTO offered Optional (Mid-PTO kit) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,874 lb (at lift points) 2,639 lb Hitch Lift Capacity (at 24”) 1,433 lb 1,558 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type F (2WD gear), DT (4WD gear): synchronized shuttle, 8F/8R; HST (4WD): hydrostatic, 3-range Mechanical No. of Speeds F (2WD gear), DT (4WD gear): 8F/8R; HST (4WD): 3-range 12 forward / 12 reverse Max Travel Speed (Forward) F (2WD gear), DT (4WD gear): 13.2 mph; HST (4WD): 14.1 mph 15.0 mph Max Travel Speed (Reverse) F (2WD gear), DT (4WD gear): 13.1 mph; HST (4WD): 12.7 mph Not Published Clutch F (2WD gear), DT (4WD gear), HST (4WD): dry type single stage Dry single plate Differential Lock & Limited Slip Options Rear differential lock standard Differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Two-post foldable ROPS (factory certified) with retractable seat belt Unit frame: engine, clutch housing, transmission and front axle support bolted into one rigid assembly Steering Integral power steering Hydrostatic Brakes Mechanical wet disc type, pedals can be locked together Wet disc Seat Suspension & Adjustability Not Published Fore and aft sliding seat with cushion strength adjustment Front Axle Type F (2WD gear): tubular steel, non-adjustable tread spacing; DT (4WD gear), HST (4WD): bevel-gear front axle, non-adjustable tread spacing 4WD center-pivot, reverse Elliott type Front Axle Rating 2,865 lb (at 41.3 in tread, 2WD and 4WD models) Not Published Drawbar Capacity 730 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 55.1 in 53.5 in Wheelbase 63.3 in 64.5 in Ground Clearance F (2WD gear): 13.6 in; DT (4WD gear), HST (4WD): 13.5 in 12.8 in Min. Turn Radius without Brakes F (2WD gear): 8.9 ft; DT (4WD gear), HST (4WD): 10.5 ft 116 in Height to Top of ROPS 97.1 in 94.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length F (2WD gear): 119.1 in; DT (4WD gear), HST (4WD): 116.3 in (with 3-point hitch) 126 in (with 3-point hitch) ▶ WeightTractor Weight (Base) F (2WD gear): 2,557 lb; DT (4WD gear): 2,734 lb; HST (4WD): 2,778 lb 3,020 lb (with ROPS) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural (standard); R3 Turf; R4 Industrial (4WD) R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front F (2WD gear): 5-15 (7.5L-15 optional); DT (4WD gear), HST (4WD): 7.2-16 Farm Specialist 8.0-16 NHS TL 6PR R1 Agricultural - Rear 11.2-24 Farm Specialist 12.4-24 NHS TL 6PR (standard); Farm Specialist 11.2-24 NHS TL 6PR (option) R3 Turf - Front F (2WD gear): 23x8.5-12; DT (4WD gear), HST (4WD): 25x8.5-14 27x10.5-15 R3 Turf - Rear 13.6-16 12.5-20 R4 Industrial - Front 27x8.5-15 (4WD) 27x10.5-15 R4 Industrial - Rear 15-19.5 (4WD) 12.5x20 ▶ Loader & AttachmentsQuick Attach Loader System LA525: 2-lever quick coupler, tool-free attach and detach TX39H: quick attachment assembly Loader Model LA525 TX39H Loader Lift Height LA525: 94.3 in (at pivot pin) TX39H: 101.5 in Loader Lift Capacity (Full Height) LA525: 1,131 lb (at pivot pin) TX39H: 2,116 lb (at pivot pin) Loader Breakout Force LA525: 2,462 lbf (bucket pivot pin) TX39H: 3,435 lb (at pivot pin, ground level) ▶ WarrantyWarranty Length & Coverage 24 months or 1500 hours (general) Basic 24 months or 2,000 hours, parts and labor; non-commercial: powertrain 72 months or 3,000 hours; rental and commercial: powertrain 36 months or 2,000 hours; loaders and backhoes 12 months ▶ ITC Company AccessoriesAccessories that fit None tagged yet
