▶ EngineEngine Manufacturer Kubota Kubota Kubota Engine Model D1803-CR-E5 D1803-CR-E5 V2403-CR-E4-GL5 Engine Type Direct injection, vertical, water-cooled 4-cycle, diesel Direct injection, vertical, water-cooled 4-cycle, diesel Liquid-cooled, 4-cycle multi valve, diesel, Turbocharged No. of Cylinders 3 3 4 Displacement 111.4 in³ 111.4 in³ 148.5 in³ Rated Engine Speed 2700 rpm 2700 rpm 2600 rpm Engine Power (Gross) 37.5 hp 33 hp 62 hp PTO Power 30.3 hp 26.1 hp 53 hp Engine Emissions Constraints Not Published Not Published Tier 4 Cooling System Type Water-cooled Water-cooled Liquid-cooled Air Cleaner Dry type, single element Dry type, single element Dry paper, dual element Fuel System Direct injection Direct injection Electronic Common Rail System (CRS) Alternator 45 A, 12 V 45 A, 12 V 45 A, 12 V ▶ HydraulicsPump Type Not Published Not Published Tandem pump - gear type Implement Flow 6.3 gpm 6.3 gpm 9.4 gpm Steering Flow 3.8 gpm 3.8 gpm 4.7 gpm Total Hydraulic Flow 10.1 gpm (6.3 + 3.8, computed) 10.1 gpm (6.3 + 3.8, computed) 14.1 gpm Overall Hydraulic Pump Flow 10.1 gpm (6.3 + 3.8, computed) 10.1 gpm (6.3 + 3.8, computed) 14.1 gpm Hydraulic System Type Open center Open center Open center Rear Remote Hydraulic Flow Not Published Not Published Not Published No. of Standard Remote Valves Not Published Not Published Not Published No. of Optional Remote Valves Not Published Not Published Optional, up to 3: double-acting valve or float detent valve, any position ▶ Fluid CapacityFuel Tank Capacity 11.1 gal 11.1 gal 13.5 gal Coolant Capacity 6.3 qt 6.3 qt 8.7 qt Crankcase Capacity 7.1 qt 7.1 qt 9.9 qt Transmission / Hydraulic System Capacity 6.9 gal 6.9 gal 11.9 gal Front Axle Fluid Capacity 4.8 qt 4.8 qt Not Published ▶ PTO & HitchPTO Type Live independent PTO with hydraulic clutch Live independent PTO with hydraulic clutch Live independent (hydraulic clutch) PTO Rear 540 rpm 540 rpm 540 rpm @ 2400 engine rpm Mid-PTO Availability Not Published Not Published Optional Category, 3-Point Hitch SAE Category I SAE Category I SAE Category I & II Hitch Lift Capacity 1,998 lb 1,998 lb 3,858 lb Hitch Lift Capacity (at 24”) 1,435 lb 1,435 lb 2,976 lb Lift Control Type Position control Position control Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic transmission (3-range) Hydrostatic transmission (3-range) Hydrostatic transmission No. of Speeds 3-range 3-range 3-range, 6 speeds (H-DS), infinitely variable in each Max Travel Speed (Forward) 14.1 mph 14.1 mph 16.8 mph Max Travel Speed (Reverse) 12.7 mph 12.7 mph 15.2 mph Clutch Not Applicable Not Applicable Not Published Differential Lock & Limited Slip Options Rear differential lock, pedal operated Rear differential lock, pedal operated Rear differential lock, standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Not Published Steering Integral type power steering Integral type power steering Hydrostatic power steering Brakes Mechanical, wet disc type Mechanical, wet disc type Wet disc type, mechanically activated Seat Suspension & Adjustability Suspension seat with fore/aft travel adjustment and suspension tension adjustment Suspension seat with fore/aft travel adjustment and suspension tension adjustment Suspension seat with swivel function Front Axle Type Cast-iron front axle Cast-iron front axle 4WD: Bevel gear front axle, non-adjustable tread spacing Front Axle Rating Not Published Not Published Not Published Drawbar Capacity 730 lb 730 lb 1,433 lb ▶ Dimensions & ManeuverabilityOverall Width 55.1 in 55.1 in 67.3 in Wheelbase 63.4 in 63.4 in 75.4 in Ground Clearance 13.4 in 13.4 in 15.4 in Min. Turn Radius without Brakes 8.2 ft (with brake applied) 8.2 ft (with brake applied) 9.2 ft (with brake applied) Height to Top of ROPS 91.7 in 91.7 in 98.0 in Height to Top of ROPS (folded) Not Published Not Published Not Published Height to Top of Cab Model Not Published Not Published Not Applicable Overall Length 108.7 in (without 3-point hitch) 108.5 in (without 3-point hitch) 135.0 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 2,778 lb 2,778 lb 3,990 lb Weight with ROPS and Loader Not Published Not Published Not Published Weight with Cab and Loader Not Published Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural; Turf; Industrial (R4) R1 Agricultural; R3 Turf; R4 Industrial Standard R1 (9.5-16 / 14.9-26); options: R1 (9.5-16 / 13.6-28), R4 (10-16.5 / 17.5L-24), R3 (29x12.50-15 / 44x18-20), LSW R3 (LSW305R343 / LSW610R470) R1 Agricultural - Front 7.2-16 7.2-16 9.5-16 R1 Agricultural - Rear 11.2-24 11.2-24 14.9-26; 13.6-28 R3 Turf - Front 25X8.50-14 25X8.50-14 29X12.50-15 R3 Turf - Rear 13.6-16 13.6-16 44X18-20 R4 Industrial - Front 27X8.50-15 27X8.50-15 10-16.5 R4 Industrial - Rear 15-19.5 15-19.5 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Front Loader (LA526 - 2 Lever Quick Coupler (OPT)) Front Loader (LA526 - 2 Lever Quick Coupler (OPT)) 2-lever mechanical quick coupler (standard); 2-lever hydraulic quick coupler (optional); single-lever hose coupler (optional) Loader Model LA526 LA526 LA1055 Loader Lift Height 94.8 in (at pivot pin) 94.8 in 112.7 in (at pivot pin) Loader Lift Capacity (Full Height) 1,144 lb (at pivot pin, max. height) 1,144 lb 2,361 lb (at pivot pin) Loader Breakout Force Not Published Not Published 3,171 lbf ▶ WarrantyWarranty Length & Coverage Basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: powertrain 36 months or 2,000 hours Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours Not Published ▶ ITC Company AccessoriesAccessories that fit
