▶ EngineEngine Manufacturer Kubota Yanmar Engine Model D1803-CR-E5 3TNV88-CR Engine Type Direct injection, vertical, water-cooled 4-cycle, diesel Natural aspiration No. of Cylinders 3 3 Displacement 111.4 in³ 100.2 in³ Rated Engine Speed 2700 rpm 3000 rpm Engine Power (Gross) 37.5 hp 36.9 hp PTO Power 32.1 hp 30.2 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dry type, single element Dual dry Fuel System Direct injection Common Rail Direct Injection Alternator 45 A, 12 V 55 A, 12 V ▶ HydraulicsPump Type Not Published Dual gear pump Implement Flow 6.3 gpm 6.4 gpm Steering Flow 3.8 gpm 4.6 gpm Total Hydraulic Flow 10.1 gpm (6.3 + 3.8, computed) 11.0 gpm Overall Hydraulic Pump Flow 10.1 gpm (6.3 + 3.8, computed) 11.0 gpm Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 1 No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 11.1 gal 9.0 gal Coolant Capacity 6.3 qt 7.4 qt Crankcase Capacity 7.1 qt 6.0 qt Transmission / Hydraulic System Capacity Not Published 9.25 gal Front Axle Fluid Capacity 4.8 qt 8.7 qt ▶ PTO & HitchPTO Type Live-continuous running Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published No mid-PTO offered Category, 3-Point Hitch SAE Category I Category I Hitch Lift Capacity 1,998 lb 2,646 lb Hitch Lift Capacity (at 24”) 1,435 lb 1,764 lb Lift Control Type Position control Position ▶ Transmission & DrivetrainTransmission Type Gear shift with synchronized shuttle 12F/12R Syncro Shuttle No. of Speeds 8 forward, 8 reverse 12 forward, 12 reverse Max Travel Speed (Forward) 13.2 mph 15.0 mph Max Travel Speed (Reverse) 13.2 mph Not Published Clutch Dry type dual stage Single plate dry clutch (8.86 in diameter); hydraulic clutch assembly for Independent PTO models Differential Lock & Limited Slip Options Rear differential lock, pedal operated 4WD, differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Unit frame: engine, clutch housing, transmission and front axle support bolted into one rigid assembly Steering Integral type power steering Hydrostatic power steering Brakes Mechanical, wet disc type Wet disc Seat Suspension & Adjustability Suspension seat with fore/aft travel adjustment and suspension tension adjustment Suspension seat with armrests and retractable seat belt, standard Front Axle Type Cast-iron front axle Center-pivot, reverse Elliot type (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity 730 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width 55.1 in 53.5 in Wheelbase 63.4 in 64.5 in Ground Clearance 13.4 in 12.8 in Min. Turn Radius without Brakes 8.2 ft (with brake applied) 116 in Height to Top of ROPS 91.7 in 94.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 108.7 in (without 3-point hitch) 126 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 2,767 lb 3,020 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural; Turf; Industrial (R4) Titan (USA): R4 Industrial (Std), R1 Agricultural (Opt), R3 Turf (Opt), R14 (Opt) R1 Agricultural - Front 7.2-16 7-16 R1 Agricultural - Rear 11.2-24 11.2x24 R3 Turf - Front 25X8.50-14 28x8.5-15 R3 Turf - Rear 13.6-16 41x14-20 R4 Industrial - Front 27X8.50-15 10-16.5 R4 Industrial - Rear 15-19.5 43x16-20 ▶ Loader & AttachmentsQuick Attach Loader System Front Loader (LA526 - 2 Lever Quick Coupler (OPT)) L102: Skid-steer compatible quick-attach Loader Model LA526 L102 Loader Lift Height 94.8 in (at pivot pin) L102: 102 in Loader Lift Capacity (Full Height) 1,144 lb (at pivot pin, max. height) L102: 2,116 lb to full height Loader Breakout Force Not Published L102: 3,435 lb ▶ WarrantyWarranty Length & Coverage Basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: powertrain 36 months or 2,000 hours Basic 2 years or 2,000 hours; powertrain 8 years or 3,000 hours, no deductible, parts and labor ▶ ITC Company AccessoriesAccessories that fit
