▶ EngineEngine Manufacturer Kubota Kubota Engine Model V2403-CR-E4-GL2 D1703-M-DI-E4 Engine Type Naturally aspirated, multi-valve, liquid-cooled diesel Direct injection, vertical, water-cooled, 4-cycle diesel No. of Cylinders 4 3 Displacement 148.5 in³ 100.47 in³ Rated Engine Speed 2600 rpm 2200 rpm Engine Power (Gross) 42 hp 24.8 hp PTO Power 32.5 hp 19 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Dry paper, dual element Dry paper single element (dual optional) Fuel System Electronic CRS (Common Rail System) Direct injection Alternator 40 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Tandem pump - gear type Open center tandem pump, gear type Implement Flow 9.4 gpm 5.15 gpm Steering Flow 4.7 gpm 3.11 gpm Total Hydraulic Flow 14.1 gpm 8.26 gpm Overall Hydraulic Pump Flow 14.1 gpm 8.26 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None standard (up to 3 optional) Not Published No. of Optional Remote Valves Optional, up to 3: double-acting valve or float detent valve, any position Up to 3: self-canceling detent valve or float detent valve ▶ Fluid CapacityFuel Tank Capacity 13.5 gal 10.0 gal Coolant Capacity 7.9 qt 6.3 qt Crankcase Capacity 8.7 qt 6.0 qt Transmission / Hydraulic System Capacity 11.4 gal HST (4WD): 6.2 gal; DT (2WD): 7.1 gal; DT (4WD): 7.3 gal Front Axle Fluid Capacity 6.9 qt 6.9 qt ▶ PTO & HitchPTO Type Live independent (hydraulic clutch) F (2WD), DT (4WD): Transmission driven with overrunning clutch; HST (4WD): Live-continuous running PTO Rear 540 rpm @ 2476 engine rpm 540 rpm Mid-PTO Availability Optional No mid-PTO offered Category, 3-Point Hitch SAE Category I Category I Hitch Lift Capacity 3,858 lb 1,918 lb Hitch Lift Capacity (at 24”) 2,760 lb 1,389 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic Hydrostatic transmission (3-range) No. of Speeds 3-Range, 6 speeds (H-DS), infinitely variable in each 3-range Max Travel Speed (Forward) 16.8 mph 11.5 mph Max Travel Speed (Reverse) 15.1 mph 10.3 mph Clutch Not Published Not Published Differential Lock & Limited Slip Options Rear differential lock, standard Rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Integral type power steering Brakes Wet disc type, mechanically activated Wet disc type Seat Suspension & Adjustability Deluxe suspension seat with swivel (standard); Air-Ride seat (optional) Suspension seat with fore/aft travel adjustment and suspension tension adjustment Front Axle Type 4WD: Bevel gear front axle, non-adjustable tread spacing Bevel gear front axle, non-adjustable tread spacing Front Axle Rating Not Published 2,865 lb (4WD, at 43.1 in tread) Drawbar Capacity 1,433 lb 730 lb ▶ Dimensions & ManeuverabilityOverall Width 66.5 in 55.1 in Wheelbase 74.6 in 63.3 in Ground Clearance 14.2 in 13.4 in Min. Turn Radius without Brakes 8.9 ft (with brake applied) 8.2 ft (with brake applied) Height to Top of ROPS 97.6 in 91.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model n/a (ROPS model) Not Published Overall Length 129.5 in (with 3-point hitch) 106.3 in (without 3-point hitch) ▶ WeightTractor Weight (Base) 3,759 lb 2,623 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural; R4 Industrial R1 Agricultural - Front 8.3-16 7.2-16 R1 Agricultural - Rear 14.9-24 11.2-24 R3 Turf - Front 27-10.50LL15 Not Published R3 Turf - Rear 41-18LLx16.1 Not Published R4 Industrial - Front 10-16.5 27X8.50-15 R4 Industrial - Rear 17.5L-24 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System 2-lever mechanical quick coupler (standard); 2-lever hydraulic quick coupler (optional); single-lever hose coupler (optional) Front Loader (LA525 - 2 Lever Quick Coupler) Loader Model LA805 LA525 Loader Lift Height 104.7 in (at pivot pin) 94.3 in (at pivot pin) Loader Lift Capacity (Full Height) 1,715 lb (at pivot pin) 1,082 lb (at pivot pin) Loader Breakout Force 2,549 lb 2,373 lbf (at pivot pin) ▶ WarrantyWarranty Length & Coverage Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours ▶ ITC Company AccessoriesAccessories that fit
